Summary of Contents for Digger Specialities Turning Point
- Page 1 Installation and Operators Manual...
-
Page 3: Table Of Contents
Table of Contents Safety Considerations................4-5 Installation Instructions ............... 6-13 Tools Needed ..................6 Pre Installed Considerations ............6 Gate Installation Instructions ........... 6-8 Control Box Installation Instructions ........9-10 Control Box Wiring & Terminal Functions ........10-1 1 Features & Adjustments ..............12-13 Trouble Shooting and Maintenance ..........14-15 P.O. - Page 4 Turning Point Gates Safety Considerations Safety Considerations Important Safety Information Digger Specialties Inc. cannot over emphasize the need for safety when installing and using power gate systems. It is of the utmost importance that the installer and owner/operator follow all installation and usage instructions.
-
Page 5: Safety Considerations
Turning Point Gates Safety Considerations Safety Considerations Gate Does NOT need Gate Needs Entrapment Entrapment Protection Protection Fence, Building or other Stationary Object Fence, Building or other Stationary Object 16” or more when fully open Less than 16” when fully open... -
Page 6: Installation Instructions
Follow all local codes and angle Bottom bracket ordinances when positioning the Turning Point gates. Bracket Gates that are to have a magnetic or power bolt lock system should have the wires routed in the gate to the... - Page 7 Turning Point Gates Gate Installation Instructions Gate Installation Instructions Place the nylon “C” washer onto the top pin power source and reverse the of the gate. And then place the top hinge positive and negative wires and let onto the pin. The top hinge bracket should the gate move until it stops.
-
Page 8: Gate Installation Instructions
Turning Point Gates Turning Point Gates Gate Installation Instructions Gate Installation Instructions Gate Installation Instructions Turning Point Gates Gate Installation Instructions Adjustment Bolt Adjustment (Counter Bolt (Counter Clockwise Clockwise raises outer raises outer edge of Gate) edge of Gate) Adjustment... -
Page 9: Control Box Installation Instructions
(If the remote does not function see section E “Trouble Shooting”). Turning Point gates are a low voltage (12- If the gates do not move, allow 10 volt) system. This minimizes the risk of seconds and press the button electric shock. -
Page 10: Control Box Wiring & Terminal Functions
Turning Point Gates Gate Installation Instructions Gate Installation Instructions press the button again. Both gates CSF (Contact Strip Front of Gate) will move together – Input for contact safety edge Sensitivity adjustment (via potentiometers installed on front of gate. can be made to increase or decrease the... - Page 11 Turning Point Gates Gate Installation Instructions Gate Installation Instructions so will damage the circuit board 5, 7, and 9 are open and 2, 4, 6, 8, and 10 are and render your warranty void. closed (see figure E3). Synchronizing is critical ALARM –...
-
Page 12: Features & Adjustments
Turning Point Gates Gate Installation Instructions Gate Installation Instructions D. Features and Adjustments Low voltage (12-volt) lights can be wired Dipswitches can be adjusted to make some into the control panel. There is a terminal additional functionality. Switching the marked for lights. The lights will turn on dipswitches should be done with a sharp when the system is activated. -
Page 13: Installation Instructions
Turning Point Gates Gate Installation Instructions Gate Installation Instructions Protect wires from sharp edges with grommets or other means of Magnetic Lock Installation (600 lb. Force) secure protection. Find the position that you want the Exception -- On a single gate locks to be on the gate. -
Page 14: Trouble Shooting And Maintenance
Turning Point Gates Turning Point Gates Trouble Shooting and Maintenance Trouble Shooting and Maintenance Trouble Shooting and Maintenance E. Trouble Shooting E. Trouble Shooting Symptom Possible Cause Remedies Symptom Possible Cause Remedies Gate opens correctly but 1.Excessive closing pressure. Gate may be 1.Loosen the bottom gate hinge collar and... -
Page 15: P.o. Box
IMPORTANT With your signature, it is stating that you have received a copy of the Operators Manual for the Turning Point Gate Opener. It also signifies that you have read and followed the installation and operating instructions, paying close attention to the red highlighted areas. Approve with this signature, date, detach and fax this portion of your Operators Manual to 574-546-5099. -
Page 16: Limited Warranty
Replacement parts are warranted for the remaining portion of the original warranty period. The manufacturer will pay standard ground freight on the return of repaired or replaced items in warranty. THE WARRANTY STATEMENTS CONTAINED IN THIS LIMITED WARRANTY EXTENDED BY DIGGER SPECIALTIES, INC. FOR ITS TURNING POINT GATE OPENERS, AND THE PROVISIONS OF THIS WARRANTY SHALL CONSTITUTE THE ENTIRE LIABILITY OF DIGGER SPECIALTIES, INC. -
Page 17: Bremen, In
Please cut out postcard and return -------------------------------------------------------------------------------------------------------------------------------- (1) ONE YEAR LIMITED WARRANTY REGISTRATION AND VALIDATION LIFETIME LIMITED WARRANTY REGISTRATION & VALIDATION IMPORTANT! IMPORTANT! Please complete information and mail within 10 days to register your warranty. FILL OUT Name:__________________________ Distributor/Dealer:_____________________________ AND MAIL Please fill out both Address:_________________________ City:_________________________State:_____________... - Page 18 P.O. Box 241 Bremen, IN 46506 Phone 574-546-5999 Fax 574-546-5099 www.turningpointgateopeners.com Place Stamp Here Digger Specialities, Inc. P.O. Box 241 Bremen, IN 46506...
