Android 4.0 system video door phones
Dear user:
Thank you for purchasing a GEMVARY Outdoor Terminal product. We hope our products
and service can make your life more convenient and happy!
This user manual is just one of the resources to help you understand all the features the
GEMVARY Outdoor Terminal has to offer, it should be properly kept for further use!
For more convenience, please read this guide before use. If any questions during use,
please contact us, we will certainly happy to serve you, or visit www.gemvary.com to learn
more about GEMVARY Outdoor Terminal product.
Note: any technology improvements are subject to changes without notice.
ADD:6th F, Bld 1, Honghualing West Industrial Area, Zhuguang North Rd, Nanshan District, Shenzhen
518055, China
TEL:+86-0755-86320888
User Guide
BEFORE BEGINNING
FAX: +86-0755-81466627
http://www.gemvary.com
第 1 页
Advertisement
Table of Contents
Summary of Contents for GEMVARY JQ1071
- Page 1 GEMVARY Outdoor Terminal has to offer, it should be properly kept for further use! For more convenience, please read this guide before use. If any questions during use, please contact us, we will certainly happy to serve you, or visit www.gemvary.com to learn more about GEMVARY Outdoor Terminal product.
-
Page 2: Table Of Contents
SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com Contents Introduction …………………………….….…4 Chapter 1 Indoor terminal Basic Operations External Interface Description...…6 Interface Introduction………..…….7 1.21 Application Interface Introduction…7 Basic Parameter Description.………..8 Product Model Description…………..9 Video Intercom Features……. 10 1.51 Phone Book…………………...12 1.52 Outgoing Message(OGM)……………….……..12 1.53 Guestbook………………………...13 1.54 Call Records……………………...13... -
Page 3: Introduction
SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com Chapter 2 Outdoor Entrance Main engine Instructions…………… 30 2.11 External Description…….30 2.12 Uses…………………….31 Basic Parameter Description….32 2.21 Outdoor machine instructions….32 Product Model Description……………….33 Chapter 3 FAQ & Maintenance Information FAQ………………………………….34 Maintenance Information………………….34 Chapter 4 After-sales service& Tips………...….………...36... -
Page 4: Chapter 1 Indoor Terminal Basic Operations
SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com security alarm information. And recorded in Netcom, then query receives outdoor terminal equipment video call on the network where each cell door machine. Through a proxy server, it control the external access. it translating internal and external... -
Page 5: External Interface Description
SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com 7〞Base The figure below shows : PA hole Screw hole 6P Jack Power Jack RJ45 Jack The figure below shows : 7＇ ＇Indoor unit external interface description Volume On\Off USB Jack TF Jack Mini 5P USB Jack... -
Page 6: Interface Introduction
SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com The figure below shows : 10＇ ＇Indoor unit base PA hole RJ45 Port Power port Buttons and interfaces description： A. Power Switch：On or Off（Long press 3 seconds），If you turn on the Standby Function （Setting refer to the Setup Function Description）,If Standby（Press the power key to switch to a state）... -
Page 7: Application Interface Introduction
SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com 1.21 Application Interface Introduction： As shown below, turn on the power and enter the first interface, the entire interface for full touch. Interface shortcut menu is as follow: Can send the the emergency alarm number to the management center 2、... -
Page 8: Video Intercom Features
SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com Video format The H.264 video up to 720P, 30 frames per second Camera 30 megapixel CMOS sensor Network type TCP / IP LAN and WAN Standby current 160MA Operating current 500MA DC voltage DC 12~18V... - Page 9 SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com such as:if you want to call District 1 Building 2 Unit 1 Room 201，enter“01,002,010,201”then, press the “ return” or keyboard marked symbols to exit the numeric keypad. Click “ call” , can make a call to the room which has already been entered. Ifthis building call another building , room number is shown : Then click “call”, the call has already been entered the room, the other person involved press...
-
Page 10: Phone Book
SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com "unlock the touch" button, there will be voice prompts and text display "Lockpicking". During the video intercom process can click the "record" button,on video recording process, you can also remotely unlock the lock function. video ends, click the "Stop" button, the video content in return to function selection screen, click on the "video query"... -
Page 11: Guestbook
SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com played OGM. 1.44Guestbook： The message that visitors left, click on this feature into “ Guestbook” choose to view, click “ View” , you can play the visitor's message 1.45Video Inquiry ： The call with the heads of households and door machine, will be displayed in this interface. -
Page 12: Information Inquiry
SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com 1.48Information Inquiry： As shown, the information sent from the service center in this query . Select the view information, click "View": 1.5Intelligent Household Only a expand interface 1.6Security Alarmfeatures 1.61Security Alarm： Click“Security Alarm” Enter into the security arming and disarming interface, as left shown. - Page 13 SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com Select the desired category, then turn on the“Arm”, and it will be displayed in the status display. For disarm, select the desired category, and click “Disarm” , enter disarm password for disarming. For inquiries alarm records, click on the “Alarm Record” , enter the query interface, as shown: Can be divided into the case of a room name, type, and time period to check alarm.
-
Page 14: Other Features
SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com alarm sounding, as shown in the figure on the left: You can select alarm phone number set in the security alarm settings, and also can set the alarm to send alarm messages to the specified phone, as shown: 1.7 Other Features... -
Page 15: Browser
SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com Click “Continue” Enter into the wallpaper selection operation Wallpaper Loading will be prompted to choose a favorite wallpaper. This is wallpaper preview state, click “Set Wallpaper”, Once Wallpaper setting success, it will automatically exit Setup and return to the main interface to view the new wallpaper. -
Page 16: Document Management
SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com door machine's range). Network Monitor window provides monitoring, playback history stored video, choose camera to take a photo. Click the "Full Screen" and cut screen interchangeable. App Store：When the area surrounding businesses to join the system, it will record related information. -
Page 17: Basic Setting Function
SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com District Stores： you can shop in nearby stores on the indoor unit, as shown on the left: 1.77Basic Setting Function IFLYTEK HD：a kind of input method. Setting： Enter setup interface, click on the lower right corner of Figure, a small window pops up, and click again to enter the selection window, in the bottom,select "setting function", enter the... - Page 18 SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com Flight Mode：Select and Cancel Ethernet： Click and enter into the Setting Mode, the first is Select or Cancel Ethernet. The second is configure the network: Click to enter, select“Advanced”to enter the Advanced Configuration. In the menu , the dynamic allocation can be selected. If not select dynamic, then you need to enter the IP address, subnet mask, gateway, DNS server on the Below, press OK to exit and then can be connected to Ethernet.
- Page 19 SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com （3）Notification ringtone. There are hundreds of ringtones to choose. （4）Touch tone Select or Close （5） Lock Screen tone :Select or Close 3、Show: Click Display, its function shown the following diagram on the right: ADD:6th F, Bld 1, Honghualing West Industrial Area, Zhuguang North Rd, Nanshan District, Shenzhen...
- Page 20 SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com （1）Brightness Adjustment: You can adjust the display brightness: （2）Wallpaper：Dynamic wallpaper replacement Wallpaper Gallery: you can choose Image and Click to set wallpaper Dynamic wallpaper settings are as follows: Static wallpaper settings: ADD:6th F, Bld 1, Honghualing West Industrial Area, Zhuguang North Rd, Nanshan District, Shenzhen...
- Page 21 SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com 4、Storage: you can select the media scan type, check the total capacity, used space and free space, internal storage capacity, and formatting the storage device functions. 5、Battery: you can check the battery power and the power consumption of related software.
- Page 22 SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com 7、Accounts & Sync: close or open the account, you can add a new account. 8、Location Services: you can use Google's location service to determine the user's probably location. 9、 Security: there are screen security protection (you can select Screen Lock unlock way: sliding, face unlock,picture, PIN, password).
- Page 23 SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com 11、Backup and Reset： （1）Restore the factory settings: Click to clear all the data on Tablet PC （2）Recovery: after system reboot and into Recovery mode, it can clear partition data or system upgrade. 12、Date and Time：In here, you can set the time and time zone and network synchronization, adjust the date and the time, time format and date format.
- Page 24 SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com determines the time zone, the system will automatically according to the network to adjust the time. 13、Auxiliary functions：In here, “TalkBack” provides spoken feedback 14、Developer: Non-developers may not need to understand this feature. 15、Tablet PC：Including the status messages, legal information, model, Android version, firmware version, kernel version, the version number and other information.
- Page 25 SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com Chapter 2 Outdoor Entrance Main engine 2.1Instructions 2.11 7'' Outdoor Terminal External Description： Number buttons 2 million pixel camera Speaker 7'' LCD Function keys(From left to right:OK, clear, correct, hang up) Number keys Swipe District Sound Hole 10'' Outdoor Terminal External Description：...
- Page 26 SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com Number keys Swipe District 10.1'' LCD Screws holes The host door of villa： Camera Sound Hole Call indoor extension Call Management Department ID\ICSwipe District Recording hole 2.12.Outdoor terminal automatically boot, boot into the main interface, as shown:...
- Page 27 SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com 1、Outdoor terminal can call the indoor terminal management unit, video intercom, IC or ID and password lock function. ２、Call households: Door machine can call all of the indoor unit. The operation is as follows: "Enter Household room number press OK. Call the indoor unit, when it is turned on, you can make two-way conversation.
- Page 28 SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com Running out of memory 1G Audio formats PCM lossless,uncompressed digital audio formats Camera CMOS Sensor 2 mega pixel Night vision compensation infrared light or bright white light６IR‐LED Standby Current 150MA DC voltage DC12~18V Video transmission 300~3,400HZ Delay 200MS Temperature 45％~95% ...
-
Page 29: Troubleshooting And Maintenance
SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com IR‐LED Network type TCP / IP LAN and WAN Standby Current 150MA Operating Current 500MA DC voltage DC 12-18V Audio transmission Single two‐wirefull‐duplex delay 200ms Vedio transmission 300～3，400HZ delay200MS Temperature -20～50<℃ Humidity 45%-95% IC/ID stored value... - Page 30 SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com NOTICE TO USERS: the product has its dedicated power supply, power cord, and may be potential risk, such as incorrect use may result in personal injury or property damage. Please use the product properly. （2）In use, pay attention to what? Note: Do not use in damp places, such as bathrooms.
- Page 31 SHENZHEN Gemvary TECHNOLOGY CO.,LTD http://www.gemvary.com Tips Chapter This manual applies to the 7 " or 10" indoor / outdoor machine. Contents of this manual are only for reference, if any change without notice, please find the supplier to provide the latest version of the manual.
- Page 32 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
