- Page 1 Icontrol One Link CH-1000 User Guide...
- Page 2 CHAPTER 2 INITIAL INSTALLATION................4 Requirements ........................ 4 Procedure ........................4 APPENDIX A SPECIFICATION ..................5 Icontrol One Link ......................5 Regulatory Approvals....................5 Copyright © 2015. All Rights Reserved. Document Version: 1.1 All trademarks and trade names are the properties of their respective owners.
- Page 3 This Chapter provides an overview of the Icontrol One Link's features and capabilities. Congratulations on the purchase of your new Icontrol One Link. This device is a primary controller and gateway, which includes Wi-Fi and Z-Wave home automation radios, provid- ing connectivity to security systems and devices (including cameras and sensors).
- Page 4 Top-mounted LEDs The Icontrol One Link has four LEDs. • Service On (Green) - The CPE device is activated in iControl network. • Off - The CPE device is not activated in iControl network. • Flashing - The CPE device can not communicated with iControl network.
- Page 5 2. Use a clip to press the Reset button and keep holding for 15 seconds. 3. Release the Reset Button. The Icontrol One Link is now using the factory default values. Use standard LAN cable (RJ45 connector) to connect your router to the ETHERNET port.
- Page 6 1. Choose an Installation Site Select a suitable place to install the Icontrol One Link. 2. Connect LAN Cable Use standard LAN cable to connect the router and the Ethernet port on the Icontrol One Link. 4. Power Up Plug the Icontrol One Link into an outlet or extension cord.
- Page 7 Appendix A Specification Icontrol One Link Model CH-1000 Dimensions 97mm(W) * 60mm(D) * 40mm(H) (without plug) Operating Temperature 0° C to 40° C Storage Temperature -20° C to 70° C Network Protocol TCP/IP Network Interface 1 * 10/100BaseT (RJ45) WAN Port...
- Page 8 FCC Radiation Exposure Statement This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause...
