  • Page 1 IEEE 802.11a Outdoor Multi-function Radio OCT. 2005...
  • Page 2 WARNINGS In order to comply with international radio frequency (RF) exposure limits, dish antennas should be laced at a minimum of 8.7 inches (22 cm) from the bodies of all persons. Other antennas should be laced a minimum of 7.9 inches (20 cm) from the bodies of all persons.
  • Page 3 To meet regulatory restrictions, the external antenna access point/bridge unit and the external antenna must be professionally installed. The network administrator or other IT professional responsible for installing and configuring the unit is a suitable professional installer. Following installation, access to the unit should be password protected by the network administrator to maintain regulatory compliance.

  • Page 4: Package Contents

    PACKAGE CONTENTS The package you have received should contain the following items: • 802.11a Wireless Outdoor Bridge/Access Point ………..……………………..………...……….x1 • PoE Injector. ……………….…………………………………………….………….…………...…….x1 • AC Power Code ………………………………..………………………………….……….…….……x1 • 15V Power adaptor………………………………………..………………………….……….……….x1 • Mounting Kit ...…………………………..……………………………..…….…………….……….….x1 • Product CD….……………………………………………………………………....…..……x1 • Quick Installation Guide……………………………………………………………………..…..…….x1 If any item on the above list is not included or damaged, please contact your local vendor for support.

  • Page 5: Mechanical Description

    MECHANICAL DESCRIPTION Please refer to the following table for the meaning of each feature. Grounding stud N- Jack Antenna RJ-45 Port Connector Outdoor Multi-function Radio Use the SFTP cat.5 cable with weatherproof connector to connect to RJ-45 Port the “To DDU” side of PoE injector. N- Jack Antenna Here you can attach the proper antenna with the Outdoor Multi-function Connector...
  • Page 6 DC Input LED Indicator (Power) To Ethernet To Radio Power over Ethernet injector To Ethernet RJ-45 port used to connect to the 10/100 Base T complied device such as switch, router or PC. To ODU RJ-45 port used to connect to the ODU. Connect to the Power adaptor for 15V DC input.
  • Page 7 The Outdoor Multi-function radio and power injector can be damaged by incorrect power application. Read and carefully follow the installation instructions before connecing the system to its power source. Power Over Ethernet Injector is not waterproof unit, should not exposed to outdoor without any protection.
  • Page 8 MOUNTING THE MULTI-FUNCTION RADIO This section show you how to mount the Outdoor Multi-function Radio, please read it carefully before you start to install the hardware, Be safe and step by step to finish the hardware installation. OUTDOOR INDOOR Panel Antenna IEEE802.11a Outdoor Multi-function radio 10/ 100 Base T...
  • Page 9 Mounting the Outdoor Radio There are two parts of the Mounting kit: Enclosure bracket － attached to the back of the outdoor radio. Pole bracket － mounted on the pole or tower with the U-bolts. Follow the next steps to mount the 802.11a Outdoor Multi-functional radio on the pole. Mount the enclosure bracket to the back of the outdoor radio.

  • Page 10: Connect The Ethernet Cable

    Mount the enclosure on the pole This equipment must be grounded. Never defeat the ground conductor or operate the equipment in the absence of a suitably installed ground conductor. Contact the appropriate electrical inspection authority or an electrician if you are uncertain that suitable grounding is available.
  • Page 11 Welding the shielding parts well of the RJ-45 connector and the SFTP cable well to ensure the performance of the system and avoid the moisture leak into the radio. Weld the RJ-45 connector with the SFTP cable Weld the SFTP cable as the Figure 2-4, make sure the welding parts NOT bigger than the figure, or it will affect the function of waterproof RJ-45 connector.
  • Page 12 You should read and carefully follow the installation instructions before connecting the system to its power source. The access point/bridge and power injector can be damaged by incorrect power application. Connect the ground stud Connect the ground stud on the ODU enclosure with the ground wire. This equipment must be grounded.
