AMI-V6
Multimedia player for CAR
INSTALLATION MANUAL
1. INTRODUCTION ....................................................................
2. RECOMMENDATIONS ..........................................................
3. SCHEME OF CONNECTIONS ..............................................
4. UNLOCKING DEVICE IN SYSTEM MMI .............................
5. ELEMENTS SET .....................................................................
6. INSTALLATION EXAMPLE IN A CAR ....................................
JuNa
PPHU
ul. Zgorzelicka 34 , 97-200 Tomaszow Mazowiecki POLAND
Content
Manufacturer
Model:
AMI-V6_MMI_3G
2
2
4
5
7
8
Advertisement
Table of Contents
Related Manuals for Juna AMI-V6
Summary of Contents for Juna AMI-V6
-
Page 1: Table Of Contents
AMI-V6 Model: AMI-V6_MMI_3G Multimedia player for CAR INSTALLATION MANUAL Content 1. INTRODUCTION ..............2. RECOMMENDATIONS ............3. SCHEME OF CONNECTIONS ..........4. UNLOCKING DEVICE IN SYSTEM MMI ......5. ELEMENTS SET ..............6. INSTALLATION EXAMPLE IN A CAR ........JuNa... -
Page 2: Introduction
The priority during the design and production of all devices by JUNA electronics company is security and service comfort. It has been achieved by applying the modern techniques of design and production processes of electronic devices. - Page 3 In the interest of high quality and development of our products, JUNA Electronics reserves the right to make technical changes. In the case of a warranty claim, the device should be sent back to the seller in original packaging with a detailed description of the problem with attached purchase invoice.
-
Page 4: Scheme Of Connections
1. Disconnect the main connector ISO from MMI unit. 2. Remove green plug from ISO socket. 3. In place of the removed plug, put in green plug of bundle AMI-V6. point 4. Insert the FAKRA plug of bundle AMI-V6 to MMI unit. point 5. -
Page 5: Unlocking Device In System Mmi
4. UNLOCKING DEVICE IN SYSTEM MMI Unlocking device in system MMI can be allowed after completely installing AMI-V6. WARNING: OBD dongle can be used only in car in which was unlocking AMI function OBD dongle is equipped in red LED, which inform about current OBD dongle state: - Directly after connecting to OBD diagnostic connector, LED flashes with 1Hz... - Page 6 If your car does not have TONE button, use MENU button. 5. Press button MEDIA --->SOURCE. 6. If LED on dongle is off – remove dongle from OBD socket. JuNa PPHU Manufacturer ul. Zgorzelicka 34 , 97-200 Tomaszow Mazowiecki POLAND...
-
Page 7: Elements Set
5. SET OF ELEMENTS 1. Interface module - AMI-V6 2. Connection cable - W-AMI-v6 3. Activator - GM-3G... -
Page 8: Installation Example In A Car
INSTALLATION EXAMPLE FOR Audi A7 MMI 3G+ 2. Choose the place of installation interface 1. Remove glove compartment and MMI unit. in the glove compartment. 4. Cut out holes for socket and screws in 3. Cut holes for socket and screws in the the side of glove compartment. - Page 9 9. Remove ISO connector from MMI unit. in this place green plug from bundle AMI-V6. 11. Connect ISO connector to MMI unit again. 12. Insert green plug (4 pin) of bundle AMI-V6 into brown socket in MMI unit. 13. After connecting USB stick and iPOD, interface is activated and devices are listed on MMI screen.
