FCC NOTE
This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part
15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
measures listed below.
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/television technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1)this device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this
equipment. Such modifications could void the user's authority to operate the equipment.
PACKING LIST
The complete 8 ports/16 ports PS/2 / USB switch package consists of:
8 ports/16 ports PS/2 / USB switch
Power Adapter
User Manual
Please check to make sure that all the components are present and that nothing was damaged in shipping. If you
encounter a problem, contact your dealer.
Read this manual thoroughly and follow the installation and operation procedure carefully to prevent any
damage to the unit, and/or any of the devices that connect to it.
User Manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lanbe KS-3108
Summary of Contents for Lanbe KS-3108
-
Page 1: User Manual
User Manual FCC NOTE This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 2: Table Of Contents
OVERVIEW....................................3 FEATURES ..................................... 3 HARDWARE REQUIREMENTS..............................3 CONSOLE ....................................3 COMPUTER ................................... 3 INTRODUCTION................................... 4 KS-3108 FRONT VIEW ................................. 4 KS-3116 FRONT VIEW ................................. 4 KS-3108 REAR VIEW................................5 KS-3116 REAR VIEW................................5 INSTALLATION..................................... 6 BEFORE YOU BEIGIN................................6 SINGLE STAGE INSTALLATION ............................ -
Page 3: Overview
The KS-3108 / KS-3116 8 ports/16 ports PS/2 / USB CAT5 UTP KVM (Keyboard, Video, Mouse) Switches are control units that allow access and control of up to 8 (KS-3108) or 16 (KS-3116) computers from a single PS/2 / USB keyboard, PS/2 / USB mouse, and monitor console. -
Page 4: Introduction
INTRODUCTION KS-3108 FRONT VIEW KS-3116 FRONT VIEW 1. REMOTE LED The REMOTE LED indicates whether the selected computer is controlled by remote console or local console. If it is on, the computer is controlled by remote console. Otherwise, it is controlled by local console. -
Page 5: Ks-3108 Rear View
KS-3108 REAR VIEW KS-3116 REAR VIEW 1. Power Jack The power adapter cable plugs into this jack. 2. USB Port The USB mouse & keyboard plug into these ports. 3. PS/2 Port The PS/2 mouse & keyboard plug into these ports. -
Page 6: Installation
INSTALLATION BEFORE YOU BEIGIN 1. Make sure that power to all the devices you will be connecting up have been turned off. 2. To prevent damage to your installation, make sure that all devices on the installation are properly grounded. SINGLE STAGE INSTALLATION To set up yourKS-3108 / KS-3116 installation, do the following: 1. -
Page 7: Operation
Note: If the unit is operating under external power, unplug the power adapter cable. 2. Wait 10 seconds, then plug the power adapter back and power on all computers. PORT SELECTION The KS-3108 / KS-3116 provides two methods to obtain instant access to any computer in your installation: manual and OSD. Manual Simply press the appropriate port selection switch on the KS-3108 / KS-3116’s front panel. -
Page 8: Osd Operation
[Enter] to show main menu. Note: There are two passwords in OSD. One is user password which is initially empty. And the other is factory password which is “LANBE”. OSD menu interface is shown as below: Note: OSD always starts in List View, with the highlight bar at the same position it was in the last time it was closed. -
Page 9: Osd Main Screen Headings
OSD MAIN SCREEN HEADINGS Heading Explanation This column lists the port numbers for all the CPU ports on the installation. The simplest method to access a particular computer is to move the highlight bar to it, then press [Enter]. If a port has been selected for Quick View scanning, an arrowhead symbol displays in this column to indicate so. - Page 10 QVIEW + NAME Lists only the ports that have been selected as Quick View Ports and have name. NAME Lists only the ports that have names. Move the highlight bar to the choice you want, then press [enter]. An icon appears before the choice to indicate that it is the currently selected one.
- Page 11 Options are CTRL, SCROLL, SHIFT and ALT. Move the highlight bar to an option and press [Enter] to select SET PASSWORD: Set new password. First enter old password, then enter new password and confirm it. The new password is set. If error occurs, the screen will remind users.
-
Page 12: Trouble Shooting
Press reset button on the rear panel. reset. OSD menu no display. Power supply problem. Plug power adapter to supply enough power. SPECIFICATIONS Type KS-3108 KS-3116 Computer connections CPU port selection Front panel switches/OSD menu Console Keyboard 1 x PS/2, 1 x USB female... -
Page 13: Safe Guide
SAFE GUIDE Please follow the directions below when installing, using and maintaining it in order to guarantee the device to work well. When installing and operating the device, please make sure proper power supply first, and then do other operations after it is initialized. As signal and power transfer need custom cable, please use matched cable, unmatched cable may cause system work improperly or even damage the device.
