Summary of Contents for Global American 3301520
- Page 1 User’s Manual 3301520...
-
Page 2: Regulatory Compliance Statements
Operation of this equipment in a residential area (domestic environment) is likely to cause harmful interference, in which case the user will be required to correct the interference (take adequate measures) at their own expense. 3301520 User s Manual Preface... -
Page 3: Ce Certification
Safety Information Before installing and using the 3301520, note the following precautions: ƒ Read all instructions carefully. ƒ Do not place the unit on an unstable surface, cart, or stand. -
Page 4: Table Of Contents
2.4 Location of Jumpers……………………………………………………………………………….…..15 2.5 Function of Jumper………………………….……………………………………………………..17 2.6 Connector and Pin Definition.………...……….…………………………………………………...…18 Chapter 3 Expansion 3.1 System Memory………………………………………………………………………………….…….33 3.2 Installing DIMM………………………………………………………………………………….. …..34 3.3 Installing Compact Flash………………………..……………………………………………………..36 3.4 Installing Intel Pentium-M CPU and Fan Heatsink…………………………………………………..37 3301520 User s Manual Table of Content... - Page 5 This Page is Left Blank Intentionally 3301520 User s Manual...
-
Page 6: Chapter 1 General Information
Chapter 1 General Information 3301520 User s Manual Chapter 1... -
Page 7: Main Feature
Shared integrated graphics controller from chipset with 2048 x 1536 resolution @ 85 Hz • Support IDE and SATA HDD • USB 2.0 Port x 8, COM x 2 • Support Disk on Module • 1.2 Specifications Figure 1.1: Block Diagram of 3301520 3301520 User s Manual Chapter 1... - Page 8 - Supporting Boot from LAN - Share integrated Graphics controller from 945G chipset Display - Analogue Display Support: Up to 2048 x 1536 @ 85 Hz for CRT - VGA DB-15 connector x 1 3301520 User s Manual Chapter 1...
- Page 9 ‹ 8 voltage (For +1.5V, +3.3V, +5V, +12V, +1.8V, Vcore and +5VSTBY and +3VSTBY) System Management ‹ 2 temperature (For CPU and system) 3 FAN speed monitor (one for CPU and 2 for systems) Real Time Clock - On-chip RTC with battery back up 3301520 User s Manual Chapter 1...
-
Page 10: Power Consumption Measurement
Max. 2GB DDR2 400 DIMM, VGA integrated , Intel 82573L PCI Express Gigabit Ethernet x 2, Serial ATA Ports x 4 1.3 Power Consumption Measurement Required watts and currents for Power Supply Power Type +12V +5VSB Consumed watts (Item: W) Consumed currents (Item A) Actually required currents (Item A/0.8) 3301520 User s Manual Chapter 1... -
Page 11: Board Layout
1.4 Board Layout Figure 1.2: Overview of 3301520 3301520 User s Manual Chapter 1... -
Page 12: Board Dimensions
1.5 Board Dimensions Figure 1.3: Mechanical Drawing of the 3301520 3301520 User s Manual Chapter 1... - Page 13 Chapter 2 Jumper Setting 3301520 User s Manual...
-
Page 14: Before You Begin
Hold electronic circuit boards (such as the 3301520 board) by the edges only. Do not touch the components on the board unless it is necessary to do so. Don’t flex or stress the circuit board. -
Page 15: Setting Jumpers
OPEN. Open (Off) Short (On) These illustrations show a 3-pin jumper. Pins 1 and 2 are SHORT. Table 2-1: Setting Jumpers 3301520 User s Manual... -
Page 16: Location Of Jumpers
Switch setting table (*: default setup) COM Port Type Select 1-20 2-19 3-18 4-17 5-16 6-15 7-14 8-13 9-12 10-11 *RS232 RS422 RS485 RTC Clear Normal Clear CMOS *1-2 CF Card Master/Slave Select Slave Master *2-3 3301520 User s Manual... - Page 17 82573L LAN2 Link 1000 LED JP12 82573L LAN1 Activity LED JP13 82573L LAN1 Link 100 LED JP14 82573L LAN2 Activity LED JP15 82573L LAN2 Link 100 LED CON1 82573L LAN2 Connector CON2 82573L LAN1 Connector CON3 Keyboard + mouse Connector 3301520 User s Manual...
- Page 18 J2: AUX +12V Power Definition Definition +12V +12V J4: Floppy Definition Definition DIR# DENSEL# STEP# Write Data# WGATE# INDEX# TK00# MOTEA# WPT# DRVB# Read Data# DRVA# SIDE1# MOTEB# DSKCHG# J5: CPU FAN Definition Definition Sense +12V 3301520 User s Manual...
- Page 19 LPC Address 1 LPC Address 0 PCI 33MHZ J14: USB 0/1 Definition Definition +5VSB Data 1- Data 0- Data 1+ Data 0+ J15: USB 2/3 Definition Definition +5VSB Data 3- Data 2- Data 3+ Data 2+ 3301520 User s Manual...
- Page 20 Data 4 DMA ACK# Data 11 Data 3 Interrupt Data 12 Data 2 DiskAddress 1 Data 13 DMA66 Detect Data 1 DiskAddress 0 Data 14 DiskAddress 2 Data 0 HDCCS1# Data 15 HDCCS3# HDD Active # 3301520 User s Manual...
- Page 21 Acknowledge# Busy Paper empty Select J21 : External keyboard Definition Definition Keyboard Clock Keyboard Data J22: VGA connector Definition Definition Green Blue DDC Data HSYNC VSYNC DDC Clock J23: Disk on module external power Definition Definition 3301520 User s Manual...
- Page 22 HDCCS3# IOR# IOW# Interrupt CF_CSEL# Reset# IOCHRDY Disk Address 2 DMA REQ Disk Address 1 DMA ACK# Disk Address 0 HDD Active# Data 0 DMA66 Dectec Data 1 Data 8 Data 2 Data 9 Data 10 3301520 User s Manual...
- Page 23 Speaker Thermal GND :PIN1 IDE LED power LED POWER ON RESET SM BUS BUZZER SYSTEM THERMAL JP3: IR Definition Definition CIRRX IRTX IRRX JP4: Keyboard lock Definition Definition Keyboard Lock JP5: Line-out Definition Definition LINEOUT_L LINEOUT_R 3301520 User s Manual...
- Page 24 JP13/JP15: 82573L LAN1 LINK100 LED / 82573L LAN2 LINK100 LED Definition Definition Speed1000# Speed100# :PIN1 JP12 JP14 JP13 JP11 JP15 CON1/CON2: 82573L LAN2 Connector/82573L LAN1 Connector Definition Definition MDI0P MDI3P MDI0N MDI3N MDI1P ACTIVITY# MDI2P +5VSB 3301520 User s Manual...
- Page 25 MDI2N LINK100# MDI1N LINK1000# CON3: Key board + mouse Connector Definition Definition Mouse Data Keyboard Clock Keyboard Data +5VSB Mouse Clock 3301520 User s Manual...
-
Page 26: Chapter 3 Expansion
Chapter 3 Expansion 3301520 User s Manual... -
Page 27: System Memory
3.1 System Memory 3301520 incorporates Intel 945G chipset supports dual channel non-ECC un-buffered DDR2 533/667 MHz memory up to 2GB. Two 240-pins DIMM sockets support up to a maximum 2GB DIMM. Followings are the recommended memory modules. Size (MB) Technology Type... -
Page 28: Installing Dimm
1. Make sure the two handles of the DIMM sockets are in the “open” position, i.e. the handles stay outward. Figure3-1: How to Install DIMM (1) 2. Slowly slide the DIMM modules along the plastic guides in the both ends of the socket. Figure 3-2: How to Install DIMM (2) 3301520 User s Manual... - Page 29 Figure 3-3: How to Install DIMM (3) 4. To take away the memory module, just push the both handles outward, the memory module will be ejected by the mechanism in the socket. Figure 3-4: How to Install DIMM (4) 3301520 User s Manual...
-
Page 30: Installing Compact Flash
3.3 Installing Compact Flash (Skip No CF with Standard 3301520) 1. To install a Compact Flash memory card into PAEK 870, align the notches on the card with the Compact Flash socket in the 3301520. Then firmly insert the card into the socket until it is completely seated. - Page 31 Step 2: a. Remove processor from shipping media by grasping substrate edges only. b. Grasp the processor with your thumb and forefinger on the edges with the orientation notches. c. Carefully place the CPU into the socket. 3301520 User s Manual...
- Page 32 Place the Heat Sink with Fan Set onto the four holes around the CPU socket making sure that the four screws are aligned with the holes on the 3301520. b. Pressing down the metal pads on the four Stand-Offs. c.
- Page 33 We will do our best to support you for your products, projects and business Global American Inc. Address: 17 Hampshire Drive Hudson, NH 03051 TEL: Toll Free (U.S. Only) 800-833-8999 (603) 886-3900 FAX: (603) 886-4545 Website: http://www.globalamericaninc.com salesinfo@globalamericaninc.com E-Mail: 3301520 User s Manual...
