Summary of Contents for LELY SHUTTLE XY

  • Page 1 Lely SHUTTLE XY Sampling Device Operator Manual D-H021.1011EN English Original www.lely.com innovators in agriculture Lely Industries N.V.
  • Page 2 innovators in agriculture INTENTIONALLY BLANK...
  • Page 3 Orbiter, Shuttle, Splendimo, T4C, Tigo, Viseo, Voyager, Walkway and Welger are registered trademarks of the Lely Group. The right of exclusive use belongs to the companies of the Lely Group. All rights reserved. The information given in this publication is provided for information purposes only and does not constitute an offer for sale.
  • Page 4 innovators in agriculture INTENTIONALLY BLANK...
  • Page 5 • Abnormal use of the equipment which is not according to the specifications stated in the Operator Manual or handled during the Operators Service and Maintenance Certification program • The result of any intervention by technicians other than Lely service technicians or technicians who have Lely’s approval to perform certain duties.
  • Page 6 innovators in agriculture INTENTIONALLY BLANK...
  • Page 7 innovators in agriculture LIST OF INCLUDED AMENDMENTS Issue Date Chapter(s) Remarks (yy/mm) 10/11 Illustrations updated 1 - 6, 8 Textual changes Cleaning procedure added Test and calibration procedures added Alarm code and attention codes added Diagram added 10/01 Initial Issue...
  • Page 8 innovators in agriculture INTENTIONALLY BLANK...
  • Page 9 The first table below shows the type number of the SHUTTLE for which this manual is applicable. The second table below shows the type numbers of the Lely milking robots for which the SHUTTLE can be used. Model designation Model...
  • Page 10 SHUTTLE, except for the maintenance done by the operator as indicated in the Operator Manual. If people who are not certified by Lely Industries do maintenance on the SHUTTLE, the warranty on the SHUTTLE becomes invalid. Before a technician does maintenance on an SHUTTLE, the owner must examine the service pass of the technician and make sure the technician is currently certified to do maintenance on the SHUTTLE.
  • Page 11 Technician Training All the technicians certified by Lely Industries have completed an approved training program, and passed written and practical examinations during and at the end of the training program. The training is given by a product specialist. The examinations are done under supervision of a master product specialist and include troubleshooting and corrective maintenance of the SHUTTLE.
  • Page 12 innovators in agriculture INTENTIONALLY BLANK...

  • Page 13: Table Of Contents

    innovators in agriculture Table of Contents 1. Introduction 2. Safety Safety Instructions 2.1.1 General Safety 2.1.2 Transport Safety 2.1.3 Operating Safety 2.1.4 Maintenance Safety Safety Decals 2.2.1 Safety Decal Messages 2.2.2 Maintenance of Safety Decals 2.2.3 Installation of Safety Decals Emergency Stop Procedure 3.
  • Page 14 innovators in agriculture 9. Diagram Glossary of Terms Index...

  • Page 15: Introduction

    1. INTRODUCTION The SHUTTLE is a removable and external sampling device for the Lely Astronaut milking robots. Once connected, the SHUTTLE can automatically collect up to a 100 milk samples. The SHUTTLE uses a sample box with bottles of CRV Nederland. The bottles are filled with approximately 30 ml of milk.
  • Page 16 innovators in agriculture INTENTIONALLY BLANK Introduction...

  • Page 17: Safety

    • Disconnect the CAN-bus cable before you clean or do maintenance on the SHUTTLE • Know the emergency medical center number for your area • Contact your nearest Lely service provider if you have any questions • Review safety related items with all operators frequently (annually) 2.1.2 Transport Safety •...

  • Page 18: Operating Safety

    • Make sure the SHUTTLE, the sampling bottles and milk tube are clean. Clean the SHUTTLE if it is not used for more than three days. • Contact your nearest Lely service provider if you have any questions 2.1.4 Maintenance Safety •...

  • Page 19: Safety Decals

    innovators in agriculture Safety Decals 2.2.1 Safety Decal Messages General safety messages appear in this safety messages section. Specific safety messages are in applicable parts of this manual when potential hazards may occur if the instructions or procedures are not followed. 2.2.1.1 Poisonous Substance - Chemical Hazard A chemical hazard decal is affixed to the cover.

  • Page 20: Maintenance Of Safety Decals

    2.2.2 Maintenance of Safety Decals Safety decals on the SHUTTLE XY Sampling Device display important and useful information that will help you safely operate and maintain the SHUTTLE. Obey the instructions below to make sure all the decals stay in the correct position and condition.

  • Page 21: Specifications

    innovators in agriculture 3. SPECIFICATIONS Dimensions and weight • Width: 73 cm (29 in) • Height: 39 cm (15.4 in), 58 cm (22.9 in) with bleed tube strip up • Depth: 59 cm (23.2 in) • Weight: 23 kg (50 lb) (without sample box) Power supply •...
  • Page 22 innovators in agriculture INTENTIONALLY BLANK Specifications...

  • Page 23: Description And Operation

    innovators in agriculture 4. DESCRIPTION AND OPERATION Description The SHUTTLE has the following main parts: • Stainless steel base • Stainless steel cover with a transparent plastic top • Sample box, with bottles • Fill unit • Operator panel. The stainless steel base has two wheels and a transport handle (9, fig. 3, page 4-2).
  • Page 24 innovators in agriculture Figure 3. Detailed overview of the SHUTTLE KEY: 1. Cover - 2. 7-Segment display - 3. Soft button (Reset/Stop) - 4. Bleed tube, with strip - 5. CAN-bus cable - 6. E-Link connector (service only) - 7. Milk tube connection (from milking robot) - 8.

  • Page 25: Operation

    innovators in agriculture Operation Operating conditions The following operating conditions must be met to take milk samples: • The SHUTTLE must be in a lower position than the milk jar • The bleed tube strip must be in the up position and the tube end must be above the 5-kg level (11 lb) of the milk jar •...

  • Page 26: Operator Panel

    innovators in agriculture Figure 4. Fill sequence Operator Panel The operator panel of the SHUTTLE has the following parts: • 7-Segment display • Button • Buzzer. 7-Segment display The 7-segment display (1, fig. 5, page 4-5) indicates the status of the system.
  • Page 27 innovators in agriculture Figure 5. The user interface of the SHUTTLE KEY: 1. 7-segment display - 2. Stop/reset button Description and Operation...
  • Page 28 innovators in agriculture INTENTIONALLY BLANK Description and Operation...

  • Page 29: Operating Instructions

    innovators in agriculture 5. OPERATING INSTRUCTIONS Transport the SHUTTLE Always lock the cover when sample bottles are in the SHUTTLE. WARNING - Make sure the transport handle is fully in when you do not transport the CAUTION SHUTTLE. - Do not transport the SHUTTLE with filled sample bottles installed. Make sure: •...

  • Page 30: Connect The Sampling Device

    innovators in agriculture Connect the Sampling Device Preparation Make sure the SHUTTLE, the sampling bottles and milk tube are clean. Clean CAUTION the SHUTTLE if it is not used for more than three days. See. - Make sure the transport handle is fully in. CAUTION - Make sure the robot arm cannot hit you when you work on the SHUTTLE.
  • Page 31 12. Connect the milk tube of the SHUTTLE, through the sampling cylinder, to the elbow. For a Lely Astronaut A2 or A3 milking robot, do the following: If necessary, remove the tube from the hole in the elbow (5, fig. 11, page 5-8).
  • Page 32 innovators in agriculture Remove the stop (5). Install the connector piece (6) in the milk tube (4). Install the connector piece in the elbow (3). 14. Select button [Close] when the milk tube is in position. 15. Make the applicable changes: 'Current rack number': enter the current rack number, this is usually rack 1.
  • Page 33 innovators in agriculture 10. Select button [Save]. Connect the CAN-bus cable from the E-Link connector (3) on the bottom of the multiple function box. A dot starts blinking on the display of the SHUTTLE. Close-up Put the milking robot in operation with the X-Link. Refer to the Operator Manual of the milking robot for more information.
  • Page 34 innovators in agriculture Figure 8. Opened bottle lid Operating Instructions...
  • Page 35 innovators in agriculture Figure 9. Make the connections Figure 10. The milk level Operating Instructions...

  • Page 36: Replace The Filled Bottles And Trays

    innovators in agriculture Figure 11. Connect the milk tube to an Astronaut A2 or A3 milking robot Figure 12. Connect the milk tube to an Astronaut A3 Next milking robot Replace the filled Bottles and Trays Operating Instructions...
  • Page 37 innovators in agriculture The sample box, with trays and disposable bottles, is provided by CRV Note: Nederland. Preparation Take the milking robot out of operation with the X-Link. Refer to the Operator Manual of the milking robot for more information. Select tab [Sampling].

  • Page 38: Disconnect The Sampling Device

    innovators in agriculture Close and lock the cover of the SHUTTLE. If the cover can not be closed, make sure the racks are installed correctly and try again. Close-up Put the milking robot in operation with the X-Link. Refer to the Operator Manual of the milking robot for more information.

  • Page 39: Print The List Of Sample Details

    Print the List in T4C 1 Select survey tab [Reports]. Select module tab [Milking]. From the tree, select 'Default reports' and 'Lely Milk Sampling'. Enter the start date and time and the end date. Choose the output format. Select button [Make Report].
  • Page 40 innovators in agriculture The total milk yield in 24 h is calculated with the formula: • Total milk yield × 1440 : time • Total milk yield: total yield of all milkings during the sampling run, denoted in kg or lb •...

  • Page 41: Maintenance

    innovators in agriculture 6. MAINTENANCE Clean the SHUTTLE Special Tools • Bucket with cold water • Bucket with warm water • Teeth brush (or comparable brush) • Sponge • Alkaline cleaning agent, for example soap Preparation The SHUTTLE must be cleaned after each sampling to avoid pollution and to Note: ensure uncomplicated operation.
  • Page 42 innovators in agriculture Clean the fill head (4), the valve on the fill head (inside and outside) and the level sensors (5) with the brush (6). Repeat flushing and cleaning procedure with warm water and the alkaline cleaning agent. Repeat flushing and cleaning procedure with clean, cold water. Repeat flushing and cleaning procedure with clean, cold water to make sure all of the cleaning agent is removed.

  • Page 43: Test And Adjustment

    innovators in agriculture 7. TEST AND ADJUSTMENT The SHUTTLE must be tested each year to make sure the fill head moves down to each bottle in the correct position with the level measure pins in the bottle. If not all bottles are filled correctly, the SHUTTLE must be calibrated.

  • Page 44: Test The Shuttle

    innovators in agriculture Close and lock the cover of the SHUTTLE. If the cover can not be closed, make sure the racks are installed correctly and try again. Connect the E-Link and Start-up Connect the E-Link manual controller to the E-Link connector on the SHUTTLE.
  • Page 45 innovators in agriculture Figure 14. Calibration positions Test and Adjustment...
  • Page 46 innovators in agriculture INTENTIONALLY BLANK Test and Adjustment...

  • Page 47: Troubleshooting

    innovators in agriculture 8. TROUBLESHOOTING Attention Codes The table shows the attention codes. The attention codes are only visible for a few seconds. The attention codes, plus the time when they appeared, are stored in the SHUTTLE and can be read with the E-Link controller for service.

  • Page 48: Alarm Codes

    innovators in agriculture Code Description Result Reason Action Three times three A time-out is The milk tube is not No action to be taken bottles could not generated. connected (correctly) be filled within 60 The sampling The sampling cylinder No action to be taken s after the fill process will does not work correctly...
  • Page 49 innovators in agriculture Code Description Result Reason Action Push the button The fill head could The sampling The lid of the bottle to [STOP/RESET] for a not move down process stops be filled is not fully open short time. (Z-axis) or could Make sure the lid is not reach the between the racks...
  • Page 50 innovators in agriculture Code Description Result Reason Action (approx. 1 revolution in 2 s) Push and hold button [STOP/RESET] for more than 5 s. Make sure the fill head moves to the home position. If the alarm remains, call your local service provider Push the button The controller...

  • Page 51: Reset An Alarm

    innovators in agriculture Code Description Result Reason Action Electrical current The sampling The spindle is dirty Clean the spindle with a required by the X- process will clean, soft towel axis and/or Y-axis continue as If the alarm remains, call motor is too high normal your local service provider...
  • Page 52 innovators in agriculture INTENTIONALLY BLANK Troubleshooting...

  • Page 53: Diagram

    innovators in agriculture 9. DIAGRAM Figure 15. Dimensions • A: 38.5 cm (15.2 in) • B: 72.6 cm (28.6 in) • C: 57.8 cm (22.8 in) • D: 58.5 cm (23.0 in) Diagram...
  • Page 54 innovators in agriculture INTENTIONALLY BLANK Diagram...

  • Page 55: Glossary Of Terms

    Astronaut: Lely Astronaut milking robot cm: centimeter EU: European Union gal: gallon h: hour in: inch kg: kilogram lb: pound LED: Light Emitting Diode m: metre s: second(s) T4C: Lely Time For Cows Farm Management Software V: Volt Glossary of Terms...
  • Page 56 innovators in agriculture INTENTIONALLY BLANK Glossary of Terms...
  • Page 57 innovators in agriculture INDEX Applicability ..........VII Calibrate the SHUTTLE .......7-2 Cleaning ............5-1 Connect the SHUTTLE to Astronaut A2/A3........5-8 Astronaut A3 Next ........5-8 Milk yield, calculate........5-11 Operating position ........2-2 OVERVIEW OF..........3-1 Preservative....... See Sample bottles Replace fille bottles ... See Sample bottles Sample bottles ........
  • Page 58 innovators in agriculture INTENTIONALLY BLANK Index...
  • Page 59 innovators in agriculture INTENTIONALLY BLANK...
  • Page 60 LELY INDUSTRIES NV Weverskade 110 NL-3147 PA Maassluis Tel +31 (0)10 - 59 96 333 Fax +31 (0)10 - 59 96 444 www.lely.com Live Life Lely...
  • Page 61 Introduction The milk recording device Shuttle XY is tested for a period of time resulting in ICAR approval. The approval is applicable for the Shuttle XY on all Astronaut milking robots. Some modifications are required to comply to the ICAR standard. Resulting in better mixing of the milk in the milk jar, reducing cleaning water remaining and ensuring minimal carry-over during sampling.
  • Page 62 The milk manifold, pre-milk, 6-fold tube, nipples and tubes are changed. Also the drain cycle during the Lely wash is improved in Robot software version 3.0 SR2. See #3-7 in the ICAR update matrix How to replace the parts can be found in the A4 service manual.
  • Page 63  Check correct function of fill head Shuttle XY. Milk of previous cow is flushed passing the fill head passing the loop to the antenna and must not flow back into the sample bottle. Little backflow is allowed, approx. 2 cm backflow during filling of the vial.
