Summary of Contents for BandRich BandLuxe M250
- Page 1 BandLuxe M250 Series HSUPA Module User Manual...
- Page 3 LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE OR INABILITY TO USE THIS MANUAL, EVEN IF PRODUCT OR ITS SUPPLIERS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. BandRich M250 Datasheet Document Number: M250-D-001 BandRich Inc. 7F., No. 188, Baociao Rd., Sindian City TAIPEI, TAIWAN, R.O.C. http://www.bandrich.com COPYRIGHT ©2007-2008 BandRich All rights reserved.
- Page 4 Table of Contents Section 1 Introduction ................1-2 Section 2 Device Driver Interface ............2-2 Section 3 AT Command Set Reference ..........3-2 Section 4 Packing Information.............3-2 Section 5 FCC Statement..............5-1...
-
Page 5: Section 1 Introduction
Section 1 Introduction General Description The M250 module series is PCI Express Mini Card providing WWAN (HSUPA, HSDPA, WCDMA, EGPRS, and GPS) connectivity to laptops or any other device equipped with a PCI Express Mini Card slot. Figure 1-1 Top View Figure 1-2 Bottom View... - Page 6 W_Disable# signal to disable radio operation. There are several GPIO pins (2.6V compatible) reserved for customized applications, please contact BandRich for discussion. Besides the above mentioned interfaces, M250V also provides PCM interfaces reserved for voice applications. The M250-LC features low power consumption but requires higher input voltage than PCI standard.
-
Page 7: Pin Description
M250 PCI-Express Mini Card Interface 1.3.1 Pin Description Table 1-1 M250 Module Series Connector Pin-out Pin No. Name Pin No. Name WAKE#/GPIO1 (optional) Vaux PCM_DOUT (M250V only) PCM_DIN (M250V only) N.C./GPIO2 (optional) N.C. UIM_PWR UIM_DATA PCM_SYNC (M250V only) UIM_CLK PCM_CLK (M250V only) UIM_RESET N.C. - Page 8 Figure 1-3 Pin-out information of M250 series (Top View) Network LED indicate device The Network LED indicated device is ground-referenced current sink. The host drives the device to provide a current path and an appropriate voltage for LED at PIN 42 of M250 module. Figure 2-2 shows the block diagram of the current drivers.
- Page 9 LED State Module Status Description LED Characteristics LED is flashing intermittently during data transfer activity. Intermittent Module is transmitting or receiving 50ms±5% ON period and blink 250ms±5% OFF period...
-
Page 10: Usb Interface
USB Interface M250, M250V and M250-LC module are compliant with USB2.0 in all three modes (Low speed, Full speed, and high speed). When two devices are connected via a USB interface, one of the devices must act as a host, and the other device must act as a peripheral. The host is responsible for initiating and controlling traffic on the bus. - Page 11 USIM_CLK and USIM_RST signal, include 33pF filter capacitors is required to be placed near the SIM connector. Route all USIM signals carefully – isolate them from sensitive analog and RF signals. External ESD diodes are necessary to protect the chip on the module; the ESD diodes should be placed near the connector.
- Page 12 Section 2 Device Driver Interface Basically the module will manifest itself as a composite USB device which creates stubs which the other higher level drivers hook into and provide their respective function. The composite USB device could be modem, NDIS interface, AT command interface or diagnostics interface. All device drivers used by OS have been created for Microsoft Windows Vista 32/64, Windows XP SP2 above, Windows 2000 SP4 above, Mac OSX 10.4 above, and Linux Fedora 8, Unbuntu 7, Open SuSE 10.
- Page 13 Section 3 AT Command Set Reference Table B-1 lists the standard AT command that are implemented in BandLuxe M250 module series. For detail command usage and possible response, please check 3GPP TS 27.007, AT command set for User Equipment (UE).
- Page 14 AT Command Command description Command Format AT+CFUN Full functionality mode AT+CFUN=<mode>[,<rst>] AT+CFUN? AT+CFUN=? AT+GCAP Request complete TA capabilities AT+GCAP list AT+GCAP=? AT+CSCS Used Character Set AT+CSCS=[<chset>] AT+CSCS? AT+CSCS=? AT+CEER Cause Location ID for the extended AT+CEER error report AT+CMEE Report Mobile Terminal Error AT+CMEE=[<n>] AT+CMEE? AT+CMEE=?
- Page 15 AT Command Command description Command Format AT+CGEQMIN 3G Quality of Service Profile AT+CGEQMIN=[<cid> [,<Traffic class> (Minimum acceptable) [,<Maximum bitrate UL> [,<Maximum bitrate DL> [,<Guaranteed bitrate UL> [,<Guaranteed bitrate DL> [,<Delivery order> [,<Maximum SDU size> [,<SDU error ratio> [,<Residual bit error ratio> [,<Delivery of erroneous SDUs>...
- Page 16 AT Command Command description Command Format AT+CSQ Request signal strength AT+CSQ AT+CSQ=? AT+CPIN Check PIN Status AT+CPIN=<pin>[,<newpin>] AT+CPIN? AT+CPIN=? AT+CGATT PS attach / detach AT+CGATT= [<state>] AT+CGATT? AT+CGATT=? AT+CGACT PDP context activate or deactivate AT+CGACT=[<state> [,<cid>[,<cid>[,…]]]] AT+CGACT? AT+CGACT=? AT+CGCMOD PDP Context Modify AT+CGCMOD=[<cid>[,<cid>[,…]]] AT+CGCMOD=? AT+CPBS...
- Page 17 AT Command Command description Command Format AT+CPWD Change password AT+CPWD=<fac>,<oldpwd>,<newpwd> AT+CPWD=? AT+CUSD Unstructured supplementary AT+CUSD=[<n>[,<str>[,<dcs>]]] service data AT+CUSD? AT+CUSD=? AT+CIMI Read IMSI AT+CIMI AT+CIMI=? AT+CGMI Request manufacturer identification AT+CGMI AT+CGMM Request model identification AT+CGMM AT+CGMR Request revision identification AT+CGMR AT+CGSN Request product serial number AT+CGSN identification...
- Page 18 Section 4 Section 4 Federal Communications Commission (FCC) Statement You are cautioned that changes or modifications not expressly approved by the part responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference.
