Summary of Contents for Qcom MD560
- Page 1 MD560(B) User’s Manual...
- Page 2 FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
-
Page 3: Table Of Contents
Contents 1. Contents 2. Introduction 3. Bluetooth Basics 4. Installation Overview 4.1 Installation Procedures of Bluetooth Utility 4.2 Installation Procedures of Modem Driver 5. Troubleshooting... -
Page 4: Introduction
Modem Daughter Card and needed component is included for Agere Systems AC’97 Modem. The MD560 (B) is designed to provide modem and Bluetooth function on a MDC form factor. The Bluetooth function is based on CSR BlueCore3-ROM Single Chip Bluetooth System, which implements the full speed class 2 Bluetooth operation with full 7 slave piconet support. -
Page 5: Bluetooth Basics
3. Wireless Bluetooth Basics Wireless Bluetooth systems offer a great number of advantages over a traditional, wired system. Wireless Bluetooth are more flexible, easier to setup and manage and often more cost effective than their wired equivalence. Using radio frequency (RF) technology. Bluetooth transmits and receives data over the air, minimizing the need for wired connections. -
Page 6: Installation Overview
4. Installation and Overview Here are some steps you will perform in establishing your wireless network connection: • Install Bluetooth Utility using the Installation CD. • Install Agere Systems AC’97 Modem driver using the Installation CD. -
Page 7: Installation Procedures Of Bluetooth Utility
4.1 Installation Procedures of Bluetooth Utility Please follow the below steps one by one to install the utility software successfully. 1. Insert the card into MDC slot, and take BT antenna to plug into RF connector. 2. Power on your PC and allow Windows to load fully. 3. - Page 8 4. The welcome window will appear, please click Next 5. Click Yes button to accept the terms in the license agreement 6. Click Next to install to this folder...
- Page 9 7. Wait, while BlueSoleil Setup is performing the request operations. 8. Please click Finish to complete the Bluetooth installation...
-
Page 10: Installation Procedures Of Modem Driver
4.2 Installation Procedures of Modem Driver 1. Start Windows 2. Windows will immediately display the Found New Hardware Wizard page. Click the Cancel button. 3. Locate the MD560(B) Driver folder, double-click setup icon to start the installation. - Page 11 4. Wait for a minute, after the Modem window displays, click OK button to start the installation. After Windows re-starts, you can check your modem by following instructions to checking your MD560(B) if setup successfully. 5. Go to Start Setting...
- Page 12 As you found the Agere Systems AC’97 Modem, the install is ready. 6. Go to Start Setting Control Panel Phone and Modem Options...
- Page 13 7. On the Phone And Modem Options table, please choose Modems and click Properties. 8. Click Diagostics table on Agere Systems AC’97 Modem Properties. Then click Query Modem to communicating with Modem 9. The Modem will respond to the following message as screen showed that means your modem installed successfully.
-
Page 14: Troubleshooting
5. Troubleshooting Bluetooth and Modem Daughter Card If you still encounter some problems while installing the Bluetooth and Modem Daughter Card utility and driver software or you want to confirm whether your software is installed properly or not, we have listed the procedure for checking the various components after you have installed the software.
