INTRODUCTION
The ATD3698 features a long life heated sensor technology that is
designed to detect the more current and difficult HFC refrigerants
such as R-134a in addition to all HCFC (R22) and CFC (R12)
refrigerants including SNAP approved hydrocarbon blends. The
ATD3698 does not require rechargeable batteries.
• Unique numeric leak size
Indicator
• R134a sensitivity .05 oz/yr
• Designed certified SAE 2791
standard
• Low battery indicator
• 2- year warranty including 2
years for the sensor
• Uses 4 AA alkaline batteries • CE Certified
• Made in USA
FEATURES
• Long life, stable sensor
• R22 sensitivity .025 oz/yr
• Automatic calibration and
reset to ambient
• 3 adjustable sensitivity levels
• True mechanical pump
1
Replacement Parts
Item
Sensor with Filter
Filter Kit
Test Vial
Product Specifications
Model #
Name
Sensitivity
Sensor Life
Response Time
Power Supply
Battery Life
Warm up time
Probe length
Weight, lbs
Warranty
Part Number
PRT3700-01
PRT3700-02
PRT3700-03
ATD3698
Leak Detector, Refrigerant
Gas
.05 oz/yr R134a
.025 oz/yr R22
> 300 hours
Instantaneous
4 AA Alkaline batteries
8 hours continuous
< 20 seconds
17 inches
1.5 lbs
2 years (2 yrs for sensor)
