Installation Manual for
EN Compliant Grade 3 Type A
INSTALLATION
Mount the metal enclose onto the wall in the usual manner.
Connect the Live, Earth and Neutral terminals to the un-switched fused spur.
Connect 0V, tamper and fault outputs to the control panel as appropriate (see control panel
manual for details). Connect 12v and 0v to the system.
Fit the batteries and ensure that the tamper switch is connected to the PCB.
Switch on the AC supply and confirm that the "EPS OK" LED is on.
If not all the batteries are to be fitted, the "Status" LED will blink. Press the "Learn" button,
and the "Status" LED will flash quickly while the battery configuration is learned in.
The "Status" LED will start to flash slowly indicating that the batteries are charging. If the
"APS OK" LED is off, the battery voltage may be low. Wait for a couple of minutes to
confirm that the "APS OK" LED comes on. When the batteries are fully charged, the
"Status" LED will go out.
These products are suitable for use in systems designed to comply with
PD6662: 2010 at Grade 3 and Environmental Class 2.
Cwm Cynon Business Park – Mountain Ash – CF45 4ER - UK
D1530 Series
Power Supplies
D1530 Series
D1531
D1532
Dycon Ltd
Tel: +44 (0)1443 471 060 - Fax: +44 (0)1443 479 374
www.dyconsecurity.com
Grade 3, 1A
Grade 3, 2A
-
sales@dyconsecurity.com
Advertisement
Related Manuals for Dycon D1531
Summary of Contents for Dycon D1531
- Page 1 Installation Manual for D1530 Series EN Compliant Grade 3 Type A Power Supplies D1530 Series D1531 Grade 3, 1A D1532 Grade 3, 2A INSTALLATION Mount the metal enclose onto the wall in the usual manner. Connect the Live, Earth and Neutral terminals to the un-switched fused spur.
- Page 2 AC supply The power supply has 3 terminal blocks for Live, Earth and Neutral connections, and is protected by a 20mm anti-surge fuse. Mains earth is isolated from the 0V output, although, when supplied boxed, mains earth is connected to the metal enclosure. Tamper output This output is connected to the tamper connector.
- Page 3 Specifications Power supply Type A, Security Grade 3, Environmental Class 2 AC input voltage 230v +10% -15%, 50Hz ± 15% AC input fuse 20mm anti-surge fuse rated at D1531 230V 1A D1532 230V 2A Output voltage 13.7v nominal Output ripple Less than 50mV (less than 0.4% @ 13.7v)
- Page 4 130 x 100 x 38 260 x 320 x 87 430 x 3455 x 90 Weight (kilos) 0.19 In case of problems, telephone Dycon Technical Support on +44 (0)1443 471064 or email technical@dyconsecurity.com. 4 D1530 Series Installation Manual - D1530-INST/13A/v3 ...
