- Page 1 LANYA ELECTRONIC Co., Ltd. User Guide & Important Information BSH560 Bluetooth Stereo Headset...
-
Page 2: Table Of Contents
CONTENTS Product introduction ..................3 C o n t e n t s ................... . . 4 Button operation..................5 C h a r g i n g . -
Page 3: Product Introduction
PRODUCT INTRODUCTION Thank you for buying the RaveTouch Bluetooth Stereo Head e from White Label. These Head e are designed to be convenient , sty lish and provide high quality audio Playback from any Bluetooth enabled Audio Device or wired only device. RaveTouch Bluetooth Stereo head e can also be used to receive tele p h one calls... -
Page 4: Contents
CONTENTS USB Cable WhiteLabel RaveTouch Bluetooth Stereo Headset... -
Page 5: Button Operation
BUTTON OPERATION 1. Volume + 2. Volume - 3. Mic 4. 3.5mm Audio Input 5. LED Indicator 6. Folding Hinges 7. Multifunction 8. USB charging Port 9. Multi-touch Control... -
Page 6: Charging
CHARGING Use the USB cable connect with headphone and PC to charge. When the power is extremely low,need 3 hours to full charged. No need to stop use the headphone when charging,you also can listen music or on the phone. In the charging can directly identify the audio equipment in the computer. -
Page 7: Connection Guide
CONNECTION GUIDE Three Methods 1. Wireless Bluetooth connection for Head e s a.Power on and press the Multifunction Button for 7 seconds to start pairing mode. Connection b.Open the mobile phone/tablet/laptop Bluetooth setting. c.Search for Bluetooth device. d.Select “RaveTouch” and connect. e.You can play music after the connection is successful. -
Page 8: Led Indicator
LED INDICATOR 1. Power on : Blue light flash 3 times quickly 2. Power off : Red light flash 3 times quickly 3. Standby(not connected) ：Blue light flash one time every 5 seconds. 4. Standby(connected) : Blue light flash one time every 5 seconds. 5. -
Page 9: Basic Operation
BASIC OPERATION Power off Hold down the multifunction button for 3 seconds, blue light flashes 3 times and Head e beep. Pairing and connection Power off sate, hold down the multifunction button for 7 seconds until blue and red light flash alternately, use the mobile phone/tablet/computer to search the Bluetooth device and connect, the Head e beep after the connection is successful. -
Page 10: Voice Dialing
BASIC OPERATION End call Short press the multifunction button and Head e beep . Reject a call When there is incoming call, press multifunction button for 2 seconds and the Head e beep. Voice dialing Standby mode, double click the multifunction button.(the mobile phone need support this function) Switch call from Head e to Phone During a call, press the multifunction button for 2 seconds, the call will be transferred to... - Page 11 BASIC OPERATION Redial the last dialed number Standby mode, press volume(+) button for 3 seconds and Head e beep. Mic mute During a call, press volume(-) button for 2 seconds and the Head e s beep, opposite side can’t hear your voice. Using the same method can recover the microphone voice. Playback Controls 1.
- Page 12 BASIC OPERATION 3. Play /pause:When play music, short press multifunction button can play/pause music. 4. last/next track:When playing music, hold down the volume(-) button can Skip tack backwards, Hold down the volume(+) button can play the next track. Battery indicator Connected with iPhone or iPad can show the Bluetooth head e Battery charge level.
- Page 13 BASIC OPERATION Touch Controls The following functions can be controlled with the touch control function by making the following gestures by touching the left Head e outside face: 1. Play pause:Single finger touch(Figure 1). 2. Volume up:Single finger swipe up, swipe more to reach maximum volume(Figure 2). 3.
- Page 14 BASIC OPERATION (Figure 1) (Figure 2) ( Figure 3) ( Figure 4) ( Figure 5)
- Page 15 BASIC OPERATION Automatic quit pairing mode When there is no pairing competed within 3 minutes the pairing mode will automatically stop. Auto power-off Lost connection for 10minutes or the battery voltage below 3.0V,the Headphones will automatically power off, red light flash 3 times and Head e beep.
- Page 16 VOICE DIALING If speech recognition to open and use a hands-free set connect Head e s , you can make a call directly from the headset using voice recognition. 1.Double click the multifunction button, You will hear a voice boot prompt. 2.Say the name of the person you wish to call loudly.(Note: the mobile phone need support this function)
-
Page 17: Battery And Charging Notice
BATTERY CHARGE/LOW VOLTAGE ALARM When the head e is charging, the red light flashes slowly. Red light turns off when the head is fully charged. Usual charge time is 2-3 hours. When the red light flash one time every 30 seconds and have a warning sound it is means the battery is run out and need to charge soon. -
Page 18: W A R N I N G
WARNINGS • Avoid placing this product near extreme temperatures or humidity. • Do not use this product while operating a motor vehicle • Do not submerse or allow this product to come into contact with water. Use in dry locations only. -
Page 19: Fcc Caution
FCC CAUTION This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
