Leaf Blower Vac
Please read and retain these instructions for future reference
OPERATING CONTROLS
Fig. 1
Page No. 1
Instructions for Use
9242
1. Wheel
2. Blower/Suction tube
3. Blower/Vacuum body
4. Auxiliary handle
5. Hole for belt hook
6. Shoulder belt
7. Switch trigger
8. Vacuum/Blower selector lever
9. Collection Bag
CONTENTS
Leaf blower body (1 set)
tube (2pcs)
collection bag (1pc)
shoulder belt (1pc)
short special screw ST4x14 (1pc)
longer screw ST4 x 50 ( 2pcs)
