ATEK TECHNOLOGY CO., LTD
2.4GMOUSE USER MANUAL(v4.0)

Product Overview

1. Compatible with USB1.1/2.0 specifications,supporting USB-IF and WHQL testing
2. 16 channel frequency hopping and Strong anti-jamming capability
3. supports two kinds of online mode ( buttons online PC software online )
4. Support of sensor type
PixArt : 3204 / 3204LL/3204UL / 3205 ( total plate)
Avago : 5030/ 5090 / A3000 ( Total board )
( 4 kinds of directions support Sensor )
5. Up to six function keys (left , right , and forward and backward , DPI selection )
6. Supports computer hibernation wake up and wake from hibernation
7. Wireless remote control distance greater than 10 meters
8. Support battery low alarm
9. Peripheral simple free Taozhen
10. Intelligent multi - level power-saving design : put stop immediately goes into sleep mode ,
put stop the mouse LED lights turn off after 30 minutes ; unplug the receiver , or turn off the PC ,
LED lights turn off automatically ; LED is off , the button or scroll wheel to wake up (if wake
button , the button does not move for the first time )
11. semi-finished production testing of code - free ; finished the code is simple and convenient
right button to enter the code mode ( short press the left + + ) ; never swap code
12. MCU support
( A3000/3204LL/3204UL/3205 ) , dual battery boost circuit can not use
Description of the code
1.: Hardware on the code
Press the " left " + " in " + " right" three-button 1S, mouse enter into code mode (low
pressure indicator light long ) 10S insert receiver . Success of the code , the
low-voltage lights immediately after the failure of the code , the the mouse exit code
mode , low-voltage lights go out , extinguished ; within the 10S Sensor of LED lights
2. : BINDING SOFTWARE
Open code software , insert the receiver to the USB port , automatically enter code
mode , short 10 seconds left, center, right , three-button mouse to enter the code
mode , if the success of the code , the code button is displayed as (mouse on success
of the code )
( In terms of the code key for 10 seconds , the mouse unsuccessful code will
automatically exit the code , while off SENSOR LED )
low voltage operation
2.4G wireless mouse ver4.0
against the Low Voltage sensor
