Summary of Contents for X2 X2-9891N1-PWM
- Page 1 Installation Manual ECLIPSE ADV ANCED P E R F O R M A N C E C P U C O O L E R...
- Page 2 2. INCLUDED PARTS 1. INTRODUCTION The Eclipse Advanced, item number: X2-9891N1-PWM, universal CPU cooler is ideally suited for those who require more performance and reliability than would be encountered in a generic cooler. One of the amenities of this unique CPU cooler is the fact that its rather universal build which enables it to be compatible with all processors such as the AMD, AM2, AM3, AM3+, FM1, FM2 and the Intel LGA775/i3/i5/i7 and LGA2011 models.
- Page 3 INSTALLATION MANUAL INSTALLATION MANUAL 3. Installation guide for AMD 3. Installation guide for Intel (except LGA 2011) STEP 1 STEP 1 Remove the fan(s) from the CPU cooler before installation. Remove the fan(s) from the CPU cooler before installation. AM2/AM3 STEP 2 STEP 2 Place the screw stem...
- Page 4 STEP 1 Before installation, please verify that your CPU platform is indeed Under normal operation, X2 provides 24 months warranty from the date of purchase. If you have socket 2011. Remove the fan(s) from the CPU cooler before installation. any technical problems, please contact your local vendor or contact us, preferably by e-mail.
Need help?
Do you have a question about the X2-9891N1-PWM and is the answer not in the manual?
Questions and answers
installation
To install the X2-9891N1-PWM CPU cooler:
1. Remove the fan(s) from the CPU cooler before starting installation.
2. Backplate Setup (for AMD and Intel except LGA 2011):
- Insert screw stems C through the correct holes in backplate A.
- Fasten them with nuts F.
- Add the screw pads (H for AMD, I for Intel).
3. AMD Installation:
- Fasten AMD retention bars N to the heatsink using screws G.
- Insert the screw stems from the back of the motherboard through the mounting holes.
4. Intel Installation (except LGA 2011):
- Insert the screw stems from the backplate through the motherboard.
- Continue with standard mounting steps.
5. Intel LGA 2011 Installation:
- Place the heatsink onto the CPU.
- Insert screw stems K into the heatsink bracket.
- Fasten Socket 2011 screws L onto stem K and tighten securely but not too tightly.
6. Final Steps:
- Reattach the fan(s) to the heatsink.
- Connect both fans to the Y-splitter cable P.
- Plug the splitter into the CPU cooler fan header on the motherboard.
Note: Use only a small amount of the supplied thermal grease. Using too much can reduce cooling performance.
