The ACPGM-80V has a built in Dual-Link module that allows connection of Android and other devices with
-
two-way mirroring control.
Adds a reverse camera input with active parking guidelines.
-
Adds 2 Audio/Video inputs.
-
Compatible with Cadillac CUE, GM MyLink (iO3, iO5 & iO6) Infotainment Systems with 4.3" and 8" screens.
-
ACPGM-80V MODULE
MyLink Harness
PUSH BUTTON SWITCH
CAN BOX
MICROPHONE
USB CABLE
Audio Cable
1 / 8
CUE Harness
VIDEO CABLE
3.5 AUX CABLE
rev.030518
Advertisement
Related Manuals for Crux ACPGM-80V
Summary of Contents for Crux ACPGM-80V
- Page 1 The ACPGM-80V has a built in Dual-Link module that allows connection of Android and other devices with two-way mirroring control. Adds a reverse camera input with active parking guidelines. Adds 2 Audio/Video inputs. Compatible with Cadillac CUE, GM MyLink (iO3, iO5 & iO6) Infotainment Systems with 4.3” and 8” screens.
- Page 2 2 / 8 rev.030518...
- Page 3 16-pin connector and the MyLink System will have a 10-pin connector. A harness for each system is included in the ACPGM-80V kit. 4. Plug the 6-pin Molex connector of the harness being used to the CAN box included in the kit.
-
Page 4: Screen Calibration
To toggle to Smartphone Connectivity mode (i.e. Android Auto), press the MENU button on the radio. SCREEN CALIBRATION The screen needs to be calibrated to the ACPGM-80V after it is installed for the first time. Please see calibration steps below: 1. - Page 5 4 / 8 rev.030518 ANDROID SMARTPHONE CONNECTION To use Android Auto and dual controlled Android Mirroring, please follow the steps below: 2. Go to “Software info” and 3. Go to “Developer 4. You will need to install 1. Go to “Settings” and then click “Build Number”...
- Page 6 Remote Pushbutton Switch. The ACPGM-80V works on the 8” CUE and on the 8” and 4.3” (RPO iO3, iO5 & iO6) MyLink systems. To find the RPO Codes, please check the label in the glove box or under the spare tire location. The label...
- Page 7 6 / 8 rev.030518 CADILLAC SYSTEM / SCREEN SIZE 2014 – 2017 2014 – 2017 CUE iO5/iO6 with 8” Screen 2014 – 2017 2016 – 2017 Escalade 2016 – 2017 CUE with 8” Screen CHEVROLET 2014 – 2015 Impala 2014 – 2015 Silverado iO3 4"...
- Page 8 2016 – 2017 Volt (high end) 2016 – 2017 Equinox rev.030518 MyLink iO5/iO6 with 8” 2014 – 2017 Impala Screen 2014 – 2017 Silverado MyLink iO5/iO6 with 8” 2014 – 2017 Suburban Screen 2014 – 2017 Tahoe 2014 – 2015 Sierra iO3 4”...
- Page 9 8 / 8 rev.030518 8 / 8 rev.112817...
