Type 5610 Infra-red Fire & Heat Detector
Issue
1
Patol Limited
Series 5000 - Manual 5610
Series 5000
SPECIFICATION
INSTALLATION - COMMISSIONING
OPERATION - MAINTENANCE
Document Ref : D1198
Change
Original
D1198 - Issue 1 - 25 September 2013
Patol Limited
Date
25/09/13
Rectory Road, Padworth Common, Reading,
Berkshire.
RG7 4JD
Tel : +44 (0) 118 9701 701
Fax : +44 (0) 118 9701 700
Email : info@patol.co.uk
Web : www.patol.co.uk
Remarks
Approved RJJ
United Kingdom.
Page 1 of 16
Advertisement
Table of Contents
Related Manuals for Patol 5610
Summary of Contents for Patol 5610
- Page 1 Patol Limited Series 5000 Type 5610 Infra-red Fire & Heat Detector SPECIFICATION INSTALLATION - COMMISSIONING OPERATION - MAINTENANCE Document Ref : D1198 Issue Change Date Remarks Original 25/09/13 Approved RJJ Rectory Road, Padworth Common, Reading, Berkshire. RG7 4JD United Kingdom.
-
Page 2: Table Of Contents
Unit Set Up Power Up Procedure Hot Body Simulation Tests OPERATION Normal Alarm Condition Reset Fault Warning Test MAINTENANCE General Fault Monitoring Functions Infra-red Detection Series 5000 - Manual 5610 D1198 - Issue 1 - 25 September 2013 Page 2 of 16... -
Page 3: Introduction
Patol Limited INTRODUCTION General The Patol 5000 Series of equipment is specifically designed for the protection of establishments and systems where a movement of materials with a potential fire hazard is a routine occurrence. The 5610 Detector employs enhanced Infra-red monitoring technology that enables the detection of fire initiating materials, whilst they are being transported, and before they have reached a flame condition. -
Page 4: Equipment Detail
The height and angle of the sensor determine the width of the monitored path. The Type 5610 Detector case is equipped with a 10mm hose fitting for connection of a compressed air supply. This is required such that a positive air pressure is maintained around the unit’s sensor “windows”. - Page 5 The unit can also be employed with the two wire connection to a remote Patol signal relay module.
-
Page 6: Sensor Arrangement
Purge Air Supply:- Pressure : 175 to 700 mBar (2.5 psi to 10 psi) Minimum Delivery : 30 litres / min Input Fitting : 10mm Compressed Air Hose Adaptor Series 5000 - Manual 5610 D1198 - Issue 1 - 25 September 2013 Page 6 of 16... - Page 7 25mm Dia. 4.9 sq cm monitored material, sensor orientation and target speed. 900 1000 Temperature Degrees C GLOWING / VISIBLE Series 5000 - Manual 5610 D1198 - Issue 1 - 25 September 2013 Page 7 of 16...
-
Page 8: Operational Programmability - Sil Switch
All detections auto-reset after scan period Table 2. Table 3. Pole AUTO RESET DELAY - SCAN PERIOD Pole SENSITIVITY (A=Most : D=Least) 2.6s 1.3s 0.9s 0.6s Series 5000 - Manual 5610 D1198 - Issue 1 - 25 September 2013 Page 8 of 16... -
Page 9: Connections
RESET ALERT Refer 2.7.3 to 2.7.6 SHOWN SHOWN NORMAL IN FAULT TRIP ALARM FAULT FIRE Operation Selection Pressure Switch CONTACTS DISABLED Fig. 9 Series 5000 - Manual 5610 D1198 - Issue 1 - 25 September 2013 Page 9 of 16... - Page 10 2/7. The voltage and current of the device must be appropriate to the alarm current parameter and load characteristic of the control equipment monitoring (trigger) circuit. Series 5000 - Manual 5610 D1198 - Issue 1 - 25 September 2013 Page 10 of 16...
-
Page 11: Installation
Supply / Signal Cable The Type 5610 Detector outer case has 3 x 20mm cable entries as standard, Cable terminations are made at rising clamp screw terminal connectors located within the inner module. The terminals accept wires of up to 1.5mm² (15AWG). Refer to section 2.7 for connections. -
Page 12: Purge Air Supply
The air supply must be capable of delivering at least 30 ltrs/min at this connection and have a pressure of 175 to 700 mBar (2.5 to 10 psi). Series 5000 - Manual 5610 D1198 - Issue 1 - 25 September 2013... -
Page 13: Commissioning
4.3.7 If an air pressure switch is employed momentarily interrupt the air supply and check that a the unit signals fault. Series 5000 - Manual 5610 D1198 - Issue 1 - 25 September 2013 Page 13 of 16... -
Page 14: Hot Body Simulation Tests
Senor than the “monitored plane”. When the 5610 detector is connected to fire panel via a conventional trigger circuit or addressable loop detector interface, latched 5610 detections are normalized by Alarm Reset operation at the fire panel. -
Page 15: Operation
Test Operation of the sensor’s internal Test push-button simulates an alarm as per 5.2. A remote test push-button has identical result if implemented. Series 5000 - Manual 5610 D1198 - Issue 1 - 25 September 2013 Page 15 of 16... -
Page 16: Maintenance
Potential “test targets” are :- Type 5501 Infra-red Radiator - Test and Commissioning Platen - Patol product. Type 5502 Infra-red Radiator - Test and Commissioning Wand - Patol product. 100W Lamp Bulb - (The Sensor responds to the glass temperature - not the visible light).
