1.0
MINIPCI WIRELESS LAN CARD
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GMIWLGRL2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Billionton GMIWLGRL2

  • Page 1 MINIPCI WIRELESS LAN CARD User’s Manual...

  • Page 2: Federal Communication Commission Interference Statement

    Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 3: Industry Canada Statement

    Industry Canada Statement Operation is subject to the following two conditions: 1) This device may not cause interference and 2) This device must accept any interference, including interference that may cause undesired operation of the device This device has been designed to operate with an antenna having a maximum gain of 2.58 dBi.

  • Page 4: Table Of Contents

    Index Introduction C H A P T E R 1 Specifications C H A P T E R 2 Hardware Installation C H A P T E R 3 Setup for Windows 98/2000/ME/XP C H A P T E R 4 Troubleshooting...

  • Page 5: Introduction

    Introduction Thank you for purchasing this miniPCI Wireless LAN Card. This card is a wireless network client that complies with IEEE 802.11b/g standard on wireless LANs. The IEEE 802.11b/g standards compliance means this adapter gives you the flexibility to connect it to any 802.11g network. The IEEE 802.11b/g standard allows you to connect computers and devices at speeds up to 54Mbps, dependent upon the distance between wireless adapters, the configuration of your working environment, or the capabilities or limitations of your computer systems.

  • Page 6: Specifications

    Specifications Features - Compatible with IEEE 802.11b/g Standard - 2.4GHz spread specturm technology - 54Mbps high speed transfer rate and backward compatible with 802.11b - Support antenna diversity - Support 64/128-bit WEP Data Encryption function for high level of security - Support WPA and AES advanced WLAN Security.
  • Page 7 @ PER <0.08 ,54Mbps < -70dBm(typical) - Security : 64/128-bit WEP Encryption 64/128-bit TKIP Data Encryption 64/128-bit AES Data Encryption - Channels Support US/Canada: 11 (1 ~ 11) Major European country: 13 (1 ~ 13) France: 4 (10 ~ 13) Japan: 14 (1~13 or 14th) Environmental Operating Ranges - Operating Temperature: 0 ~70°...

  • Page 8: Hardware Installation

    Hardware Installation Module is installed in the Personal Computer, located either under the keypad or on the bottom side of the Personal Computer (see the following diagrams). Antennas are embedded in the top corners of the panel (see the two circles shown below )

  • Page 9: Setup For Windows 98/2000/Me/Xp

    Setup for Windows 98/2000/ME/XP 1. Insert the CD into the CD-ROM device and execute the "setup.exe" program. The InstallShield Wizard box will appear, click "Next" to continue. 2. Follow the instruction of the installation program. The program will install the software for this device directly.
  • Page 10 3. Click "Finish" to complete the installation. 4. When the Utility installation is completed, a new icon will display in the system tray...
  • Page 11 at the bottom of the screen. Double click the shortcut or the icon to start using the miniPCI Wireless LAN Card. In the system tray Windows XP Due to Windows XP has built-in wireless network utility you may decide to use the system’s utility or the one provided by this adapter.
  • Page 12 2. On the “Wireless Networks“ tab in the “Wireless Network Connection Properties“ screen, clear the “Use Windows to configure my wireless network settings“ check box. If you want to enable the Windows XP built-in utility, select the check box again. 3.
  • Page 13 Wireless LAN Card. Note: If you don’t disable the XP’s Utility, you can still see the link status and statistics during communication process from the adapter’s utility.

  • Page 14: Configuration Utility

    Configuration Utility The Configuration Utility is a powerful application that helps you configure the miniPCI Wireless LAN Card and monitor the link status and the statistics during the communication process. This utility can be used to change the following configuration parameters when the device is active.
  • Page 15 mode setting (64-bit or 128-bit) of the network. Confirm Network Key Enter the same network key again to confirm the key. Advanced Button To configure additional wireless network setting, review the link status and statistics or if you have difficulty connecting to a network, click “Advanced“ button. Connect Button Click the button to connect to the selected network.
  • Page 16 2. Configuration This screen is for you to make advanced settings in order to connect to an available network or create a new wireless network connection. You could also define the connection order here. Profile: This list shows the preferred networks for the wireless connection. You can add, remove, edit the preferred networks or set one of the networks as the default connection.
  • Page 17 Network Name (SSID) The SSID (up to 32 printable ASCII characters) is the unique name identified in a WLAN. The ID prevents the unintentional merging of two co-located WLANs. Only the wireless devices with the same SSID can interconnect. Delete Button To remove a wireless network from the available profiles list, click the “Delet”...
  • Page 18 Link Status: Signal Strength This bar shows the signal strength level. The higher percentage shown in the bar, the more radio signal been received by the adapter. This indicator helps to find the proper position of the wireless device for quality network operation. Signal Quality This bar indicates the quality of the link.
  • Page 19 Site Survey: It will show all available wireless Network(s) within range of your computer. You can double click the network listed in the table to make further configurations. Configure Button If you are unable to connect to an existing wireless network, click the network name and then click this button.
  • Page 20 Statistics You can get the real time information about the packet transmission and receiving status during wireless communication from the screen. If you want to recount the statistics value, please click “Reset Counter“ button.
  • Page 21 Advance This screen allows you to do some advanced configuration and some specific settings for the adapter. Ad Hoc wireless mode Select the number of the radio channel used for the Ad Hoc networking. The channel of all the wireless stations in the Ad Hoc network should be the same. The parameter is not active in the infrastructure operation mode.
  • Page 22 About This screen displays the version and the designer of the Utility.

  • Page 23: Troubleshooting

    Troubleshooting This chapter provides solutions to problems usually encountered during the installation and operation of the adapter. 1. What is the IEEE 802.11g standard？ The IEEE 802.11g Wireless LAN standard subcommittee which formulates the standard for the industry. The objective is to enable wireless LAN hardware from different manufactures to communicate.
  • Page 24 A specific Ad hoc LAN is called a Basic Service Set (BSS). Computers in a BSS must be configured with the same BSS ID. 6. What is WEP？ WEP is Wired Equivalent Privacy, a data privacy mechanism based on a 40 bit shared key algorithm, as described in the IEEE 802 .11 standard.
  • Page 25 10. Can Wireless products support printer sharing？ Wireless products perform the same function as LAN products. Therefore, Wireless products can work with Netware, Windows 2000, or other LAN operating systems to support printer or file sharing. 11. Would the information be intercepted while transmitting on air？ WLAN features two-fold protection in security.
  • Page 26 13. What is Spread Spectrum？ Spread Spectrum technology is a wideband radio frequency technique developed by the military for use in reliable, secure, mission-critical communication systems. It is designed to trade off bandwidth efficiency for reliability, integrity, and security. In other words, more bandwidth is consumed than in the case of narrowband transmission, but the trade off produces a signal that is, in effect, louder and thus easier to detect, provided that the receiver knows the parameters of the...
