Technical Data - Gradient Golden5 User Manual

3
Golden5
Flat Area
Projected area
Span
Projected span
Aspect ratio
Projected aspect ratio
Max. chord
Min. chord
Number of cells
Line consumption
1
Weight of the glider
Take-off weight range
2
Certification EN/LTF
1
- Line consumption is the sum of lengths of all lines including brake lines.
2 - Take-off weight is the weight of the pilot including equipment and paraglider (approx. 20-25 kg
or approx. 10-20kg for Light glider)
Length of the riser:
Golden5-22
non-accelerated [mm]
accelerated [mm]
Golden5-24
non-accelerated [mm]
accelerated [mm]
Golden5-26
non-accelerated [mm]
accelerated [mm]
Golden5-28
non-accelerated [mm]
accelerated [mm]
Golden5-30
non-accelerated [mm]
accelerated [mm]
Risers are without trimmers.
Length tolerance of risers is +/-5mm.
Pilot's manual for Golden5

2.2. Technical data

Units 22
2 22.20
[m ]
2 18.85
[m ]
[m] 10.88
[m] 8.56
[1] 5.34
[1] 3.88
[m] 2.47
[m] 0.79
54
[m] 243.84 251.51
[kg]
[kg] 62-77
B
A₁+A₂ B C
440 440 443
315 357 443
A₁+A₂ B C
460 460 463
330 374 463
A₁+A₂ B C
480 480 483
345 390 483
A₁+A₂ B C
500 500 503
360 407 503
A₁+A₂ B C
500 500 503
360 407 503
24 26
24.10 26.12
20.47 22.18
11.34 11.80
8.92 9.28
5.34 5.34
3.88 3.88
2.58 2.68
0.82 0.86
54 54
265.59
4.80 5.10
75-90 85-105
B B
28 30
28.32 30.52
24.17 25.92
12.30 12.76
9.75 10.03
5.34 5.34
3.93 3.88
2.80 2.90
0.89 0.92
54 54
273.97 281.52
5.50 5.80
95-115 110-135
B B
