Summary of Contents for Beyondvape Centurion

  • Page 1 User Manual...
  • Page 2: Standard Configuration

    Output Wattage: 1-100w Resistance Range: 0.05-1.5ohm for TC modes 0.1-3.5ohm for VW/ Bypass mode Temperature Range: 100-315°C/ 200-600°F(TC modes) OLED screen Standard Configuration 1*Beyond Vape Centurion 1*Decorative Ring 1*Battery Sleeve 1*USB Cable Up button 1*User Manual 1*Warranty Card Down button...
  • Page 3 How to use: 1. Power On/Off: Unscrew the bottom cover and put one 26650 cell into the battery body. Press the fire button 5 times in quick succession to turn the device on and off. You can also use one 18650 cell with the help of battery sleeve, and then the maximum output power recommended is 75W. (Note: Please adjust the wattage to a proper range to match your atomizer before using.
  • Page 4 3. Resistance Lock Function: While the device is on, simultaneously hold the fire button and the up button to enter Resistance Lock mode. To disable resistance lock, repeat the procedure.(Note: Such operation should be carried out at room temperature.) 4. Adjustment Lock function: While the device is on, simultaneously press the up and down buttons.
  • Page 5 300-400 Titanium 300-400 SS (303, 304, 316, 317) 80-200 Note: 1. The TCR value in the sheet is 10 multiplied by the actual TCR. 2. The TCR value range for Beyond Vape Centurion is 1-1000. Supplementary TC Modes Functions: English...
  • Page 6 Wattage adjustment: In TC modes, press the fire button 4 times in quick succession to enter the menu, press the up button to increase wattage and the down button to decrease wattage. Long pressing the up or down button will make the wattage setting rapidly increase or decrease.
  • Page 7 VW Mode: In this mode, output wattage can be adjusted from 1W to 100W with the up and down buttons. Bypass Mode: Bypass mode is a direct output mode of voltage. In this mode, the internal chip is “bypassed” and the supporting atomizer resistance is 0.1-3.5ohm.
  • Page 8 temperature, the device shows “Temp Protection”. Weak Battery Alert: In TC/VW/Bypass mode, when the device installed with an atomizer is working and the voltage of battery is below 2.9V, the device shows “Weak Battery”. Meanwhile, the output power will be reduced accordingly. English...
  • Page 9 Designed by Beyondvape in USA Manufactured by WISMEC in China...
