MIDI Test RDM Controller Touch Screen Calibration Send and Receive DMX using Art-Net and sACN System Settings 4. Appendix Keeping Your BUDDHA™ As Good As New Returns (Gasp!) Shipping Issues Tech Specs Updating the Firmware Page 2 BUDDHA™ User Manual - Rev. D...
DMX-512 challenges! IMPORTANT: BUDDHA™ will do a lot of things, but it won’t teach you any noble truths. You need to do that yourself. Well, what are you waiting for? GO! Now that you’ve got your BUDDHA™, you should carefully unpack the box and...
11.) Down (-) Button Navigate down 12.) Enter Button Confirm/store a current selection 13.) Right / CH (+) Button Navigate right/increase a selected value 14.) Light Sensor Light Sensor for PWM testing Page 4 BUDDHA™ User Manual - Rev. D (c) 2017 Blizzard Lighting, LLC...
USB to Micro-USB cable, plugged into any computer or device with USB (5V, >200mA.) You can also plug it in to a standard power outlet with use of the USB to AC power adapter. If power is supplied to BUDDHA™ via the USB port, the battery is automatically disconnected.
ADDRESSES: Change the visible DMX range to ALL (1-512) or OPEN (currently input.) CLEAR: Clears all of the current values, and restarts. SOURCE: Select DMX IN or NETWORK as the incoming DMX signal source. Page 6 BUDDHA™ User Manual - Rev. D (c) 2017 Blizzard Lighting, LLC...
You will see a solid line extending from each Input to Output (pins 1-5) that make a good connection, while broken lines indicate no thru connection. Page 7 BUDDHA™ User Manual - Rev. D (c) 2017 Blizzard Lighting, LLC...
<ENTER> button while any is highlighted will disable the display of that certain highlighted channel (NULL). Timing Analyzer: This function of BUDDHA™ will allow you to analyze DMX timings. Select TIMINGS from the MENU, and connect a DMX source to the DMX input.
It can be used to help troubleshoot a wide range of equipment including DMX boosters, splitters, stability of a network, stability of DMX controller, and if faders shake without pushing. Page 9 BUDDHA™ User Manual - Rev. D (c) 2017 Blizzard Lighting, LLC...
Scanning for Flickers: 1.) Configure your console to send a non-changing static scene, or a Static DMX Look. This look should not consist of only zeros. Then, replace the flickering fixture with BUDDHA™. 2.) In the main menu of BUDDHA™, select FLICKER FINDER. 3.) Adjust the Compare Limit if needed (001-255.) Normally, it should be set to 001. 4.) Press the START button to start scanning. 5.) Let the Flicker Finder run for some time. The longer you let the Flicker Finder run, the more you can be sure that your transmission is OK.
2.) Press and hold down the <ENTER> button. 3.) When the data is stabilized, release the <ENTER> button. 4.) The test result will be locked in and shown on the screen. Page 11 BUDDHA™ User Manual - Rev. D (c) 2017 Blizzard Lighting, LLC...
To make it easy to test and use, we designed BUDDHA™ with two-way MIDI, that is able to receive and send MIDI signal. The MIDI test function in BUDDHA™...
RDM (Remote Device Management) enabled fixtures. First, ensure that your RDM enabled fixture(s) are powered on and connected in-line with Buddha’s DMX output, then enter the RDM Controller function from the menu list. The initial screen in the RDM Controller is the Device List.
Page 14
All DMX512 products do not inherently support RDM. Only RDM ‘enabled’ products will actually use the RDM standard, so please check the specifications of your equipment first. RDM can provide users with: • Identification and classification of connected devices • Addressing of devices controllable by DMX512 • Status reporting of fixtures or other connected devices • Configuration of fixtures and other DMX devices Page 14 BUDDHA™ User Manual - Rev. D (c) 2017 Blizzard Lighting, LLC...
5.) Once complete, click on the screen to exit. How to send and receive DMX using Art-Net and sACN BUDDHA™ is capable of receiving or broadcasting Art-Net or sACN (ANSI E1.31 streaming Architecture for Control Networks). 1.) In the OPTIONS interface, select the protocol (Art-Net or sACN), universe and sub- universe for transmission/reception.
Whenever it is not in use, keep BUDDHA and it’s accessories in it’s case. You wouldn’t throw a prized guitar, drumset, or other piece of expensive gear into a gear trailer without a case, and similarly, you shouldn’t even think about doing...
• Number of sequences: microSD card storage capacity dependent • Steps in sequence: 99 Updating the Firmware: 1.) Download the latest BUDDHA™ firmware update from our website. It can be found on the BUDDHA™ product webpage at www.blizzardlighting.com. 2.) Using your computer, create a folder called RECORDER on the microSD card (if not already present), and copy the firmware file “xxx.upf” into it. 3.) Insert the microSD card into BUDDHA™.
Page 18
This page intentionally left blank. Page 18 BUDDHA™ User Manual - Rev. D (c) 2017 Blizzard Lighting, LLC...
Page 19
This page intentionally left blank. Page 19 BUDDHA™ User Manual - Rev. D (c) 2017 Blizzard Lighting, LLC...
Page 20
Enjoy your product! Our sincerest thanks for your purchase! --The team @ Blizzard Lighting...
