Operating Instructions

STAMA Micro, Parker, Mini, Multi,

Evo, Maxi EL

Registration of Use ............................................................. 3

EU declaration of conformity .............................................. 5

General information ............................................................ 6

Safety requirements ........................................................... 7

Operating ............................................................................ 9

Maintenance ..................................................................... 10

Lead-acid batteries ............................................................11

Lithium-ion batteries ......................................................... 18

Marking/labelling............................................................... 23

Customer services and claims.......................................... 24

Table of Contents

Need help?

Do you have a question about the STAMA Micro and is the answer not in the manual?

Questions and answers

Summary of Contents for GMR STAMA Micro

Page 1: Table Of Contents
Operating Instructions STAMA Micro, Parker, Mini, Multi, Evo, Maxi EL Registration of Use ............. 3 EU declaration of conformity ..........5 General information ............6 Safety requirements ............7 Operating ................9 Maintenance ..............10 Lead-acid batteries ............11 Lithium-ion batteries ............18 Marking/labelling...............
Page 3: Registration Of Use
Compensation will not be given for consequential damage or wearing parts. A condition for the processing of claims is that this registration for use is submitted to GMR maskiner a/s no later than 1 month after delivery to the user.
Page 5: Eu Declaration Of Conformity
Operating Instructions STAMA Micro, Parker, Mini, Multi, Evo, Maxi EL EU declaration of conformity EU declaration of conformity Manufacturer: GMR maskiner a/s Saturnvej 17, 8700 Horsens, Denmark Tel.: +45 7564 3611 hereby declares that machine: STAMA machine no.: date: is in conformity with the applicable requirements of:...
Page 6: General Information
Operating Instructions STAMA Micro, Parker, Mini, Multi, Evo, Maxi EL General information General comments Please read the Operating Instructions before you start to use your new STAMA truck. If you are in any doubt, contact the dealer. Use only original STAMA parts in your electric truck. To order original parts, contact your dealer or GMR maskiner a/s directly.
Page 7: Safety Requirements
Operating Instructions STAMA Micro, Parker, Mini, Multi, Evo, Maxi EL Safety requirements Acceleration The truck starts smoothly and continues to accelerate until it reaches maximum speed. Maximum speed Micro 12 km/h Parker and Mini 15 km/h Mini 15 km/h Multi and Evo...
Page 8 Operating Instructions STAMA Micro, Parker, Mini, Multi, Evo, Maxi EL Safety requirements Speed, slopes and in- The truck speed should be adapted to the conditions, i.e. reduce clines speed at corners and in narrow passages. There is a risk that the truck may overturn when travelling on an incline.
Page 9: Operating
Operating Instructions STAMA Micro, Parker, Mini, Multi, Evo, Maxi EL Operating Preparation Pre-start inspection Before starting, check that: • The battery is fully charged • The battery electrolyte density is correct • The battery is clean • There is no battery error or operating fault Pre-start inspection Turn the main switch.
Page 10: Maintenance
Then switch the ignition switch to OFF and restart. If there is an alarm code in the display all the time, you must contact an authorised workshop. For a full list of error codes in English, contact GMR maskiner. Hydraulic system The hydraulic system is generally maintenance-free. However, you should replace hydraulic fluid once a year or after 500 operating hours.
Page 11: Lead-Acid Batteries
Operating Instructions STAMA Micro, Parker, Mini, Multi, Evo, Maxi EL Lead-acid batteries Lead batteries WARNING Risk of personal injury/death The charging of lead-acid batteries can be hazardous, due to the formation of explosive hydrogen gas. WARNING Risk of personal injury/death Flames and sparks are not permitted in the vicinity of the battery.
Page 12 Operating Instructions STAMA Micro, Parker, Mini, Multi, Evo, Maxi EL Lead-acid batteries Function Depending on type and production year, your truck will have one of two different types of battery charger. SMC-HF 600/800 Curtis 1621 Recharging • Connect the battery. Switch on the mains supply. The POWER ON diode is lit when the unit is charging.
Page 13 Operating Instructions STAMA Micro, Parker, Mini, Multi, Evo, Maxi EL Normal operation Before charging Drive the machine close to the charger. The charger and battery connectors must be within easy reach of each other. Turn ignition switch to 0. Cut the power.
Page 14 Operating Instructions STAMA Micro, Parker, Mini, Multi, Evo, Maxi EL Normal operation After charging Check that the charger has fully charged the battery. The Green lamp is lit. Power down the charger or press the pause button. Disconnect the charger connector from the battery connector.
Page 15 Operating Instructions STAMA Micro, Parker, Mini, Multi, Evo, Maxi EL Lead-acid batteries Manual top-up COMMENT: NEVER add acid to the battery, only battery fluid. with battery fluid Do not store battery fluid in a metal container. To top up, use equipment made of plastic or other non-conductive material, which can also withstand contact with water and acid.
Page 16 Operating Instructions STAMA Micro, Parker, Mini, Multi, Evo, Maxi EL Normal operation Automatic top-up with a The battery filling system (BFS) caps work best when water pressure is BFS and water caniste 0.3-2.0 bar, which corresponds to water column pressure when pouring from a height of 3-20 metres.
Page 17: Operating Instructions Stama Micro, Parker, Mini, Multi, Evo, Maxi El
Operating Instructions STAMA Micro, Parker, Mini, Multi, Evo, Maxi EL Normal operation Position the canister at the correct height and check the BFS system regularly. If you do not, your battery may get damaged. The battery manufactur- For further information about the different types of batteries, er's guarantee provisions click: http://www.gnb-nordic.com/anden-info/garanti/motive/...
Page 18: Lithium-Ion Batteries
Operating Instructions STAMA Micro, Parker, Mini, Multi, Evo, Maxi EL Lithium batteries The battery pack The lithium battery pack contains a number of individual LFP cells. The (LFP = Lithium Ferro pack has a nominal voltage of about 3.3 V per cell. This is the safest phosphate) type of lithium battery on the market.
Page 19 Operating Instructions STAMA Micro, Parker, Mini, Multi, Evo, Maxi EL Lithium batteries Battery management The lithium-ion battery pack is fitted with BMS, a system which monitors system the voltage in each individual battery cell. A combined battery sensor/ BMS = Battery Management balancing unit is fitted to the top of each cell.
Page 20 Operating Instructions STAMA Micro, Parker, Mini, Multi, Evo, Maxi EL Lithium batteries MCU diode lamps There are two diode lamps on the MCU: The green diode lamp indicates that there is a 12 V supply to the PCB. The red diode lamp indicates that the monitoring circuit is broken, i.e.
Page 21 Operating Instructions STAMA Micro, Parker, Mini, Multi, Evo, Maxi EL Lithium batteries Lithium-ion battery charger The battery charger charges all the batteries serially and simultaneously to a charge voltage of 3.65 V per cell. The charger charges constantly until the desired voltage level is achieved. Then the charge voltage is reduced until full starting voltage is achieved.
Page 22 Operating Instructions STAMA Micro, Parker, Mini, Multi, Evo, Maxi EL Lithium batteries Battery indicator Like an electricity meter, the battery indicator measures power entering and leaving the lithium-ion battery. The battery indicator also calculates power reserves. The indicator is always connected to the battery –...
Page 23: Marking/Labelling
Operating Instructions STAMA Micro, Parker, Mini, Multi, Evo, Maxi EL Marking/labelling The truck is marked with various labels and signs. These must remain on the truck at all times. If labels and signs are damaged or obscured by paint, they must be replaced.
Page 24: Customer Services And Claims
GMR maskiner a/s reserves the right to assign a claim of this kind to the relevant supplier and not to reach a decision until the relevant supplier has responded.
Page 25 Complete a complaint report, stating the machine type, production number and date of its delivery to the customer, and send it to us. This is done via the dealer login on our website www.gmr.dk. If questions arise about claims on imported machines, we reserve the right to present the claim to the manufacturer before making any decision about whether the claim can be accepted.
