Summary of Contents for Lexus RC 350 2015

Page 1 RC350/RCF Pre-Delivery Service Manual Lexus Technician: Before you perform Pre-Delivery Service (PDS) on this vehicle, be sure you: • Read and understand this PDS Manual • Read and understand all applicable PDS Technical Service Information Bulletins (TSIBs) for this vehicle • Read and understand the PDS Precautions in the TSIBs. • Attend the “Technical Introduction to Lexus Course L005” at the Lexus Area Office When performing PDS on this vehicle: • Use the PDS Manual when performing this service • Check the Technical Information System (TIS) for any updated PDS TSIBs that apply to the model you are servicing • Verify that the Vehicle Identification Number (VIN) on repair order and vehicle match • Lift vehicle and perform under vehicle safety/damage inspection • Road test vehicle long enough to test hot engine and drive over rough road (Bott dots) to test for rattles/ squeaks • When PDS is completed, sign Vehicle Delivery Certificate, located in the glove box The following TSIBs are available on TIS:...
Page 2 2015MY RC350/RCF Pre-Delivery Service Manual RC350/RCF...
Page 3: Table Of Contents
TABLE OF CONTENTS INSPECTION DETAILS A. ENGINE COMPARTMENT ............1 B. LOCKS AND LIGHTS ..............5 C. LEFT FRONT ................11 D. LEFT REAR ................34 E. TRUNK ..................36 F. RIGHT REAR ................38 G. RIGHT FRONT ................39 H. FRONT BUMPER ..............42 I. UNDER VEHICLE (SAFETY/DAMAGE) ........45 J. ROAD TEST ................46 COMPLETION ..................54 INDEX ....................57 RC350/RCF...
Page 4 TABLE OF CONTENTS RC350 Page Relay block......................- Battery ........................3 Engine oil level dipstick ..................2 Engine coolant reservoir ..................3 Engine oil filler cap ....................2 Brake fluid reservoir ....................2 Washer fluid tank ....................4 Electric cooling fans .................... 48 Condenser ......................- Radiator ......................... - NOTE: Install protective fender covers prior to beginning the under-hood inspection. RC350/RCF...
Page 5 TABLE OF CONTENTS Relay block ......................- Battery ........................3 Engine oil level dipstick ..................2 Engine coolant reservoir ..................3 Engine oil filler cap ....................2 Brake fluid reservoir ....................2 Washer fluid tank ....................4 Electric cooling fans .................... 48 Condenser ......................- Radiator ......................... - RC350/RCF...
Page 6 TABLE OF CONTENTS Page Engine switch ....................... 8 Transmission shift lever ..................47 Meters ........................- Multi-information display ..................24 Parking brake ..................... 48 Turn signal lever ....................9 Headlight switch ....................9 Windshield wiper and washer switch ..............18 Emergency flasher switch .................. 10 Trunk opener ...................... 17 Hood lock release lever ..................2 Tilt and telescopic steering control switch* ............24 Tilt and telescopic steering release lever* ............24 Air conditioning system..................25 Audio system ......................
Page 7 TABLE OF CONTENTS Page Audio remote control switches................27 Paddle shift switches .....................- Meter control switches ..................24 Vehicle-to-vehicle distance button*..............50 Cruise control switch* ..................50 LDA switch* ......................49 Talk switch ......................27 Telephone switches ....................27 * If equipped RC350/RCF...
Page 8 TABLE OF CONTENTS Page Inside rearview mirror ..................32 Sun visors ......................31 Vanity mirrors ......................31 Interior light ......................16 Personal lights ....................16 Moonroof switches* ...................32 SOS button*......................33 Garage door opener switches ................33 * If equipped RC350/RCF...
Page 9 TABLE OF CONTENTS Page Driving position memory switches* ..............14 Outside rearview mirror switches ................16 Door lock switches....................15 Power window switches..................15 Window lock switch .....................15 Tire pressure warning reset switch ................ - PCS OFF switch* ....................11 * If equipped RC350/RCF...
Page 10 TABLE OF CONTENTS Page Seat heater switches* ..................31 Seat ventilator switches* ..................31 Heated steering wheel switch* ................31 Driving mode select switch ................. 51 TVD switch* ......................51 Snow mode switch....................51 VSC OFF switch ....................52 Remote touch* ....................28 Lexus display audio controller* ................28 * If equipped RC350/RCF VIII...
Page 11 TABLE OF CONTENTS RC350 Page Automatic high beam switch* ................10 Windshield wiper de-icer switch* ................ 16 Active rear wing switch*..................30 Odometer/trip meter and trip meter reset button ..........17 Instrument panel light control switches............... 17 Intuitive parking assist switch* ................29 BSM (Blind Spot Monitor) main switch* .............. 17 ASC switch* ......................53 * If equipped RC350/RCF...
Page 12 INSPECTION DETAILS...
Page 13: A. Engine Compartment
Visually and by hand check for water leaks in the vehicle interior from each of the following areas (make sure that the trim and floor carpet are not damp): a) Door glass weather strips b) Front cowl sides c) Around the windshield d) Around the moonroof area e) Around the quarter window f) Around the rear window PAINT FINISH (PAINT DEFECTS, DAMAGE) Visually and by hand inspect all body panels (doors, trunk, fenders, engine hood, roof panel) for surface damage from shipment or any for abnormalities (surface rust, paint flaking, chips, dents or scratches). NOTE: Carefully inspect all painted surfaces in a well-illuminated area (800-lux illumination is recommended). EXTERIOR PARTS FOR FIT Visually and by hand check the following parts for proper installation, rust, fit, misalignment and loose items: a) Front and rear bumpers b) Window moldings (front, side and rear) c) Lexus emblems (front and rear) d) Outside rearview mirrors e) Headlights, turn signal lights, side marker lights, fog lights and tail light lenses f ) Doors, engine hood and fuel filler door g) Moonroof h) Front/Rear door panel protector i) Outside door handle j) Radiator grille RC350/RCF...
Page 14: Engine Oil Level Dipstick
INSPECTION DETAILS - A. ENGINE COMPARTMENT ENGINE HOOD RELEASE LEVER Use the engine hood release lever to check that the latch operates properly. Ensure that the engine hood opens and closes smoothly. RC350 shown (RCF similar) ENGINE OIL LEVEL (ENGINE NOT RUNNING) a) Remove the engine oil level dipstick and wipe it clean. Reinsert the dipstick and pull it out to check the oil level. The level should be between the two marks. Low Normal Excessive b) Check the oil for dirt or impurities. NOTE: If the oil level is low, add specified engine oil and check for oil leaks. RC350 shown (RCF similar) BRAKE FLUID LEVEL Visually check the fluid level through the reservoir. If the fluid level is low, replenish the brake fluid reservoir with FMVSS No. 116 DOT 3, FMVSS No. 116 DOT 4 or SAE J1703 brake fluid and check for fluid leaks. Brake fluid level should be at the “MAX” line (within 0.2 inches [5.0 mm] below).
Page 15: Battery
INSPECTION DETAILS - A. ENGINE COMPARTMENT BATTERY TERMINAL TIGHTNESS AND CHARGE a) Check the electrolyte level. If the electrolyte level is low, check the battery case for leakage. b) Check the battery charge. Measure the open-circuit battery voltage between the terminals. If the voltage reading is less than 12.6 volts, recharge the battery. NOTE: Before measuring the voltage, turn off the engine and all electrical systems. Wait 60 seconds to remove the surface charge. If the engine was running before measuring the voltage, wait 20 minutes after the engine stops to remove the surface charge. c) Check that the battery terminals are properly connected and that the clamp is firmly installed. Terminals Hold-down clamp RC350 ENGINE COOLANT LEVEL Visually check the coolant level through the coolant reservoir tank when the engine is cool. The coolant level is satisfactory if the level is between the “FULL” and “LOW”. Reservoir cap “FULL” “LOW” Only use “Toyota Super Long Life Coolant.” CAUTION: To prevent burning yourself, do not remove the radiator cap when the engine is hot.
Page 16 INSPECTION DETAILS - A. ENGINE COMPARTMENT RC350 shown (RCF similar) WASHER FLUID LEVEL Open the washer tank cap and visually check the washer fluid level in the washer tank. The fluid level should be filled within 2 inches of the cap. WIRING AND HOSES a) Check the hoses, hose connectors and various clamps for tightness. b) Visually inspect the condition of all harness connectors and terminals for proper installation and tightness. RC350/RCF...
Page 17: B. Locks And Lights
INSPECTION DETAILS - B. LOCKS AND LIGHTS WIRELESS REMOTE CONTROL Inspect the five functions of the system. Locks the doors Unlocks the doors Opens the trunk (Press and hold) Sounds alarm (Press and hold) a) Locking the doors 1. Close all the doors. 2. Press on the electronic key to lock all the doors from outside the vehicle. NOTE: When is pressed to lock doors, a beep will sound and all turn signal lights will flash once. However, if any door is not closed securely, pressing will cause the buzzer to sound continuously until all doors are properly closed. b) Unlocking the doors 1. Press on the electronic key once to unlock the driver’s door.
Page 18: Theft Deterrent System
INSPECTION DETAILS - B. LOCKS AND LIGHTS SMART ACCESS SYSTEM a) With electronic key inside of the vehicle, touch the lock sensor (on the upper part of the door handle) and trunk lock button. Check that the buzzer sounds and that the doors do not lock. b) Take the electronic key and get out of the vehicle. Touch the lock sensor (on the upper part of the door handle). Check that the door locks. NOTE: Recognition signals for the lock operation will operate up to two consecutive times. c) From a distance of at least 2.3 ft. (0.7 m), approach the vehicle and pull the driver and passenger side door handles, and the trunk opener. Check that the door unlocks. NOTE: The doors cannot be unlocked for 3 seconds after the doors are locked. THEFT DETERRENT SYSTEM With the doors locked, check that the system operates properly. System Test: a) Open the windows. b) Lock the doors by smart access system, wireless remote control or mechanical key. Be sure to wait until the security light on the center panel starts flashing. c) Unlock one of the doors using the inside door lock. The system should activate the alarm (sounding of the horn, blinking of the headlights, tail lights and emergency flasher, lighting up interior light).
Page 19: Remote Engine Starter
INSPECTION DETAILS - B. LOCKS AND LIGHTS DOOR LOCK SYSTEM AND ILLUMINATED ENTRY SYSTEM a )Check that all doors open and close smoothly using the inside and outside door handles. b )Check that the doors cannot be opened by using the inside and outside door handles when the lock button is in the locked position (except front inside door handles). c )For front inside door handles: Check that the front doors can be opened by using the inside door handles when the lock button is in the lock position. d )Check exterior key lock control system operation by mechanical key (with driver’s door). Locks both side doors Unlocks the door (two-step unlock function): 1. Turn the key once to unlock the driver’s door. 2. Turn the key twice to unlock all the doors. e) Check that the outer footlight illuminates when the door is opened. OUTER FOOTLIGHT REMOTE ENGINE STARTER* a )Starting the Engine 1. Close and lock all doors. 2. Quickly press twice and then press and hold for 3 seconds.
Page 20: Engine Switch
INSPECTION DETAILS - B. LOCKS AND LIGHTS RC350 shown (RCF similar) POWER SUPPLY CHANGEOVER AND ENGINE START/STOP Check for proper activation of the “ENGINE” switch. Power supply changeover a) Carry the electronic key in the vehicle and apply the parking brake. b) Without depressing the brake pedal, press the “ENGINE” switch and change the power supply. OFF Press once: ACCESSORY mode Press twice: ”IG-ON” mode c) In each mode, check that the power supply has changed properly. Engine start/stop a) Carry the electronic key in the vehicle and apply the parking brake. b) Check that the shift lever is in the“P” position. c) While depressing the brake pedal, press the “ENGINE” switch. EXTERIOR LIGHTS Walk around the vehicle and check that the following lights illuminate: a) Headlights b) Parking lights and daytime running lights c) Front side marker lights d) Side turn signal lights...
Page 21: Turn Signal Lever
INSPECTION DETAILS - B. LOCKS AND LIGHTS TURN SIGNAL, HEADLIGHT, HIGH BEAM, AUTOMATIC HIGH BEAM*, FOG LIGHTS* AND EMERGENCY FLASHER INDICATOR LIGHTS a )Check that the turn signal indicator lights on the instrument panel illuminate when the turn signal lever is moved up or down. Right turn Move and hold the lever partway to signal a lane change (Right) Move and hold the lever partway to signal a lane change (Left) Left turn b )Check operation of the headlight switch. The side marker, tail, license plate and instrument panel lights turn on. The headlights and all lights listed above turn on. The headlights, daytime running lights and all the lights listed above turn on and off automatically.
Page 22: Emergency Flasher Switch
INSPECTION DETAILS - B. LOCKS AND LIGHTS e) Check operation of the automatic high beam* switch. f) Check that the front fog lights illuminate when the switch* is turned on with the headlights on. OFF g) Check that the turn signal lights and turn signal indicator lights blink when the emergency flasher switch is on. HEADLIGHT AIM If headlight aim is not correct, see Repair Manual for headlight aim procedure. * If equipped RC350/RCF...
Page 23: C. Left Front
INSPECTION DETAILS - C. LEFT FRONT INTERIOR PARTS FOR DAMAGE AND FIT Visually inspect the following interior parts for dirt, damage, and proper fit and alignment: a) Instrument panel, dashboard and glove box b) Roof headliner, pillar, roof side garnish and sun visors c) Door trim and quarter trim panels d) Seat upholstery and floor carpeting e) Console box f) Steering wheel FLOOR MATS Check that the floor mats are designed specifically for this car. Fix them securely in place onto the carpet. PRE-COLLISION SYSTEM* Check that the “PCS” warning light turns on when pre-collision is disabled. Pre-collision system enabled. Pre-collision system disabled. * If equipped RC350/RCF...
Page 24: Seat Belt
INSPECTION DETAILS - C. LEFT FRONT GS shown (RC similar) ON-BOARD DIAGNOSTIC SYSTEM OPERATION Using the “Techstream,” check the on-board diagnostic system function. For details of this procedure, refer to the engine troubleshooting section of the Repair Manual. SEAT BELT Check seat belt operation. a) Check that the belt extends and retracts smoothly. b) Check that the belt is not twisted. c) Check that the buckle locks securely and releases smoothly. RC350 RC350/RCF...
Page 25 ONE-TOUCH WALK-IN INITIALIZATION (Both front seats) Adjust seat cushion to rearmost & lowest position. Use 1-touch walk-in lever to move seat forward. Push seatback back, confirm seat returns.
Page 26: Driving Position Memory System
INSPECTION DETAILS - C. LEFT FRONT DRIVING POSITION MEMORY SYSTEM* a) With the “ENGINE” switch in the “IG-ON” mode and the shift lever in the “P” position, check the operation: 1. Adjust the driver’s seat and outside rearview mirrors to the desired positions. 2. While pressing the “SET” button, press down the button “1,” “2” or “3” until a beep is heard. 3. Check all buttons (1, 2 and 3) to make sure that all memorized settings operate correctly. b) With the shift lever in the “P” position, close the driver’s door and turn the “ENGINE” switch to “IG-ON” mode. 1. Register a driving position to the button “1,” “2” or “3.” 2. Do not carry more than one key (including a card key*) when registering. While pressing the button “1,” “2” or “3,” press the driver’s door lock switch (either lock or unlock switch) until a signal beeps. 3. Unlock the driver’s door using the entry function or wireless remote control, open the driver’s door, and check that the stored driving position is recalled. * If equipped RC350/RCF...
Page 27: Window Lock Switch
INSPECTION DETAILS - C. LEFT FRONT POWER WINDOWS AND DOOR LOCKS a) With the “ENGINE” switch in the “IG-ON” mode, operate the power window switch. Check that the power window up and down operation is smooth. Closing One-touch closing Opening One-touch opening b) Check that the windows (other than the driver’s window) cannot be operated when the window lock switch is on. c) Check operation of the power door lock switch. Locks both side doors Unlocks both side doors d) With the doors closed, check that the power windows can be fully operated after the “ENGINE” switch has been switched to the ACCESSORY or OFF mode. NOTE: This feature is canceled after 45 seconds or if either front door is opened. RC350/RCF...
Page 28: Interior Light
INSPECTION DETAILS - C. LEFT FRONT OUTSIDE REARVIEW MIRRORS a) Check power outside rearview mirrors operation with the “ENGINE” switch in the ACCESSORY or “IG-ON” mode. 1. Press the master switch “L” (left) and “R” (right) and press the control switch in the desired direction (up, down or side-to-side). Check that the mirrors operate smoothly. b) Check the operation of the mirror defoggers. Press the rear window and outside rearview mirror defogger switch with the “ENGINE” switch in the “IG-ON” mode, check by hand that the rear window and rearview mirrors become hot. WINDSHIELD WIPER DE-ICER* Check the windshield wiper de-icer operation with the “ENGINE” switch in the ACCESSORY or “IG-ON” mode. INTERIOR LIGHTS Check operation of the following interior lights: Outer footlights Personal lights Front interior light Ambient lights Rear interior light Door courtesy lights Footwell lights * If equipped RC350/RCF...
Page 29: Trunk Opener
INSPECTION DETAILS - C. LEFT FRONT ODOMETER AND TRIP METER DISPLAY Check operation of the odometer and trip meter display switch. INSTRUMENT PANEL LIGHT CONTROL Check that the instrument panel light control switch operates properly. Darker Brighter IS shown (RC similar) BLIND SPOT MONITOR* With the “ENGINE” switch in the “IG-ON” mode, check that the switch’s indicator light illuminates when the switch is pressed. BSM main switch Outside rearview mirror indicator Rear cross traffic alert buzzer TRUNK OPENER BUTTON Check operation of the trunk opener button. * If equipped RC350/RCF...
Page 30: Windshield Wipers And Washer
INSPECTION DETAILS - C. LEFT FRONT WINDSHIELD WIPERS AND WASHER With the “ENGINE” switch in the “IG-ON” mode: a) Push the lever toward you and check that washer fluid squirts onto the proper area of the windshield and that wipers are activated. Wipers will make one additional pass after a 3-second delay. Intermittent Type b) Check wiper speed operation on mist, intermittent, low and high cycles. Check that the wiper blades wipe off the washer fluid cleanly. c) The wipers should not make any abnormal noise when operating. NOTE: • Intermittent Type --- The frequency of the intermittent wiper can be adjusted by turning the knob. • Rain-Sensing Type --- The sensitivity of the sensor can be adjusted by turning the knob. • Add washer fluid up to the proper level. Rain-sensing Type Rain-Sensing Type d) With the wiper switch lever in the “AUTO” position, splash the water on the windshield around the windshield sensor and check that the wipers operate. RC350/RCF...
Page 31 INSPECTION DETAILS - C. LEFT FRONT RC350 WARNING LIGHTS AND INDICATOR LIGHTS a ) With the “ENGINE” switch in the “IG-ON” mode, check that each warning and/or indicator light operates properly. b ) With the “ENGINE” switch in the “IG-ON” mode, check that the following warning and/or indicator lights turn on and then go off after a few seconds: • Brake system warning light • Seat belt reminder • SRS airbag warning light • Charging system warning light RC350 F Sport • Malfunction indicator lamp • Master warning light • ABS warning light • PCS (Pre-Collision System) warning light* • Tire pressure warning light • Open door warning light • Electric power steering system warning light • Low fuel level warning light • Slip indicator light • Automatic headlight leveling system warning light Refer to “Warning Lights and Buzzers” on page 20 for details. * If equipped RC350/RCF...
Page 32 INSPECTION DETAILS - C. LEFT FRONT Warning Light and Buzzer Light/Buzzer Function/Condition Brake system warning light Brake System Warning • Low brake fluid Light and buzzer • Malfunction in the brake system Indicates a malfunction in the parking brake Brake System Warning system Light The driver’s and front passenger’s seat belt...
Page 33 INSPECTION DETAILS - C. LEFT FRONT Light/Buzzer Function/Condition A buzzer sounds and the warning light comes on or flashes to indicate that the master warning system has detected a Master Warning Light malfunction. If the master warning light comes on, a message appears on the multi-information display.
Page 34 INSPECTION DETAILS - C. LEFT FRONT Light/Buzzer Function/Condition Low Fuel Level Warning Indicates remaining fuel is approximately Light 2.6 gal. (10.0L, 2.2 lmp.gal.) or less Indicates a malfunction in: • Vehicle stability control Slip indicator light • Traction control • Hill-start assist control Indicates a malfunction in the automatic Automatic headlight leveling system warning...
Page 35 INSPECTION DETAILS - C. LEFT FRONT RC350 (except F Sport models) WARNING MESSAGE (on the Multi- Information Display) The multi-information display shows system malfunctions, incorrectly performed operations, or messages that indicate a need for maintenance. The master warning light comes on or flashes when a message is being shown on the multi-information display. Multi-information display RC350 (F Sport models: Main meter in center position) RC350 (F Sport models: Main meter moved to the right) RC350/RCF...
Page 36: Tilt And Telescopic Steering Wheel
INSPECTION DETAILS - C. LEFT FRONT MULTI-INFORMATION DISPLAY The multi-information display provides information on vehicle driving conditions and warning messages. Switch menu, Scroll up/down the screen and move/ up/down the cursor Press: Enter/Set Press and hold: Reset Return to previous screen (Except F Sport models) Move the main meter NOTE: Refer to the multi-information display section in the vehicle’s Owner’s Manual for a comprehensive list of the system’s functions and displays. TILT AND TELESCOPIC STEERING WHEEL Check steering wheel adjustment operation: a) Power adjustment* Down Toward the driver Away from the driver b) Manual adjustment Hold the steering wheel and push the lever down to set the steering wheel in the desired position. * If equipped RC350/RCF...
Page 37 INSPECTION DETAILS - C. LEFT FRONT Navigation system AIR CONDITIONING AND HEATER Warm up the engine and check for smooth operation of each control: Press the “MENU” button. Select “Climate” and push the touchpad* or remote touch knob* to display icons for automatic air conditioning control. a) Select high fan speed and set the temperature to 85 °F (29.5 °C) with the “TEMP” button. b) Press the windshield defogger button and check that hot air flows out of the front defroster vents. c) Select “FOOT” air flow mode and check that hot air flows out of the foot vents. d) Check that the airflow volume changes when the fan speed button is pressed. e) Press the “AUTO” button followed by the “DUAL” Display Audio system button (indicator on) and lower the temperature of the driver’s side by pressing the “TEMP” button. f) Set the temperature of the driver’s side to 65 °F (18.5 °C). g) Check that the display of the airflow mode and the air flow volume changes automatically by changing the temperature in auto mode. h) Check that the temperature of the passenger side remains at 85 °F (29.5 °C). i ) Select “FACE” air flow mode. j) Check that cool air flows out of the driver’s side center vent and hot air flows out of the passenger’s side center vent.
Page 38: Audio System
INSPECTION DETAILS - C. LEFT FRONT SET CLOCK Set the clock to the proper time. Press and hold to move the clock hands backward. Press and hold to move the clock hands forward. AUDIO SYSTEM a) With the “ENGINE” switch in the ACCESSORY or “IG-ON” mode, press the “RADIO” or “AUDIO” button and check for proper operation of both AM and FM stations. b) Preset all the station memory buttons to local broadcast frequencies. c) Check that XM audio is active. d) CD player should be inspected for proper operation. e) USB and AUX port should be inspected for proper operation. RC350/RCF...
Page 39: Talk Switch
INSPECTION DETAILS - C. LEFT FRONT STEERING WHEEL AUDIO SWITCHES With the “ENGINE” switch in the ON mode, check the following switches: Volume switch Radio mode “MODE” switch STEERING WHEEL SWITCHES Check the following steering wheel switches: Volume switch Off hook switch On hook switch Talk switch RC350/RCF...
Page 40 LEXUS NAVIGATION SYSTEM* a) With the “ENGINE” switch in ACCESSORY or “IG- ON” mode check that the initial “LEXUS” screen appears for a few seconds and then changes to the “CAUTION” screen. NOTE: “CAUTION” screen appears if map or destination screen was displayed during last use. b) Press the “MENU” button and select the “Climate”, “Nav”, “App Suite”, “Info”, “Radio”, “Media”, “Phone”, and “Setup” icon. Push the touchpad and check that the display changes. NOTE: After about 5 seconds, the “CAUTION” screen automatically switches to the map screen. When the “MAP/VOICE” button is pressed, the map screen is displayed. LEXUS DISPLAY AUDIO SYSTEM* a) With the “POWER” switch in the ACCESSORY or ON mode, check that the initial “LEXUS” screen appears. b) Press the “MENU” button and select the “Climate”, “Phone”, “Info”, “Setup”, “Radio”, “Media” and “Display” icon. Push the controller knob and check that the display changes. ® XM NAVWEATHER This service is active on all new Lexus vehicles with navigation systems. To confirm activation, press the “MENU” button, select “Info” then select “Weather”. NOTE: If service is currently unavailable, the navigation screen will show the following pop-up message: “XM signal not available or active XM subscription needed.” This means one of the following: a) XM tuner is looking for active subscription confirmation from XM.
Page 41: Intuitive Parking Assist Switch
INSPECTION DETAILS - C. LEFT FRONT INTUITIVE PARKING ASSIST* This procedure is performed by placing safety cones at 6 points: a) With the “ENGINE” switch in the “IG-ON” mode, press the intuitive parking assist switch. b) Check that the indicator light illuminates and the buzzer sounds. c) The safety cones gradually approach the vehicle. About 3.3 ft. (100 cm) About 4.9 ft. (150 cm) About 2.0 ft. (60 cm) About 1.6 ft (55 cm) d) Check that the buzzer sounds and the indicator bar is displayed on the screens. Front corner sensor operation Front center sensor operation Rear corner sensor operation Rear center sensor operation * If equipped RC350/RCF...
Page 42: Active Rear Wing Switch
INSPECTION DETAILS - C. LEFT FRONT ACTIVE REAR WING (RCF)* With the “ENGINE” switch in the “IG-ON” mode and the trunk closed, operate the active rear wing switch to raise/ retract the active rear wing manually. Multi-information display Active rear wing switch Indicator CUP HOLDERS Check that the cup holders do not make noise during operation. CONSOLE BOX Check that the console box opens and closes smoothly and that it does not make any noise during operation. POWER OUTLET (12V) With the “ENGINE” switch in the ACCESSORY or “IG-ON” mode, check the power outlet using an electrical accessory designed for this use. * If equipped RC350/RCF...
Page 43: Sun Visors
INSPECTION DETAILS - C. LEFT FRONT SEAT HEATERS* With the “ENGINE” switch in the “IG-ON” mode, check that the indicator light comes on when the dials are moved. SEAT VENTILATORS* With the “ENGINE” switch in the “IG-ON” mode, check that the indicator light comes on when the dials are moved. HEATED STEERING WHEEL* With the “ENGINE” switch in the “IG-ON” mode, check that the steering wheel heats when the heater button is pressed. SUN VISOR AND VANITY MIRROR a) Check that the sun visor is easy to use: Flip down Unhook and swing to the side Slide extender * If equipped RC350/RCF...
Page 44: Inside Rearview Mirror
INSPECTION DETAILS - C. LEFT FRONT b) Slide the cover and check that the vanity light comes on. MOONROOF* With the “ENGINE” switch in the “IG-ON” mode, check for smooth operation and any unusual noise. a) Check the tilt function - up and down. b) Check the automatic open function of the moonroof by pressing and holding the moonroof switch in the open direction for one second, release the switch. c) To close the moonroof, hold the moonroof switch in the close direction for one second, release the switch. The moonroof should automatically slide to the forward position. Push and hold to fully close. d) The sun shade can be opened or closed manually; however, the sun shade will automatically open with the moonroof. ANTI-GLARE INSIDE REARVIEW MIRROR Check that the anti-glare function switch operates properly. * If equipped RC350/RCF...
Page 45: Sos Button
INSPECTION DETAILS - C. LEFT FRONT HomeLink ® GARAGE DOOR OPENER* Check the HomeLink garage door opener by pressing each ® of the three buttons and observing that the indicator light illuminates. Final operational check requires programming. Indicator light Garage door operation indicators Homelink Icon Buttons ®* SAFETY CONNECT Inspect the Safety Connect LED, (located in the overhead console) for a green activation status indicator. If green LED is not illuminated, press the SOS button once, wait for voice prompt, and press the button again within 5 seconds. If successful, tones will be heard followed by voice prompt saying “Activation is complete - Good bye”. Green light will illuminate after call has ended. If the green light does not illuminate, please refer to TIS for troubleshooting procedures. SOS button LED light indicator Microphone NOTE: Vehicles may arrive with hanger requesting inspection to Safety Connect system. If system is working properly and green light is illuminated, disregard hanger. COMPASS* Calibrate compass. See TSIB.
Page 46: D. Left Rear
INSPECTION DETAILS - D. LEFT REAR SEAT BELT Check seat belt operation. a) Check that the belt extends and retracts smoothly. b) Check that the belt is not twisted. c) Check that the buckle locks securely and releases smoothly. REAR SEAT HEAD RESTRAINT Check that the head restraint operates smoothly. REAR CUP HOLDERS* Check that the cup holders open and close smoothly and that they do not make noise during operation. ARMREST* Check that the center armrest operates smoothly. * If equipped RC350/RCF...
Page 47: Trunk Storage Extension
INSPECTION DETAILS - D. LEFT REAR TRUNK STORAGE EXTENSION* Check that the armrest door can be locked and unlocked using the mechanical key. FOLDING REAR SEAT BACKS* Check that the rear seat backs can be folded down. * If equipped RC350/RCF...
Page 48: E. Trunk
INSPECTION DETAILS - E. TRUNK FUEL DOOR Check that the fuel door opens and closes smoothly. (Vehicle must be unlocked.) TRUNK a) Check that the trunk unlocks using the exterior button. b) Check that the trunk cannot be unlocked by pressing the back door opener button when all the doors are locked by power door lock switch, wireless remote control, smart access system or key. c) Check that the luggage compartment light comes on when the trunk is opened. Spare tire, jack and tools TOOLS, JACK AND JACK HANDLE Check that the tools, jack, jack handle, spare tire* and emergency repair kit* are properly installed. Tire puncture repair kit, jack and tools * If equipped RC350/RCF...
Page 49 INSPECTION DETAILS - E. TRUNK TEMPORARY SPARE TIRE PRESSURE Check and adjust spare tire air pressure: or bar) TYPE A T155/70D17 110M: 60 psi (420 kPa, 4.2 kgf/cm TYPE B T145/70D18 107M: 60 psi (420 kPa, 4.2 kgf/cm or bar) TRIM APPEARANCE AND LUGGAGE CARPET FIT Inspect the luggage trim and luggage carpet for proper installation and appearance. LUGGAGE SECURITY SYSTEM* Check that the luggage security system operates properly. * If equipped RC350/RCF...
Page 50: F. Right Rear
INSPECTION DETAILS - F. RIGHT REAR SEAT BELT Check seat belt operation. a) Check that the belt extends and retracts smoothly. b) Check that the belt is not twisted. c) Check that the buckle locks securely and releases smoothly. REAR SEAT HEAD RESTRAINT Check that the head restraint operates smoothly. RC350/RCF...
Page 51: G. Right Front
INSPECTION DETAILS - G. RIGHT FRONT POWER WINDOW AND DOOR LOCKS a) With the “ENGINE” switch in the “IG-ON” mode, operate the power window switch. Check that the power window up and down operation is smooth. b) Check operation of the power door lock switch. c) With the doors closed, check that the power window can be fully operated after the “ENGINE” switch has been switched to the ACCESSORY or OFF mode. NOTE: This feature is canceled after 45 seconds or if either front door is opened. SEAT BELT Check seat belt operation. a) Check that the belt extends and retracts smoothly. b) Check that the belt is not twisted. c) Check that the buckle locks securely and releases smoothly. d) Check that the adjustable seat belt anchor operates properly and that it securely locks in position. RC350/RCF...
Page 52 ONE-TOUCH WALK-IN INITIALIZATION (Both front seats) Adjust seat cushion to rearmost & lowest position. Use 1-touch walk-in lever to move seat forward. Push seatback back, confirm seat returns.
Page 53: Glove Box
INSPECTION DETAILS - G. RIGHT FRONT SUN VISOR AND VANITY MIRROR a) Check that the sun visor is easy to use: Flip down Unhook and swing to the side b) Slide the cover and check that the vanity light comes on. GLOVE BOX Check that the glove box opens and closes smoothly and that it does not make any noise during operation. Open Unlock Lock TRUNK OPENER MAIN SWITCH Check that the trunk opener disable switch operates properly. Off RC350/RCF...
Page 54: H. Front Bumper
INSPECTION DETAILS - H. FRONT BUMPER FRONT LICENSE PLATE Front License Plate & Mounting Bracket Installation. Refer to Service Bulletin. RC350/RCF...
Page 55 INSPECTION DETAILS - I. UNDER VEHICLE (SAFETY/DAMAGE) BEFORE LIFTING VEHICLE WHEEL LUG NUT TORQUE (Should be checked if wheels have been taken off.) Using a torque wrench, tighten all wheel lug nuts to the specified torque in the order of the numbers in the illustration to the left. Torque specifications: 76 ft-lbf (103 N•m, 10.5 kgf•m) INSTALL WHEEL CENTER CAPS Install the wheel center caps on the wheels. TIRES Visually inspect all tires for damage and/or defects. RC350/RCF...
Page 56 INSPECTION DETAILS - I. UNDER VEHICLE (SAFETY/DAMAGE) AFTER LIFTING VEHICLE REMOVE WHEEL FILM Visually inspect rotors for rust. NOTE: For the best rotor rust prevention, retain wheel film on vehicle until just prior to customer delivery. If leakage is found, see Repair Manual. CHASSIS INSPECTION FOR LEAKAGE OR DAMAGE a )Visually and by hand check the following components for proper installation, clamping, connection and damage: • Brake lines, hoses and protectors • Fuel lines, hoses and protectors • Steering linkage and dust boots • Drive shaft boots • Parking brake cable b )Visually check the following components for fluid leakage: • Engine • Transmission • Brake lines • Fuel lines c )Visually check the entire underside of the body for proper rust-resistant coating.
Page 57: I. Under Vehicle (Safety/Damage)
INSPECTION DETAILS - I. UNDER VEHICLE (SAFETY/DAMAGE) FLUID LEAKS a) Engine (cylinder head and around the head cover) b) Brake lines and hoses c) Radiator and hoses d) Fuel lines and hoses e) Transmission f) Front shocks g) Front differential* h) Transmission RUBBER BODY PLUGS Install the rubber body plugs into the torque box holes. NOTE: Plugs are shipped with the vehicle and put in the glove compartment. GS shown (RC similar) EXHAUST SYSTEM Visually check for leaks and damage to the exhaust pipes and mufflers. Ensure they are properly installed. Softly hit cold pipes with fist FLUID LEAKS a) Rear brake system b) Rear shocks c) Rear differential * If equipped RC350/RCF...
Page 58: J. Road Test
INSPECTION DETAILS - J. ROAD TEST BOTT DOT ROAD TEST LAYOUT As part of the PDS road test, the vehicle must be driven over a rough road surface or over Bott Dots in order to check for squeaks and rattles. If a rough surface is not available for this road test, Bott Dots should be installed on the dealership property where vehicles can be safely driven 5 to 10 mph. (See Bott Dots installation instructions below, as recommended and provided by TMC Quality Division.) Bott Dots are available at industrial supply outlets. RC350/RCF...
Page 59: Rearview Monitor System
INSPECTION DETAILS - J. ROAD TEST A comprehensive road test is vital in order to ensure that a perfect automobile is delivered to a Lexus customer. We recommend that you map out a specific road test course that includes a variety of road conditions including stop and go, highway speed and rough road surfaces.
Page 60: Electric Cooling Fans
INSPECTION DETAILS - J. ROAD TEST ENGINE OPERATION COLD AND HOT ENGINE SYSTEM OPERATION WHILE DRIVING a) Check engine performance over a broad range of driving conditions including acceleration, cruising and deceleration. b) Make sure engine operation is smooth and responsive. c) Make sure the gauges, speedometer and engine Indicator operations are smooth and accurate. ELECTRIC COOLING FANS a )Check that the engine cooling fans rotate smoothly. CAUTION: The engine cooling fans are controlled depending on engine coolant temperature. Do not touch the fans when the engine is hot. b) Turn the air conditioning on and build up sufficient pressure. Check that the electric cooling fans turn on and rotate smoothly. CAUTION: The electric cooling fans are controlled depending on air conditioning refrigerant pressure. Do not touch the fans when the “A/C” switch is turned on. RC350 shown (RCF similar) PARKING BRAKE Check brake effort. Check for pull or any abnormal noise.
Page 61 INSPECTION DETAILS - J. ROAD TEST IF PEDAL DOES NOT OPERATE CORRECTLY, USE REPAIR MANUAL TO CHECK, ADJUST, AND TROUBLESHOOT. See repair manual if needed. HEADLIGHTS TRANSMISSION OPERATION LANE DEPARTURE ALERT* Check that the indicator light illuminates on the multi- information display when the switch is pressed and released. * If equipped RC350/RCF...
Page 62: Vehicle-To-Vehicle Distance Button
INSPECTION DETAILS - J. ROAD TEST CRUISE CONTROL* a )Check the cruise control functions: • ON-OFF • SET • RES • CANCEL b )Check that the preset speed is canceled by: • Depressing the brake pedal • Using cancel switch and “ON-OFF” button For details regarding the operation of the cruise control, refer to the Owner’s Manual. RC350 shown (RCF similar) Dynamic Radar Cruise Control System* c) Press the “ON-OFF” button and check that the indicator in the instrument cluster comes on and “RADAR “READY” appears on the multi-information display. (Vehicle to vehicle distance control mode) d) Check that cruise control mode is changed between vehicle to vehicle distance control mode and conventional (fixed speed) control mode by pressing the cruise control lever for longer than about 1 second. (Indicator in the instrument cluster comes on) Vehicle-to-vehicle distance button Display Set speed Indicators Cruise control switch...
Page 63: Tvd Switch
INSPECTION DETAILS - J. ROAD TEST DRIVING MODE SELECT Check that the driving modes operate properly. Vehicles without AVS Normal mode Eco driving mode Check that the indicator light illuminates on the display. Sport mode Check that the indicator light illuminates on the display. Vehicles with AVS Normal mode Eco driving mode Check that the indicator light illuminates on the display. Sport mode, Sport S + mode Check that the indicator light illuminates on the display. SNOW MODE Check that the indicator light illuminates on the multi- information display when the switch is pressed. TORQUE VECTORING DIFFERENTIAL* Check that the TVD switch changes the TVD control mode properly. STANDARD mode SLALOM mode TRACK mode * If equipped RC350/RCF...
Page 64: Vsc Off Switch
INSPECTION DETAILS - J. ROAD TEST RC350 shown (RCF similar) TRAC AND/OR VSC SYSTEM a) Turning off the TRAC system Check that the indicator light illuminates on the multi- information display when the switch is quickly pressed and released. b) Turning off the TRAC and VSC systems Check that the indicator light illuminates on the multi- information display when the switch is pressed and held for more than 3 seconds. c) Set the VSC off switch “ON”. STEERING OPERATION AND OFF-CENTER a) Check steering for smooth turning operation and any unusual noise. b) Check that the steering wheel is correctly aligned when driving on a level road surface. NOTE: For details about adjustment and inspection, refer to the Repair Manual. AIR CONDITIONING AND HEATER FUNCTIONS SQUEAKS AND RATTLES Check for squeaks and rattles in the followings: a) Instrument panel b) Doors...
Page 65 INSPECTION DETAILS - J. ROAD TEST ABNORMAL NOISE OR VIBRATION Check for vibration or abnormal noise while the vehicle is in motion. a) Wind noise b) Power train (engine) c) Road noise (tires) d) Other e) RC350 - operate Active Sound Control* Loud BRAKE LIGHTS AND BACKUP LIGHTS CHECK HORN TURN OFF RADIO, AIR CONDITIONING, SEAT HEATERS, LIGHTS GS shown (RC similar) OWNER’S MANUALS AND PORTFOLIO a) Place the Quick Guide booklet in the glove box.
Page 66: Completion
COMPLETION COMPLETION RC350/RCF...
Page 67 Floor Mat Installation see TSIB, p.2 I have attended the "Technical Introduction to Lexus Course L005" at the Lexus Area Office. I have read and understand the PDS Manual, PDS precautions, and applicable PDS TSIBs. I have lifted the vehicle and performed under vehicle safety/damage inspection. I have road tested vehicle long enough to test hot engine and driven over rough road/Bott dots to test for rattles/squeaks.
Page 68 • Contact your Dealership’ s Lexus Technology Specialist. • Find resources and “How-to” videos by: - Visiting www.LexusDrivers.com and selecting “My Lexus. ” - Downloading the free My Lexus and Beyond App to your smart device and selecting “My Lexus. ” (Initially available for iPhone and iPad .
Page 69: Index
INDEX Technical Service Information Engine hood release Rubber body plugs Bulletins Available on TIS Engine transmission operation 47 Safety Connect D/CCut Fuse Installation during PDS Engine oil level Seat adjustment 13, 40 Initial Calibration of Compass Exterior lights Seat belt 12,34,38,39 during PDS Exhaust system Seat heaters/ventilators Front License Plate & Mounting Bracket Installation Floor Mats Smart Access system Fog lights Snow mode Front Wheel Opening Extension Pad Installation during PDS Folding rear seat backs Spare tire pressure Tire Pressure Warning System Fuel door Steering wheel switches Initialization Glove box...
