Summary of Contents for Cozum GP922
- Page 1 GP922 GP722 GAS TILTING PAN INSTRUCTION MANUAL Sayfa 1/15...
-
Page 2: Table Of Contents
CONTENTS INSTALLATION INFORMATION A. AIMS AND SCOPE B. RESPONSIBLITIES C. SIGNS 1. DEVICE SPECIFICATIONS 1.1. TECHNICAL SPECIFICATIONS 2. TRANSPORTATION AND INSTALLATION OF THE PRODUCT 3. SAFETY WARNINGS 4. COMING THINGS TOGETHER WITH THE PRODUCT 5. DEVICE DESCRIPTION/EXPLANATION 6. PLACING THE DEVICE AND PREPARING IT FOR START UP 7. -
Page 3: Aims And Scope
AIMS AND SCOPE Descriptions for safe use and maintenance of the product RESPONSIBLITIES Responsibilities of Product’s Owner: The product’s owner is responsible for applying of safety rules stated in this Instruction Manual or getting them applied by delegating his authorities and risks, which may arise due to not applying. The product’s owner is also responsible for the periodical maintenance of the machine. -
Page 4: Device Specifications
1. Device Specifications 1.1 Technical Specifications GP922 G-GAZ BAĞLANTISI (GAS CONNECTION) W-SU GİRİŞİ (WATER İNLET) S-SU ÇIKIŞI (WATER OUTLET) 1000 GP722 G-GAZ BAĞLANTISI (GAS CONNECTION) W-SU GİRİŞİ (WATER İNLET) S-SU ÇIKIŞI (WATER OUTLET) Sayfa 4/15... - Page 5 Heat input of one burner Total heat input Number Type G20- G20- G30- G30- G31- nozzles 20mbar 25mbar 30mbar 50mbar 37mbar GP922 GP722 Nozzle Diamater Type G20- G20- G30- G30- G31- Nozzle diamter 20mbar 25mbar 30mbar 50mbar 37mbar Burner 1.50...
-
Page 6: Transportation And Installation Of The Product
2.TRANSPORTATION AND INSTALLATION OF THE PRODUCT During transportation, take necessary precautions against the risk of falling down and being turned upside down for the product. Place the product onto a flat and solid ground. Do not install the product near the flammable and explosive materials and do not keep any flammable and explosive material near the furnace, while it is working. -
Page 7: Coming Things Together With The Product
In case of needing to drive the device by a different gas, this transformation must be carried out a certified specialist or an authorized service. When determining any gas leakage, gas valve must be closed and burning must be ended up. This appliance is only for professional use and that it shall be used by qualified people If the fire stops continuously, authorized service must be called. -
Page 8: Pre-Inspections To Be Performed For Start Up
Place on the ground the machine with adjustable leg in type by adjusting its legs, for fixed the devices with fixed leg, by smoothing the ground. There must be sufficient ventilation in the area, where you operate the device. ... - Page 9 IGNITION OF THE PILOT BURNER SERİES 600-700-900 Press the knob and turn it counterclokwise until it reach position .Wait 20 seconds all the air expelled from the pipes then push piezoelectric button until the pilotflame alights.After 5 seconds release the konb desired position.Repeat oparation if the pilotflame should go out. IGNITION OF THE BURNER AND TEMPATURE REGULATİON SERİES 700- SERİES 900 Turn to knob numbered from 1 to 8 to the desired setting;the gas will fallow the main burners,which will ignated.
-
Page 10: Gas Diagram
GAS DIAGRAM SERİES 900 15-03 15-01 15-02 07-01 07-02 07-03 Sayfa 10/15... -
Page 11: Gas Equipments
GAS EQUIPMENTS SERİES 900- SERİES 700 DIMENTION/ PART NAME STANDART Collector Ø21x2 1000mm Olive Ø 10 (İnlet) Olive 3/8’’ (Outlet) M16x10 Gas valve Pel25st Burner (series 900) 10 kW Burner (series 700) 8,4 kW Pilot Burner 07-01 Nut Ø 4 07-02 Olive Ø... -
Page 12: Cleaning The Device
12. CLEANING THE DEVICE Device must be cleaned every day after use, after being sure that it is completely cooled down. Cleaning must be made by a clean wet cloth by wiping the device. It is recommended that stainless steel surfaces should be wiped by inox cleaners. During cleaning, do not use sharp edged, cutting and drilling tools such as scraper, emery in no way. -
Page 13: Change The Gas Enjector
15. CHANGE THE GAS ENJECTOR 15.1 Main Burner 1) Remove the control panel by unscrew the secrews ‘2’. 2)Raplace the main burner nozzles 14 with disered gas type nozzle according to nozzle daimeter chart. Sayfa 13/15... -
Page 14: Pilot Burner
Primary air -adjustment of the diffuser for gas types G20-20 mbar:a=15 mm G20-25 mbar:a=7mm G30-30 mbar:a=12 mm G30-50 mbar:a=12 mm G31-37 mbar:a=12 mm 15.2 Pilot Burner The pilot flame is the nozzle type with fixed air.The only adjustment required is replacement of the nozzle depending on the type of gas. - Page 15 INFORMATIONS ABOUT THE FIRM COZUM KITCHEN IND. & TRADE CO. Head Office-Factory 10015 Sokak No.13 A.O.S.B. Izmir - TURKEY Tel: 00 90 (232) 376 72 76 Fax: 00 90 (232) 376 72 78 e-mail: fabrika@cozummutfak.com Export Department-Showroom-Sales Center Kısıklı Caddesi Haluk Türksoy Sokak No.21/1 Altunizade-Istanbul-TURKEY...
