  • Page 1 CT-Router LAN...

  • Page 2: Copyright © Comtime Gmbh

    CT-Router LAN Copyright © comtime GmbH Copyright Statement The contents of this publication are protected by copyright. Translations, reprints, reproduction and storage in data processing systems require the express permission of comtime GmbH. © 2011 comtime GmbH All rights reserved.

  • Page 3: Table Of Contents

    CT-Router LAN Content Copyright © comtime GmbH .......................... 2 Technical data ..............................5 Hardware installation ............................6 LED indicators ............................... 7 Configuration WBM ............................8 Device information ............................9 Hardware ............................... 9 Software ............................... 10 Status ................................11 Network Connections........................... 11 I/O status ..............................
  • Page 4 CT-Router LAN Content I/O ..................................44 Inputs ................................44 Outputs ................................ 45 Socket Server .............................. 46 System ................................47 Web configuration ............................47 User ................................48 Log configuration ............................49 Log file ................................. 50 ComSERVER - Serielle Schnittstelle konfigurieren (optional)..............51 SMTP Configuration ............................

  • Page 5: Technical Data

    CT-Router LAN Technical data Supply 10 V DC ... 30 V DC via plugable screw terminals Supply voltage Nominal current consumption < 90mA at 24V Power (LED green) Continuous light: Operation LED display Protocols / Interfaces DHCP-Server, HTTP-Server, FTP, NAT, Firewall, SMS, OpenVPN, IPSec,...

  • Page 6: Hardware Installation

    CT-Router LAN Hardware installation Terminal assignment Ethernet 1 Ethernet 2 Supply voltage 10V - 30V DC Digital output Digital input I4I I4...

  • Page 7: Led Indicators

    CT-Router LAN Hardware installation LED indicators Reset Power Packet Data LED Router HSPA Explanation Off = no connection Package Data Flashing = modem connection On = package data connection Off = no VPN connection On = VPN connection activated Off = no power supply...

  • Page 8: Configuration Wbm

    CT-Router LAN Configuration WBM The configuration of the CT-Router is performed via a Web browser based function. To do so, first fulfil the following conditions:  The PC which is used for the configuration of the router is equipped with a LAN interface.

  • Page 9: Device Information

    CT-Router LAN Device information In this area you can see more detailed information about the built-in hardware as well as about the installed software. Hardware Here you will find a tabular overview of the built-in hardware.

  • Page 10: Software

    CT-Router LAN Device information Software Here you will find a tabular overview of the software installed on the CT-Router.

  • Page 11: Status

    CT-Router LAN Status In this menu all current status information about the the network connections are displayed. Network Connections Status  Network connections Network conncetions Explanation Wireless Network TCP/IP connected: TCP/IP connection established in the mobile phone network. Link VPN connected: VPN connection established in the mobile phone network...

  • Page 12: I/O Status

    CT-Router LAN Status I/O status Here you will find an overview in tabular form of all current input and output settings.

  • Page 13: Comserver - Status (Optional)

    CT-Router LAN Status ComSERVER – status (optional) Status ComSERVER ComSERVER Explanation Link TCP Remote Baud Rate Data bits The status of the ComServer connection (serial) is displayed: Parity Stop bits Flow control...

  • Page 14: Routing Table

    CT-Router LAN Status Routing table Status Routing table Routing Table Explanation Includes among others information about the target gateway to the subnet mask and metrics.

  • Page 15: Dhcp Leases

    CT-Router LAN Status DHCP Leases Status DHCP leases DHCP Leases Explanation Here you will find an overview in tabular form of all DHCP data assigned by the AK-DinRail-3G-Router. Host name Host name of the terminal in the network. Client MAC address MAC address of the terminal in the network.

  • Page 16: Local Network

    CT-Router LAN Local network In the menu "Local network" you can set the local network settings for the CT-Router. IP configuration Local network  IP configuration IP configuration Explanation Current address IP Address Current IP address of the router Subnet mask...

  • Page 17: Dhcp Server

    CT-Router LAN Local network DHCP server Local network  DHCP server DHCP server Explanation DHCP server Deactivated / Activated Domain name Enter Domain name which is distributed via DHCP. Lease time (d,h,m,s) Period of time during which the network configurations are valid.

  • Page 18: Static Routes

    CT-Router LAN Local network Static routes Local network  Static routes Static routes Explanation Network Network in CIDR form Gateway Gateway address of the network Max. 8 networks can be entered.

  • Page 19: Wide Area Network

    CT-Router LAN Wide Area Network Wireless network Wireless network Determine the settings for the use of CT-Router in the “Wide Area Network ” menu. WAN Setup Wide Area Networks WAN Setup Explanation Connection Type Select the connection in the "Connection Type" menu and set it to Enable "Yes".

  • Page 20: Static Address

    CT-Router LAN Wide Area Network Static Address Setting for use in local area networks Wide Area Networks WAN Setup Explanation IP Address IP address of the router on the WAN interface Subnet Mask subnet mask Default Gateway IP address of the gateway to the Internet...

  • Page 21: Dhcp Client

    CT-Router LAN Wide Area Network DHCP Client Einstellung für den Betrieb mit Kabelmodems Soll dem Router aus dem Netzwerk automatisch eine IP-Adresse zugewiesen werden setzen Sie den „Connection Type“ auf „DHCP Client“ und bestätigen mit „Apply“. Wenn Sie die IP-Adressen des DNS-Servers manuell einstellen wollen setzen Sie unter „Manual DNS“...

  • Page 22: Pppoe

    CT-Router LAN Wide Area Network PPPoE Einstellung für den Betrieb mit DSL-Modems Bei einen Betrieb an einem (DSL-)Modem wählen Sie unter „Connection Type“ die Einstellung „PPPoE“ und mit „Apply“ bestätigen Wide Area Networks WAN Setup Erklärung Username Username für den Zugang zum Netz Password Password für den Zugang zum Netz...

  • Page 23: Static Routes

    CT-Router LAN Wide Area Network Static routes Wireless network  Static routes Static routes Explanation Network Network in CIDR form Gateway Gateway address of the network Max. 8 networks can be entered.

  • Page 24: Dyndns

    CT-Router LAN Wide Area Network DynDNS Wireless network  DynDNS DynDNS Explanation DynDNS Disable: Deactivating the DynDNS Enable: Activating the DynDNS DynDNS provider Selection of the DynDNS provider DynDNS username User name of the DynDNS account DynDNS password Password of the DynDNS account...

  • Page 25: Connection Check

    CT-Router LAN Wide Area Network Connection Check Wireless network  Connection check Connection check Explanation Connection check Disable: Deactivating the connection check of the package data connection Enable: Activating the connection check of the package data connection Host #1…#3 IP address or host name as reference point for the connection check Local: Activating for addresses which are available via a VPN tunnel.

  • Page 26: Network Security

    CT-Router LAN Network security Perform the settings for network security in the menu "Network security". General setup Network security  General setup General setup Explanation Disable Deactivating the integrated stateful package inspection Firewall Firewall Enable: Activating the integrated stateful package inspection Firewall...

  • Page 27: Firewall

    CT-Router LAN Network security Firewall Network security  Firewall Firewall Explanation Incoming traffic Protocol Protocol selection: TCP, UDP, ICMP, all From IP / To IP IP address range in CIDR form (0.0.0.0/0 means all IP addresses) From Port / To Port Port range ("any"...

  • Page 28: Nat Table

    CT-Router LAN Network security NAT Table Network scurity NAT table Firewall Explanation Protocol Protocol selection: TCP, UDP, ICMP, all In Port / To Port Port range ("any" means all ports) To IP IP address range in CIDR form (0.0.0.0/0 means all IP addresses)

  • Page 29: Vpn

    CT-Router LAN In the menu OpenVPN you can perform on the one hand settings for the Internet protocol security (IPsec) on the other hand for virtual private network (VPN). For a VPN connection, the IP addresses of the VPN remote sites must be known and addressable.

  • Page 30: Connections Settings

    CT-Router LAN VPN-IPsec Connections settings VPN  IPsec  Connections  Settings  Edit Settings Explanation Name Name of the VPN connection Activating (=Enable) or deactivating (=Disable) of the VPN connection Remote host IP address / URL of the remote station Can only be set if "Initiate"...
  • Page 31 CT-Router LAN VPN-IPsec Empty: No entry in this row means that the indications are selected from Remote ID the certificate. Subject: IP address, E-mail address or host name mean that these entries should also be available in the certificate in order that it is possible to authenticate the router.

  • Page 32: Connection Ike

    CT-Router LAN VPN-IPsec Connection IKE VPN  IPsec  Connections  IKE  Edit Explanation Name Name of the VPN connection. Phase 1 ISAKMP SA Key exchange ISAKMP SA Encryption Choice of encryption algorithm ISAKMP SA Hash Choice of hash algorithm ISAKMP SA Lifetime Lifetime of the ISAKMP SA key.
  • Page 33 CT-Router LAN VPN-IPsec Ipsec SA Encryption see ISAKMP SA Encryption Ipsec SA Hash see ISAKMP SA Hash Lifetime of the Ipsec SA key. Standard setting 28800 seconds (8 hours) Ipsec Lifetime max. setting value 86400 seconds (24 hours) Perfect Forward Secrecy Activating (=Yes) or deactivating (=No) the PFS function.

  • Page 34: Certificates

    CT-Router LAN VPN-IPsec Certificates VPN  IPsec  Certificates Certificates Explanation Load remote certificate Uploading of certificates which allow to perform an authentication for the router at the VPN remote station. Load Own PKCS#12 Uploading a certificate (pre-setting of the provider)

  • Page 35: Status

    CT-Router LAN VPN-IPsec Status VPN  IPsec  Status Status Explanation Name Name of the VPN connection Remote host IP address or URL of the remote station ISAKMP SA Activated (green field) IPSec SA Activated (green field)

  • Page 36: Tunnel

    CT-Router LAN VPN - OpenVPN Tunnel VPN  OpenVPN  Tunnel OpenVPN tunnel Explanation OpenVPN Tunnel activated (=Enable) or inactivated (=Disable) Name Name of the OpenVPN connection Remote host IP address or URL of the remote station Remote pPort Port of the remote station (Standard: 1194)
  • Page 37 CT-Router LAN VPN - OpenVPN Allow remote float Option: For the communication with dynamic IP addresses the OpenVPN connection accepts authenticated packages of any IP address. Local port Local port Determine type of authentication of the OpenVPN connection (X.509 or...

  • Page 38: Server

    CT-Router LAN VPN - OpenVPN Server VPN  OpenVPN  Tunnel OpenVPN tunnel Explanation OpenVPN Tunnel activated (=Enable) or inactivated (=Disable) Name Name of the OpenVPN connection Local Port Port of the local station (Standard: 1194) Protocol Determine UDP or TCP protocol for the OpenVPN connection!
  • Page 39 CT-Router LAN VPN - OpenVPN Local certifacation Certificate of the router for the authentication at the remote station. Diffie-Hellman Parameter Encryption Encryption algorithm of the OpenVPN connection Client to Client Traffic Client Subnet Base IP address/subnet mask of the local network...

  • Page 40: Port Forwarding

    CT-Router LAN Port Forwarding VPN  OpenVPN  Port Forwarding Port forwarding Explanation Protocol Selection:TCP / UDP / ICMP In port Port no. incoming connection To IP IP address of target To port Port no. from target...

  • Page 41: Certificates

    CT-Router LAN VPN - OpenVPN Certificates VPN  OpenVPN  Certificates OpenVPN certificates Explanation Load Own PKCS#12 Uploading a certificate which is originated from your provider. certificate Password Password for the PKCS#12 certificate. The password is assigned during export. Own certificates Here you will find an overview in tabular form of all "Own certificates"...

  • Page 42: Static Keys

    CT-Router LAN VPN - OpenVPN Static keys VPN  OpenVPN  Static keys Static keys Explanation Generate static key Generating and saving a static key. Load static key Load static key in the router (the remote station must have the same static key).

  • Page 43: Status

    CT-Router LAN VPN - OpenVPN Status VPN  OpenVPN  Status OpenVPN status Explanation Name Name of the VPN connection Remote host IP address or URL of the remote station Status Activated (=green field)

  • Page 44: I/O

    CT-Router LAN The CT-Router HSPA is equipped with four digital inputs and outputs which can be configured by you in the "I/O" menu. Inputs I/O Inputs Inputs Explanation High Option: In a high level it is possible to send a message via SMS or E-mail.

  • Page 45: Outputs

    CT-Router LAN Outputs I/O Outputs Outputs Explanation Manual: The device is switched ON / OFF manually via the WBM. Optionen Remote controlled: Switching on / off by SMS or socket server. Additionally it is possible to use the function "autoreset" for which a time period in minutes is being determined.

  • Page 46: Socket Server

    CT-Router LAN Socket Server I/O  Socket Server Socket server Explanation Socket server Disable: Triggering of the router via Ethernet is deactivated. Enable: Triggering of the router via Ethernet is activated. Determine socket server port (Port 80 cannot be used). Data which are Server port (default 1432) send to the router have to be compliant with XML version 1.0.

  • Page 47: System

    CT-Router LAN System It is possible to make general settings for the AK-DinRail-3G-Router in the system menu. Web configuration System  Web configuration Web configuration Explanation Server Port (default 80) Port setting for WBM via Internet browser.

  • Page 48: User

    CT-Router LAN System User System  User User Explanation Unlimited access (writing and reading) admin Determine new password. Limited access (only reading / not all areas) user Determine new password.

  • Page 49: Log Configuration

    CT-Router LAN System Log configuration System  Log configuration Log configuration Explanation Disabled: External logging deactivated. Remote UPD logging Enabled: External logging activated. Server IP Address IP address of the external log server. Server port (default 514) Port of the external log server.

  • Page 50: Log File

    CT-Router LAN System Log file System  Log-File Log-File Explanation Clear Entries in the internal log file are deleted. View Log file entries are displayed in the browser window. Save Log file is saved.

  • Page 51: Comserver - Serielle Schnittstelle Konfigurieren (Optional)

    CT-Router LAN System ComSERVER - Serielle Schnittstelle konfigurieren (optional) System ComSERVER ComSERVER Explanation Satus Schnittstelle: Disabled / Enabled Einstellen der seriellen Verbindung – RAW oder RFC2217 Connection Type Server Port (default 3001) Auswahl des Ports für die Netzwerkkommunikation Baud Rate...

  • Page 52: Smtp Configuration

    CT-Router LAN System SMTP Configuration System SMTP Configuration SMTP configuration Explanation SMTP Server IP address / host name of the SMTP server SMTP Port (default 25) Port of the SMTP server Transport layer security Encryption: None, STARTTLS, SSL/TLS Authentication No authentication: No authentication Plain password: Authentication user name and password (unencrypted transmission of the authentication data).

  • Page 53: Configuration Up-/Download

    CT-Router LAN System Configuration Up-/Download System  Configuration Up-/Download Up-/Download Explanation Download Download current configurations. Upload Upload secured or modified configuration and confirm by pressing the button "apply". Reset to factory defaults Reset the configuration and IP settings to factory settings. Uploaded...

  • Page 54: Rtc

    CT-Router LAN System System  RTC Explanation New Time Manuelle Zeitkonfiguration, falls kein NTP-Server vorhanden ist. Time zone Selection of time zone. Disable: Consideration of summertime deactivated. Daylight saving time Enable: Consideration of summertime activated. NTP Synchronisation Date and time can be synchronized using an NTP server. If this function is used for the first time the first synchronisation may take up to 15 minutes.

  • Page 55: Reboot

    CT-Router LAN System Reboot System  Reboot Reboot Explanation Reboot NOW! Force immediate restart of the router! Restart the router on certain days of a week at a certain point in time. Determine the Daily reboot days of the week for the restart by clicking on the check box.

  • Page 56: Firmware Update

    CT-Router LAN System Firmware update System  Firmware update Reboot Explanation Firmware update modem These updates provide for function extensions and product updates. Update Web based These updates refer to the configuration via an Internet browser. management...

  • Page 57: Inquiry And Control Via Xml Files

    CT-Router LAN Inquiry and control via XML files Format of the XML files Each file starts with the header: <?xml version="1.0"?> oder <?xml version="1.0" encoding="UTF-8"?> Followed by the base entry. The following basic entries are available: <io> </io> # I/O system <info>...

  • Page 58: B) Query General Information

    CT-Router LAN Inquiry and control via XML files b) Query General Information <?xml version="1.0"?> <info> <device /> # query device data <radio /> # Query data for radio communication (mobile phones only) </info> The system returns something like this: <?xml version="1.0" encoding="UTF-8"?>...
  • Page 59 CT-Router LAN Inquiry and control via XML files The response is delivered as follows: <?xml version="1.0" encoding="UTF-8"?> <result> <email>done</email> </result> or in case of an error: <?xml version="1.0" encoding="UTF-8"?> <result> <email error="3">transmission failed</email> </result> Notes regarding the presentation: The indentations and line breaks only serve for a better understanding and do not need to be sent nor are they sent.

  • Page 60: Functional Test

    CT-Router LAN Functional test Functional test by means of Windows Hyperterminal In order to perform a test it is possible to use the known program "Hyperterminal" under Windows. Using Hyperterminal it is possible to send XML files to the socket server of the router. The corresponding XML files (see chapter "Inquiry and control via XML files") need to be saved on your user PC beforehand.

  • Page 61: Examples Of An Application

    CT-Router LAN Examples of an application Establishing a connection to the Internet Using the AK-DinRail-ROUTER you have access to the Internet via mobile phone networks. A SIM card of your mobile phone provider which is released for package services e.g. GPRS/EDGE or UMTS/HSPDA is required.
  • Page 62 CT-Router LAN Examples of an application  Change over to a "Wireless network" and "Packed data setup" and activate the package data transfer in the mobile phone network. To do so, set "Package data" to "Enable".  In order to access the Internet with your PC you have to enter the IP address of the router as default gateway and as DNS server in the network settings.
