DT-QSW
CCTV Camera Interface
User Manual
Please read this manual carefully before using the product you
purchased, and keep it for future use. We reserve the right to
modify specification in this manual at any time without notice
2-Wire System
Model: QSW
Power
In-Use
CAM1
CAM3
CAM(1~4)
Camera Interface
CAM2
CAM4
Advertisement
Table of Contents
Summary of Contents for 2easy DT-QSW
-
Page 1: User Manual
DT-QSW CCTV Camera Interface User Manual 2-Wire System Camera Interface Model: QSW Power In-Use CAM1 CAM2 CAM3 CAM4 CAM(1~4) Please read this manual carefully before using the product you purchased, and keep it for future use. We reserve the right to... -
Page 2: Terminal Description
1.About DT-QSW CCTV Interface DT-QSW CCTV Interface is designed for 2-wire series system to connect up to 4 x CCTV cameras. Works as quad splitter with Aura and Alecto monitors Works with Avro and Leda monitors but not in a ‘quad’ mode. Each CCTV... - Page 3 INDICATORS: 1.Power: Working indicator, always On when the QSW works 2.In-Use: Video output indicator, always On when the QSW engaged 3.CAM(1~4): Video output indicator In-Use CAM(1~4) Description CAM1 video output CAM2 video output CAM3 video output CAM4 video output NOTE: :Indicator is ON :Indicator is OFF B.
-
Page 4: Dip Switches
DIP switches Bit State Description DIP switches configuration for first DT-QSW 3 4 5 6 DIP switches configuration for second DT-QS W 3 4 5 6 DIP1~DIP2 DIP switches configuration for third DT-QSW 3 4 5 6 DIP switches configuration for fourth DT-QSW... -
Page 5: Unit Mounting
3. Unit Mounting Step1: Mount din rail onto the wall with screws Din rail Step2: Pull down the mounting buckle and hang the unit on the din rail Din rail Mounting Buckle... -
Page 6: Wiring Diagram
4. Wiring Diagram 4.1 Single Door Station and single QSW application 1# Camera 2# Camera 3# Camera 4# Camera BUS(IM) BUS(DS) BUS(OUT) BUS(IN) RF CARD... - Page 7 4.2 Multiple Door Stations and two QSW application 1# Camera 5# Camera 2# Camera 6# Camera 3# Camera 7# Camera 4# Camera 8# Camera BUS(OUT) BUS(IN) BUS(OUT) BUS(IN) (Device Address:1) (Device Address:0) RF CARD RF CARD A B C D DBC-4A BUS(IM) BUS(DS)
-
Page 8: Specification
5. Specification • Power Supply : DC24V • Working Temperature: C~+55 • Wiring: 2 wire, no-polarity • Dimensions: H90×W72×D60mm The design and specifications can be changed without notice to the user. Right to interpret and copyright of this manual are preserved. www.intelligenthomeonline.com...
