  • Page 1 Model: 434T User Manual 02-May-2013...

  • Page 2: Table Of Contents

    Table of Contents Chapter I Product Introduction......................3 1.1 Product appearance and LED indicators....................3 Chapter II Product Installation......................4 2.1 Wireless network connection- take Windows Xp for example Power 434T........4 2.2 Login User management Interface (UI)....................6 2.3 Wi-Fi password modification.........................7 2.4 Default factory setting..........................9 Chapter III Internet access mode setting ....................10...

  • Page 3: Chapter I Product Introduction

    5.4.4 Settings............................36 Chapter V FTP..........................37 5.5 FTP: files download and upload....................37 ................................37 Chapter I Product Introduction 1.1 Product appearance and LED indicators...

  • Page 4: Chapter Ii Product Installation

    Chapter II Product Installation 2.1 Wireless network connection- take Windows Xp for example Power 434T （ 1 ） Select “wireless network connection” on “Network Connection” property of the...
  • Page 5 computer desktop. See as below，m ake the In ternet protocol to “ ob ta in IP address automat ica l l y ” . （ 2 ） The icon “ ” co mes on the r ight bot tom of co mputer desktop ， press r ight but ton of m ouse, then se lect “...

  • Page 6: Login User Management Interface (Ui)

    （3） When“Connected” ，i t m eans connect ion success. 2.2 Login User management Interface (UI) （ 1 ） Open Web browser, input “http ： //192.168.169.1 ” in Address bar , and press “ En ter ” .

  • Page 7: Wi-Fi Password Modification

    “Login”. 2.3 Wi-Fi password modification （1） Connect your PC to 434T via WiFi ，in the W E B browser input ：192.168.169.1，c l ick “W IF I ” i con，input password：ad min，enter in to WIFI m anage ment set t ing...
  • Page 8 （ 2 ） Select the encrypt ion m ode in “ Security Mode ”，and set WIFI key.

  • Page 9: Default Factory Setting

    （ 3 ） After set t ing，cl ick “Apply ” but ton，then 434T wi l l restar t ，connect your PC to 434T again. 2.4 Default factory setting When you reset 434T, it will be factory status. default IP ： 192.168.169.1 ， password ：...

  • Page 10: Chapter Iii Internet Access Mode Setting

    1s/t imes) ，i t m eans “ r eset ” success，then 434T wi l l res tar t . Chapter III Internet access mode setting 3.1.1 Insert the SIM card Warning Before inserting or removing the SIM card, you must disconnect the device from the power adapter.

  • Page 11: Connect To A Telephone Set

    M A C. 3.3 DHCP （ Hotel ） （1） Power 434T, connect the cable in hote l or m ode m LAN to 434T W A N por t . （2） Connect your PC to 434T v ia WIFI 3.4 STATIC IP(Campus)

  • Page 12: Wifi Hotspot

    （ 4 ） When 434T status indicator light is blue(always), it means connection success and internet available. 3.5 WIFI Hotspot （1） Power 434T, connect your PC to 434T via WIFI （2） In Web browser input: 192.168.169.1, password: admin, click “Network setting- WAN”,make WAN mode be “WIFI”.

  • Page 13: Chapter Ⅴ Software Feature

    Chapter Ⅴ Software feature Login GUI of 434T，you can m ake so me set t ings.

  • Page 14: Internet Settings

    ：Check and conf igue the bas ic in fo of wire less network ： Login the status W ebpage，check the in ternet access m ode, connect ion and net f low, ect . ：W hen ADSL i s cur rent access m ode，you can input account and password f rom your operator .

  • Page 15: Static Mode

    5.1.1.1 STATIC Mode The superior equipment is router or others; you need to enter fixed IP address provided by ISP. IP address : Static IP address provided the ISP.  Subnet mask : Provided by ISP.  Default Gateway ：Fi l l in the gateway address as prov ided by the ISP. ...

  • Page 16: Pppoe (Adsl) Mode

    sure that the extranet ports connect to DHCP server. You can choose not to fill in the Hostname. 5.1.1.3 PPPOE (ADSL) Mode Superior equipment is modem or optical fibre; you need to enter user name and password appointed by ISP.
  • Page 17 User Name: Fill in the Internet access account as provided by the ISP. Please place  enquiries on the ISP in case of any queries. Password: Fill in the password as provided by the ISP. Please place enquiries on  the ISP in case of any queries.

  • Page 18: Mode

    status webpage）。 This m ode i s su i tab le for the user who pay accord ing to the in te rnet us ing t ime and save the cost . 5.1.1.4 3G Mode Use 3G wireless data card 3G Run Type : ⑴...

  • Page 19: Wifi

    If the “Manual DNS” is selected, the router will use the DNS information entered by the user. Net Backup: If you slect “3g back”, means 434T supports failover, when 3g  disconnect,it will dial no through ADSL/DHCP for internet prepare.

  • Page 20: Lan

    5.1.2 LAN IP address : Set up IP addresses for Intranet ports  Subnet mask : Set up masks for the Intranet.  MAC address : Indicated physical addresses of the Intranet ports.  DHCP type : Select “Server” to open DHCP services and then the host in the Intranet ...

  • Page 21: Dhcp Clients

    Destination IP address: Identify target addresses or networks that are hopefully to be  visited. Range ： Host/Net : The selection of a host means to designate a certain IP for the  host. The network defines a specific network segment by defining a subnet mask. Gateway: IP address of the router or the host where the data packets are sent.

  • Page 22: Wireless Network Settings

    5.2 Wireless Network Settings 5.2.1 WIFI Settings...
  • Page 23 Wireless switch : Switch on/off wireless functions of the router.  Network mode : Wireless application standards for the router. The router supports  802.11b, 802.11g, and 802.11n or mix modes. SSID : Network name of the wireless signals. This router supports multiple wireless ...
  • Page 24 Wi-Fi Protection Settings : Used to disable or enable WPS functions. The default  status is “Disable”. Overview :  Display relevant information including current status, authentication modes and encryption types applied, and default private key indexing. WPS Current Status : “Idle” means the idle status. “Start MSC Process” means that ...

  • Page 25: Firewall

    mode is commonly seen. WPS Encryption Type : It means the data encryption type. AES/TKIP encryption type is  commonly seen. WPS Key : Effective keys automatically generated by AP.  Reset OOB : When you press this button, the WPS service terminal is indicated as Idle ...

  • Page 26: Address Filter

    Web host filtering: URL WEBPAGES including keywords are filtered.  5.3.2 Address Filter This function is aimed at restricting and managing the client ports of the router. If you need to limit Internet use of the machine of the router, you could use this function. To use this function, you should first activate it and then select a default strategy (accept or reject), which means the data packets that do not comply with the rules to be accepted or rejected.
  • Page 27 Mac/IP/Port Filtering : This function takes no effect if “Prohibit” is selected. After you  click “Enable”, this function will take effect. Default Policy : Select “Dropped” or “Accepted”. This strategy shall be implemented if  rules as defined below are not matched. MAC Address : Fill in MAC addresses that you plan to define rules.

  • Page 28: Virtual Server

    Destination IP Address : Enter destination IP address that needs filtering. You shall fill  in rules that correspond to this IP. Port range : Ranges for ports that need to be abandoned or accepted.  Protocol: Select protocols that are used by controllable data packets. ...
  • Page 30 Virtual Server settings : Enable or disable functions of the virtual servers.  IP address : It is used to input necessary IP addresses, such as192.168.1.103.  Port Range: It is used to input necessary port ranges, such as 80-80. ...

  • Page 31: System Security

    5.3.4 System Security Remote management : Identify whether it is permitted to access WEB management  pages via Extranet ports. Ping form WALL Filter : Identify whether it is permitted to PING the router via Extranet  port 5.3.5 DMZ Settings Transfer all data that are received by the router’s Extranet ports to “DMZ IP Address”...

  • Page 32: Status

    5.4.1 Status Current work conditions of the router. System information: Version : indicates the router’s current software versions and the release date.  Running Time: indicates the system operation time after the router is loaded with a  power supply. Such time will be cleared to zero after the power supply is unloaded. Internet Configurations ：...

  • Page 33: Management

    Primary Domain Name server: Address of the DNS server that is currently used by  the router. Local Network: Local IP address: IP address of the router’s Intranet ports.  Local Net mask: Subnet mask of the router’s Intranet.  MAC address: Physical address of the router’s Intranet ports.
  • Page 34 Current Time ：Set the router t ime the same to PC.  Time Zone ：Select t ime and area.  NTP Server : Enter the address for the NTP Server, then the Router will get the time  from the NTP Server preferentially. In addition, the router built-in some common NTP Servers, so it can get time automatically once it connects the Internet.

  • Page 35: Upload

    Account : the login name you register in the websites that provide dynamic domain  name service. Password : the password you register in the websites that provide dynamic domain  name service. DDNS  : the domain name you register in the websites that provide dynamic domain name service Note: Before using Dynamic Domain Name function, please register the dynamic DNS address services in the website listed in drop-down box of service providers and...

  • Page 36: Settings

    5.4.4 Settings Export system configurations : Save system configuration files locally for further  recoveries. Export LOG : Click the “open” button; store the Log file locally to seek error.  Import system configuration s: Introduce local configuration files to the router. After ...

  • Page 37: Chapter V Ftp

    Chapter V FTP 5.5 FTP: files download and upload Put USB driver/Hard disk/HDD into USB port of 434T, then connect your PC to 434T via WIFI or cable. Click your “My computer” or “Browser”, input:ftp://192.168.169.1. then you can see all files and you can upload and download the files you want.
