OPERATOR'S

MANUAL

SLIDING ROUTER TABLE

MODEL: RTS-3012

Baileigh Industrial, Inc.

P.O. Box 531

Manitowoc, WI 54221-0531

Phone: 920.684.4990

Fax: 920.684.3944

sales@baileighindustrial.com

REPRODUCTION OF THIS MANUAL IN ANY FORM WITHOUT WRITTEN APPROVAL OF BAILEIGH INDUSTRIAL, INC.

IS PROHIBITED. Baileigh Industrial, Inc. does not assume and hereby disclaims any liability for any damage or loss

caused by an omission or error in this Operator's Manual, resulting from accident, negligence, or other occurence.

Rev. 8/2012

Table of Contents

Summary of Contents for Baileigh RTS-3012

Page 1 REPRODUCTION OF THIS MANUAL IN ANY FORM WITHOUT WRITTEN APPROVAL OF BAILEIGH INDUSTRIAL, INC. IS PROHIBITED. Baileigh Industrial, Inc. does not assume and hereby disclaims any liability for any damage or loss caused by an omission or error in this Operator’s Manual, resulting from accident, negligence, or other occurence.
Page 2: Table Of Contents
Table of Contents THANK YOU & WARRANTY ..................1 INTRODUCTION ......................3 GENERAL NOTES......................3 SAFETY INSTRUCTIONS ....................4 SAFETY PRECAUTIONS ....................6 TECHNICAL SPECIFICATIONS ..................9 TECHNICAL SUPPORT ....................9 UNPACKING AND CLEANING ..................10 Cleaning ........................11 GETTING TO KNOW YOUR MACHINE ............... 12 INSTALLATION ......................
Page 3: Thank You & Warranty
THANK YOU & WARRANTY Thank you for your purchase of a machine from Baileigh Industrial. We hope that you find it productive and useful to you for a long time to come. Inspection & Acceptance. Buyer shall inspect all Goods within ten (10) days after receipt thereof. Buyer’s payment shall constitute final acceptance of the Goods and shall act as a waiver of the Buyer’s rights to inspect or...
Page 4 Baileigh Industrial makes every effort to ensure that our posted specifications, images, pricing and product availability are as correct and timely as possible. We apologize for any discrepancies that may occur. Baileigh Industrial reserves the right to make any and all changes deemed necessary in the course of business including but not limited to pricing, product specifications, quantities, and product availability.
Page 5: Introduction
After receiving your equipment remove the protective container. Do a complete visual inspection, and if damage is noted, photograph it for insurance claims and contact your carrier at once, requesting inspection. Also contact Baileigh Industrial and inform them of the unexpected occurrence. Temporarily suspend installation.
Page 6: Safety Instructions
IMPORTANT PLEASE READ THIS OPERATORS MANUAL CAREFULLY It contains important safety information, instructions, and necessary operating procedures. The continual observance of these procedures will help increase your production and extend the life of the equipment. SAFETY INSTRUCTIONS LEARN TO RECOGNIZE SAFETY INFORMATION This is the safety alert symbol.
Page 7 SAVE THESE INSTRUCTIONS. Refer to them often and use them to instruct others. PROTECT EYES Wear safety glasses or suitable eye protection when working on or around machinery. CUTTER HAZARD Keep hands and fingers away from the rotating cutter blades. These rotating cutters can be extremely dangerous if you do not follow proper safety procedures.
Page 8: Safety Precautions
SAFETY PRECAUTIONS Wood working can be dangerous if safe and proper operating procedures are not followed. As with all machinery, there are certain hazards involved with the operation of the product. Using the machine with respect and caution will considerably lessen the possibility of personal injury. However, if normal safety precautions are overlooked or ignored, personal injury to the operator may result.
Page 9 SAFETY PRECAUTIONS (cont.) 10. Cutting Depth. NEVER attempt to remove too much material in one pass. Making several light cuts produces a cleaner finish and helps to prevent kickback. 11. Dress appropriate. DO NOT wear loose fitting clothing or jewelry as they can be caught in moving machine parts.
Page 10 SAFETY PRECAUTIONS (cont.) 27. Be Sure all equipment is properly installed and grounded according to national, state, and local codes. If machine is equipped with a three-prong plug, it should be plugged into a three-hole electrical receptacle. If an adapter is used to accommodate a two-prong receptacle, the adapter plug must be attached to a known ground.
Page 11: Technical Specifications
TECHNICAL SPECIFICATIONS 3/4 hp – 5 hp (.56kw – 3.72kw) Acceptable Portable Routers 30.70” x 9.84” (780 x 250mm) Main Table Surface 30.86” x 12.20” (784 x 310mm) Sliding Table Surface Table Tilt 0° -45° Table Insets – Outside Ø3.93” (100mm) Table Insets –...
Page 12: Unpacking And Cleaning
UNPACKING AND CLEANING Remove table from the shipping carton. Check for damage and ensure all parts are intact. Any damage should be reported immediately to your distributor and shipping agent. Before assembling, read the manual thoroughly, familiarizing yourself with correct assembly and maintenance procedures and proper safety precautions.
Page 13: Cleaning
Cleaning Your machine may be shipped with a rustproof waxy oil coating and grease on the exposed unpainted metal surfaces. To remove this protective coating, use a degreaser or solvent cleaner. For a more thorough cleaning, some parts will occasionally have to be removed. DO NOT USE acetone or brake cleaner as they may damage painted surfaces.
Page 14: Getting To Know Your Machine
GETTING TO KNOW YOUR MACHINE...
Page 15: Installation
INSTALLATION IMPORTANT: Consider the following when looking for a suitable location to place the machine:  Overall weight of the machine.  Weight of material being processed.  Sizes of material to be processed through the machine.  Space needed for auxiliary stands, work tables, or other machinery. ...
Page 16: Electrical
ELECTRICAL CAUTION: HAVE ELECTRICAL UTILITIES CONNECTED TO MACHINE BY A CERTIFIED ELECTRICIAN! Check if the available power supply is the same as listed on the machine nameplate. WARNING: Make sure the grounding wire (green) is properly connected to avoid electric shock. DO NOT switch the position of the green grounding wire if any electrical plug wires are switched during hookup.
Page 17: Extension Cord Safety
 Use only 3-wire extension cords that have grounding type plugs and receptacles that accept the tool’s plug.  Repair or replace damaged or worn cord immediately. Extension Cord Safety Extension cord should be in good condition and meet the minimum wire gauge requirements listed below: LENGTH AMP RATING...
Page 18: Assembly
ASSEMBLY 1. Assemble the front upper brace and two upper side braces. 2. Assemble the two reinforcing legs. 3. Assemble the lower plate to the four legs and reinforcing legs. 4. Tighten the braces and lower plate by using M8 screws.
Page 19: Install Hold-Downs
INSTALL HOLD-DOWNS 1. Insert the post of the hold-downs into the holes on the dust hood cover. 2. Use an open ended wrench to tighten. INSTALLING THE FENCE 1. After the dust hood has been mounted on the fence, then mount the fence onto the table. 2.
Page 20: Install The Router Onto The Stand
INSTALL THE ROUTER ONTO THE STAND 1. If possible have an assistant help during router installation. 2. Tilt the table to 45° to install the portable router. Lock the table in the tilted position by moving the table tilt lock levers into the lock position. 3.
Page 21: Sliding Table
SLIDING TABLE 1. Use the toggle clamp to fix the workpiece to the sliding table. 2. The push plate position can be set by loosening the push plate lock knobs, adjusting the position, then retightening the knobs. 3. The sliding table can be made stationary by setting the lock tabs on the ends of the sliding table.
Page 22: Routing Operations
ROUTING OPERATIONS CAUTION: Always wear proper eye protection with side shields, safety footwear, dust mask, and leather gloves to protect from splinters. 1. Below are examples of correct routing using the router table. 2. Always feed the workpiece against the rotation of the router cutting bit. 3.
Page 23: Rear Table Routing
REAR TABLE ROUTING 1. When working on small workpieces the sliding table may be unnecessary. The fence assembly can be turned around and refixed to two holes closer to the sliding table. 2. Loosen and remove the two fence lock handles. 3.
Page 24: Parts Diagram
PARTS DIAGRAM...
Page 25: Parts List
Parts List Item Description Fence Half Sliding Screw M6 X 20 Micrometric Adjustment Rod Fence Body Fence Body Guard Micrometric Adjustment Rod Hold-Down Holder Hold-Down L-Bar Knob M8 x 16 Wing Screw M10 x 20 Hex Socket Head Screw M10 x 45 Fence Plate Clamp Holder Dust Hood...
Page 26 Item Description Hex Screw M6 x 20 Washers Washer M6 Hex Screw M6 x 25 Sliding Table Upper Plate Fixed Table Arched Handle Hex Socket Head Screw M6 x 20 Hex Screw M8 x 20 Knob Screw M8 x 30 Frame Slide Way Middle Bracket...
Page 27 Item Description Front Stand (Fitted With Switch) Upper Angle Plate Middle Plate Front Upper Angle Plate Right Bracket Washer M8 Nut M8 Hex Socket Head Screw M8 x 40 Washers Nut M8 Anti-Loose Nut M8 Rubber Leg Screw M8 x 12 Left Bracket Switch (Optional) Switch Box (Optional)
