Blue Canvas 265BXQ7W-UC User Manual

Digital canvas 26.5"
Hide thumbs
Table of Contents

Advertisement

Quick Links

Blue Canvas
User Manual
Models
265BXQ7W-UC
`

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 265BXQ7W-UC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Blue Canvas 265BXQ7W-UC

  • Page 1 Blue Canvas User Manual Models 265BXQ7W-UC...

  • Page 2: Table Of Contents

    4. Blue Canvas Viewer Setting........................... 7 4-1) Blue Canvas connect ..........................7 4-2) Wi-Fi setting ............................11 4-3) Blue Canvas Device Name setting ....................12 4-4) Google ID setting ..........................13 4-5) Instagram settings ..........................14 5. Blue Canvas contents settings ........................17 5-1) Menu ................................

  • Page 3: Safety Instruction

    1. Safety Instruction Read, keep and follow these instructions - Heed all warnings. - Do not use this product near water or expose the product to dripping or splashing of any water or liquid. - Clean only with a dry cloth. - Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus (including amplifiers) that product heat.
  • Page 4 “This application and its antenna must not be co-located or operation in conjunction with any other antenna transmitter. A minimum separation distance of 20 cm must be maintained between the antenna and the person for this application to satisfy the RF exposure requirements.” The device for operation in the band 5150–5250 MHz is only for indoor use to reduce the potential for harmful interference to co‐channel mobile satellite systems.

  • Page 5: Composition Of Items And Installation

    2. Composition of Items and Installation 1-1) Composition of Items Check the following accessories Blue Canvas Power Adapter Power Cable Wall-Bracket Wall Bracket Manual Screw 1-2) Names of parts On/Off Button Reset Button Micro USB DC Power Input - 5 -...

  • Page 6: 1-3) Installation

    1-3) Installation Drill ① ② Clean the wall where the device are installed Check the space Put the Wall-Bracket to the wall and mark screw hole at right position Mark Hole Drill the hole at marked point(at ) with drill that fit diameter of screws Drill the hole Put the Wall-Bracket at the right position with hole(at ) and screw the...

  • Page 7: Blue Canvas Editor Download

    4. Blue Canvas Viewer Setting 4-1) Blue Canvas connect 1. When you first turn on the blue canvas, you can see Device Settings screen displays. And Wi-Fi hotspot function is executed. The Wi-Fi hotspots SSID are displayed. Blue Canvas Viewer Settings...
  • Page 8 2. In the Blue Canvas editor, press the '+' button. and touch the 'Device Connect' button. connection screen will change to blue canvas. press the '+' button - 8 -...
  • Page 9 - 9 -...
  • Page 10 SSID List 3. Touch the SSID you want to connect, connect the device to the blue canvas blue canvas both the editor and the viewer will change Wi-Fi settings screen. - 10 -...

  • Page 11: 4-2) Wi-Fi Setting

    4-2) Wi-Fi setting Wifi setting 1. When the changes to the Wi-Fi settings screen, blue canvas, the editor will search for nearby Wi-Fi network to display a list of networks. 2. Select the network device to connect to the blue canvas and then enter your password.

  • Page 12: 4-3) Blue Canvas Device Name Setting

    4-3) Blue Canvas Device Name setting Device Name setting The device name is the name to be displayed on the device list of blue canvas editor. We recommend that you set a unique name. 1. Enter device name in blue canvas Editor Settings screen.

  • Page 13: 4-4) Google Id Setting

    4-4) Google ID setting Google ID setting 1. When Google changed identity settings screen, blue canvas, the editor displays a list of IDs registered in the Google smart phone / tablet. 2. Choose your Google ID. 3. If you touch the right arrow (>),will change to the Instagram ID settings screen.

  • Page 14: 4-5) Instagram Settings

    4-5) Instagram settings Instagram account setting Blue Canvas will play Instagram contents using the Instagram account 1. Instagram account will appear. 2. If you are not logged on Instagram, 'Instagram login' will be displayed. Touch to display the login screen.
  • Page 15 Blue Canvas Device will displayed setting finish. And will try to connect to a network. After connect network, display will changed to Initial Screen. Setting finish Initial Screen - 15 -...
  • Page 16 Blue Canvas Editer Initial Screen - 16 -...

  • Page 17: Blue Canvas Contents Settings

    5. Blue Canvas contents settings 5-1) Menu Press the button(≡) to open the menu. Menu 1. General Settings : Show general settings menu. 2. Page Settings : Show page settings menu. 3. Device Management: Show device management menu. - 17 -...
  • Page 18 When you touch the blue canvas Editor '+' button on the bottom right, show function buttons. function menu ( '+' button ) 1. Device connect : Connect new device. 2. New File : Create new contents file. 3. Open File : Open existing created contents file.

  • Page 19: 5-2) General Settings

    5-2) General Settings General Setting 1. SNS Service Authentication : Click the gray color Instagram icon and type Instagrame ID and password. Be sure that one log in ID need to be used for one master device. Instagram will cancel the authentication if same ID will be used in a different device at the same time.
  • Page 20 ‘Time’ option is to show contents according to the contents posting time. ‘Random’ option is to show contents in random order. ‘Video’ option is used for Blue Canvas with wide monitor showing YouTube video contents (this option is testing one and ignore at this time).
  • Page 21 General Setting 2 1. Show Page Info : If checked this option, default image will show when start contents. 2. Display Photo in Square : If photo is not square, show center crop, displays the photo central area. 3. Default Image : User can set default image of BlueCanvas page. Select square image (recommended resolution of image is 1,920*1,920) and this image will be shown instead of Instagram logo.

  • Page 22: 5-3) Page Settings

    4. Font Folder : User can set font file folder on Android smartphone/tablet. Copy font file to this folder and user can set different font file for each page. 5. Auto Update : BlueCanvas Viewer will be updated automatically by SoundGraph, Inc. It is highly recommended to check this option.
  • Page 23 Instagram using user ID and password. Also user need to get authentication by Instagram on Blue Canvas Editor. In case of Google Drive, user can show the image files on Google Drive folder. User need to select appropriate Google ID when using Google Drive.
  • Page 24 Page Settings 2 1. Display Schedule : User can set the time schedule to show each content page. User can set Page 1 to be shown from 10:00 ~ 11:00 and Page 2 be show from 11:00 ~ 12:00. 2. Page Name : Default Page name will be shown according to contents type as like ‘#Starbucks’...
  • Page 25 4. Contents Display Period : User can set the period of contents searching as like show contents posted within 1 week. 5. Number of Display Contents : User can set the total number of contents will be show Blue Canvas. Page Settings 3 - 25 -...
  • Page 26 1. Focus Color : The background color of the photo information & hash tag will change 2. Font : User can select font size, font and color etc 3. Apply All Pages : User can set same font selection to the other pages at one time. 4.

  • Page 27: Product Specs

    6. Product Specs ※ Product specs are subject to change without notice to improve performance. 1)Display Active Screen Size 26.49 inches (672.85mm) diagonal LG Display IPS Panel ( Hard Coating, Anti-Glare Surface Panel Type treatment) Resolution 1920 × 1920(QHD) Luminance ,white 450 nit ( center 1point, Typical ) Color Gamut NTSC 92%(Wide Color Gamut)
  • Page 28 - 28 -...
