Xicom XTU-400K Operation And Installation Manual

Hide thumbs

Advertisement

Quick Links

XTU-400K
Operation and
Installation Manual
Document Number: MN5-0184-104
Revision:
Applicable to:
This is a controlled document.
The official version of this document is located
in Xicom Technology Document Control.
Printed copies are for reference only.
408-213-3000 Phone • 408-213-3001 Fax
D
305-0184-104
3550 Bassett Street
Santa Clara, CA 95054 USA
www.xicomtech.com

Advertisement

Chapters

loading

Related Manuals for Xicom XTU-400K

Summary of Contents for Xicom XTU-400K

  • Page 1 Applicable to: 305-0184-104 This is a controlled document. The official version of this document is located in Xicom Technology Document Control. Printed copies are for reference only. 3550 Bassett Street Santa Clara, CA 95054 USA 408-213-3000 Phone • 408-213-3001 Fax...
  • Page 2 Document Number: MN5-0184-104 Revision: D Date: February 2007...
  • Page 3 Applicable to: 305-0184-104 This is a controlled document. The official version of this document is located in Xicom Technology Document Control. Printed copies are for reference only. 3550 Bassett Street Santa Clara, CA 95054 USA 408-213-3000 Phone • 408-213-3001 Fax...
  • Page 4 Xicom Technology for current technical specifications. Xicom Technology reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Xicom Technology to notify any person of such revision or changes.
  • Page 5 Figures, and List of Tables. Chapter One— Provides an overview of the manual; delineates who should use the manual; how to contact Xicom Technology. Chapter Two— Describes safety information that pertains to Xicom Technology products. It also provides information about Warnings, Cautions and Notes that are found throughout the manual.
  • Page 6 XTU-400K Operation and Installation Manual Who should use this manual This manual is designed for use by trained operators and technicians who have a thorough knowledge of satellite transmitting and receiving equipment. Persons using this manual should familiarize themselves with the information in the Appendices before reading the main sections.
  • Page 7 XTU-400K Operation and Installation Manual Record of Changes ELECTRONIC APPROVAL. SEE PLM. Revision ECO Description Date Initiated By 9849 Original Release 05/29/2002 ALCjr 10125 Replace MNC-0500-013 with 08/07/2002 ALCjr MNC-0000-015 11383 Update Interconnect Drawings 08/15/2003 ALCjr 14886 Update Table of Contents...
  • Page 8 XTU-400K Operation and Installation Manual Table of Contents Paragraph Title Page Number List of Abbreviations, Acronyms, and CE Symbols MNC-0000-010 Chapter 1 Overview MNC-0100-003 Chapter 2 Safety MNC-0200-001 Chapter 3 Unpacking and Installation MNC-0300-003 Chapter 4 Operation MNC-0400-001 Chapter 5...
  • Page 9 List of Abbreviations, Acronyms, and CE Symbols List of Abbreviations, Acronyms, and CE Symbols Record of Changes ELECTRONIC APPROVAL. SEE PLM. Revision ECO Description Date Initiated By 9735 Original Release 04/17/2002 A.L. Crozier, Jr. 10179 Add numerous abbreviations 08/21/2002 A.L. Crozier, Jr. 10646 Add more abbreviations;...
  • Page 10 MNC-0000-010 2 of 10 Revision A7...
  • Page 11 List of Abbreviations, Acronyms, and CE Symbols List of Abbreviations, Acronyms, and CE Symbols References The following documents are used as reference material for this chapter: International Standard ISO-7000: 1989. Graphical symbols for use on • equipment — Index and synopsis International Standard CEI/IEC 60417-2: 1998.
  • Page 12 List of Abbreviations, Acronyms, and CE Symbols Abbreviation or Definition Acronym BDELIM band elimination binary digit beamwidth btry battery Block Upconverter buzzer bandwidth °C degree Celsius calibration CATE computer aided test equipment component board CCTWT Coupled Cavity Traveling Wave Tube commsat communications satellite central processing unit...
  • Page 13 List of Abbreviations, Acronyms, and CE Symbols Abbreviation or Definition Acronym helix voltage °F degree Fahrenheit farad First Article Test field-effect transistor FGIPA Fixed Gain Intermediate Power Amplifier freq frequency Filament Time Delay (TWTA, KPA) Giga (one billion) Giga Hertz henry Process using a high voltage power supply to verify high voltage Hi-pot...
  • Page 14 List of Abbreviations, Acronyms, and CE Symbols Abbreviation or Definition Acronym Line Driver Amplifier Light Emitting Diode Local Oscillator Low Power Amplifier Mega (million) M&C Monitor and Control milli Ampere MSDC Multistage Depressed Collector Mega Hertz miprcs microprocessor Modular Power Supply MSDC Multi-Stage Depressed Collector mean sea level...
  • Page 15 List of Abbreviations, Acronyms, and CE Symbols Abbreviation or Definition Acronym In a standard 19-inch rack, a set of four mounting holes spaced as follows: .625 inches between holes 1, 2, and 3. .5 inches between holes three and four. RU = 1.75 inches.
  • Page 16 Xicom Technology Controller Xicom Technology Digital Outdoor Amplifier Xicom Technology Klystron Amplifier XTKD Xicom Technology Klystron Amplifier with Flat Display Xicom Technology Klystron High Efficiency Amplifier — Flat XTKH Display with Multistage Depressed Collector XTPS Xicom Technology Power Supply XTRD...
  • Page 17 List of Abbreviations, Acronyms, and CE Symbols CE Symbols Symbol Definition Alternating Current (AC) CE Marking symbol for equipment and documentation meeting European Quality Standards. Earth Ground Fuse Input Local OFF for a part of equipment ON for a part of equipment MNC-0000-010 9 of 10 Revision A7...
  • Page 18 List of Abbreviations, Acronyms, and CE Symbols Symbol Definition Output Power OFF Power ON Protective Earth Ground Remote Reset Transmitted Power Monitor MNC-0000-010 10 of 10 Revision A7...
  • Page 19 Overview, Digital ODU HPAs Record of Changes Revision ECO Description Date Initiated By 9295 Original Release 11/29/2001 A.L. Crozier, Jr. 10359 Update Contacting Xicom Technology 10/14/2002 A.L. Crozier, Jr. paragraph 11301 Update to reflect Waveguide Switching 08/08/2003 A.L. Crozier, Jr. MNC-0100-003 Revision C...

  • Page 20: Table Of Contents

    Contacting Xicom Technology ........

  • Page 21: Overview

    Overview, Digital ODU HPAs Overview, Digital ODU HPAs Product Overview This manual is for the Xicom Technology ODU (Outdoor Unit) Power Amplifier with microprocessor control. The ODU may be mounted on an antenna or other outdoor location without the need for an additional watertight enclosure.

  • Page 22: Figure 1, Typical Odu Antenna Mount Amplifier Block Diagram

    Overview, Digital ODU HPAs Figure 1, Typical ODU Antenna Mount Amplifier Block Diagram MNC-0100-003 Revision C...

  • Page 23: Physical Characteristics

    Refer to Appendix titled Mechanical Drawings for the Physical Characteristic Specifications of your amplifier. The Xicom ODUs are air cooled where the outside cooling air does not pass through the microwave tube and power supply enclosure. The tube and power supply are conduction cooled. They are mounted on a thick, finned aluminum plate.

  • Page 24: Contacting Xicom Technology

    Overview, Digital ODU HPAs Contacting Xicom Technology Assistance If you need to contact Xicom Technology for assistance with your product you may use one of the following: Address: Xicom Technology 3550 Bassett Street Santa Clara, CA 95054 USA Telephone: 408-213-3000 Facsimile: 408-213-3001 www.xicomtech.com...
  • Page 25 Safety/Sicherheit Safety/Sicherheit Record of Changes Revision ECO Description Date Initiated By Preliminary Release 08/2001 A.L. Crozier, Jr. Format changes 08/2001 A.L. Crozier, Jr. Format change—Table of Contents, List 09/2001 A.L. Crozier, Jr. of Figures, List of tables 9183 Original Release 10/12/2001 A.L.
  • Page 26 Safety/Sicherheit Table of Contents Paragraph Title Page Number Safety/Sicherheit............. . . 3 General Information .

  • Page 27: Safety/Sicherheit

    Safety/Sicherheit Safety/Sicherheit General Information This chapter identifies the safety requirements to be applied when performing any of the procedures specified in this manual. It is the responsibility of the user to follow all applicable safety regulations when using this manual. This chapter contains safety summaries consisting of general safety and health precautions.
  • Page 28 Safety/Sicherheit WARNING — A procedure, technique, restriction, etc., if not followed exactly, could result in injury or death to personnel. WARNING This symbol denotes an ELECTRICAL SHOCK HAZARD WARNING in a procedural step and is used whenever death or injury to personnel could result from electrical shock.

  • Page 29: General Warnings And Cautions

    Safety/Sicherheit Note — A procedure, technique, restriction, special interest, etc., that requires emphasis or consideration for the performance of a procedural step or steps. Note This symbol denotes a NOTE in a procedural step. A NOTE is used whenever emphasis or consideration for the performance of a procedural step or steps is necessary.

  • Page 30: Ladder Hazards

    Safety/Sicherheit WARNING To prevent electrical shock when servicing a Klystron Tube or a 2 kW Power Amplifier: ensure the Bus Indicator LED located in the Power Supply Drawer • High Voltage side is out. use shorting probe before taking measurements on the capacitor •...

  • Page 31: Rf Radiation Hazards

    Safety/Sicherheit RF Radiation Hazards WARNING The power amplifier is capable of generating high power microwave radiation that can cause bodily harm. Prior to operation ensure that: the technician assigned to perform the maintenance does not wear • a pacemaker. all the microwave connections are securely fastened. •...

  • Page 32: Sicherheit

    Safety/Sicherheit Sicherheit Allgemeine Information Dieses Kapitel benennt die Sicherheitsvorkehrungen, die bei der Durchführung eines jeden in diesem Handbuch angeführten Verfahrens getroffen werden müssen. Der Benutzer ist bei der Verwendung dieses Handbuches verpflichtet, alle zutreffenden Sicherheitsvorschriften zu befolgen. Dieses Kapitel fasst allgemeine Sicherheitsbestimmungen und Gesundheitsschutz zusammen.
  • Page 33 Safety/Sicherheit WARNUNG —Wenn ein Verfahren, eine Technik, Einschränkung usw. nicht genau befolgt werden, könnte dies zur Verletzung oder zum Tode von Mitarbeitern führen. WARNUNG Dieses Symbol bedeutet eine WARNUNG VOR DER GEFAHR EINES ELEKTRISCHEN SCHLAGES bei einem Verfahrensschritt und wird stets verwendet, wenn Mitarbeiter durch einen elektrischen Schlag getötet oder verletzt werden könnten.

  • Page 34: Allgemeine Warnungen Und Vorsichtshinweise

    Safety/Sicherheit Hinweis Dieses Symbol bedeutet einen HINWEIS bei einem Verfahrensschritt. Ein HINWEIS wird stets verwendet, wenn bei der Durchführung eines Verfahrensschrittes oder mehrerer Verfahrensschritte Nachdruck oder Berücksichtigung erforderlich sind. Allgemeine Warnungen und Vorsichtshinweise Hochspannungsgefahren WARNUNG Der Leistungsverstärker des ODU (Outdoor Unit/Gerät für den Außenbereich) ist nicht mit internen Sicherheits- Verriegelungsschaltern ausgerüstet.
  • Page 35 Safety/Sicherheit WARNUNG Zur Vermeidung eines elektrischen Schlages bei der Wartung einer Klystron Röhre oder eines 2 kW Leistungsverstärkers: stellen Sie sicher, dass die auf der Hochspannungsseite der • Stromversorgung befindliche Bus-LED-Anzeige erloschen ist. benutzen Sie eine Kurzschluss-Sonde, bevor Sie Messungen an •...

  • Page 36: Gefahren Bei Leiterbenutzung

    Safety/Sicherheit Gefahren bei Leiterbenutzung WARNUNG Wenn Sie eine Leiter benutzen müssen, stellen Sie sicher, dass: der Boden im Bereich der Leiteraufstellung frei von Gegenständen • ist, die zur Instabilität der Leiter führen könnten. Sie ALLE an der Leiter angebrachten Etiketten gelesen und •...

  • Page 37: Magnetfeld

    Safety/Sicherheit Magnetfeld Vorsicht Eine Mikrowellenröhre hat ein sehr starkes magnetisches Feld. Die Röhre kann beschädigt werden, wenn sie in Kontakt mit magnetischen Objekten oder Werkzeugen kommt. WAS SIE NICHT DÜRFEN: den Verstärker auf einer magnetischen Lagerfläche abstellen. • für Aufbau, Wartung oder Reparatur magnetisches Werkzeug •...
  • Page 38 Safety/Sicherheit MNC-0200-001 14 of 14 Revision E...
  • Page 39 Unpacking and Installation, TWTA Octagon CPU Unpacking and Installation, TWTA Octagon CPU Record of Changes Revision ECO Description Date Initiated By 9295 Original Release 11/29/2001 A.L. Crozier, Jr. 9933 Add information for Tri-band Power 06/21/2002 A.L. Crozier, Jr. Connector 10096 Replace Fig. 7 07/14/2002 A.L.
  • Page 40 Unpacking and Installation, TWTA Octagon CPU Table of Contents Paragraph Title Page Number Unpacking and Installation, TWTA Octagon CPU ......5 Unpacking and Inspection .
  • Page 41 Unpacking and Installation, TWTA Octagon CPU List of Figures Paragraph Title Page Number Figure 1 , Typical 4 Screw Mounting Flange Tightening Sequence....8 Figure 2 , Typical 8 Screw Mounting Flange Tightening Sequence....8 Figure 3 , Connector J2 Pinout for Standard Unit .
  • Page 42 Unpacking and Installation, TWTA Octagon CPU List of Tables Paragraph Title Page Number Table 1 , Recommended Waveguide Flange Torque ......9 Table 2 , Monitor and Control Connector Pinouts .

  • Page 43: Unpacking And Installation, Twta Octagon Cpu

    Unpacking and Installation, TWTA Octagon CPU Unpacking and Installation, TWTA Octagon CPU Note This document is intended for outdoor TWTAs and other related products with Octagon microprocessors. Unpacking and Inspection Inspect the inside and outside of the shipping container for signs of damage.

  • Page 44: Waveguide Connection

    Xicom recommends the use of Kapton® tape, 3M Brand, #92, Xicom P/N 602-0001-001. Remove tape or cap prior to final installation. Failure to comply could result in contamination to the internal waveguide system or TWT and equipment damage.
  • Page 45 Band abgedeckt werden, das beim Entfernen keine Kleberrückstände hinterlässt. Xicom empfiehlt die Verwendung von Kapton® Band, 3M Brand, #92, Xicom P/N 602-0001-001. Band oder Kappe vor der endgültigen Aufstellung entfernen. Nichtbefolgen könnte Verunreinigung des internen Hohlleitersystems oder Beschädigung von TWT und Gerät zur Folge haben.
  • Page 46 Unpacking and Installation, TWTA Octagon CPU 5. Tighten all mounting screws with the appropriate size Allen wrench. 6. Use a sequential tightening procedure. Refer to Table 1. Proceed as follows: Partially tighten one of the screws (#1). • Move the tool to the screw that is diagonally opposite to the screw •...

  • Page 47: Air Ducting Installation

    Unpacking and Installation, TWTA Octagon CPU Table 1, Recommended Waveguide Flange Torque Threads per Recommended Torque Screw Size Inch (inch-lb) No. 4 No. 6 No. 8 No. 10 Air Ducting Installation The power amplifier is cooled with a built-in fan. Heated exhaust air should not be recirculated into the power amplifier.

  • Page 48: Power And Interface Interconnections

    Unpacking and Installation, TWTA Octagon CPU Power and Interface Interconnections When performing the procedures in this section refer to the Wiring and Interconnect Drawings for your specific amplifier. These drawings are located in the appendix titled Interconnect Drawings. Prime Power Connections The AC Prime Power receptacle is located on the amplifier front panel.

  • Page 49: External Interlock (Prime Power Enable)

    Unpacking and Installation, TWTA Octagon CPU Figure 4, Connector J2 Pinout for EIK Unit Some amplifiers may have an MS connector. Refer to Figure 5 , MS Connector J2 Pinout. Figure 5, MS Connector J2 Pinout Refer to the Outline Drawing in the appendix titled Mechanical Drawings.

  • Page 50: Monitor And Control Connector

    Unpacking and Installation, TWTA Octagon CPU Monitor and Control Connector To externally control the amplifier a M&C interface is provided. The connector is a 32-pin MIL style waterproof connector. The Monitor and Control connector provides these interfaces for the use of the customer: COM1 —...
  • Page 51 Unpacking and Installation, TWTA Octagon CPU See the appendix titled Specifications for the pinouts on your amplifier. Table 2, Monitor and Control Connector Pinouts Signal Name RS-232 RS-232 RS-232 RS-232 RS-232 RS-232 RS-232 RS-232 RS-232 System GND RS-422/485 Transmit + RS-422/485 Transmit - RS-422/485...

  • Page 52: Redundancy Interface (Waveguide Switch) Connector (J6)

    Unpacking and Installation, TWTA Octagon CPU Redundancy Interface (Waveguide Switch) Connector (J6) Provides control and status indication for Waveguide Switch position. Refer to Table 3 and Figure 8. Passes RF Inhibit command during the switching operation or Waveguide Switch failure. Sends and receives Summary fault from primary amplifier in redundant system (Automatic Mode Only).

  • Page 53: Rf Inhibit Control (J1-Y)

    Unpacking and Installation, TWTA Octagon CPU Figure 8, Waveguide Switch Connector Pinouts RF Inhibit Control (J1-Y) The TWTA has the capability to Inhibit RF. If the unit has a SSA preamplifier, inhibit is accomplished by turning off the SSA. If the unit does not have a SSA preamplifier, the RF Inhibit command is factory set to disable high voltage to the tube.
  • Page 54 Unpacking and Installation, TWTA Octagon CPU Figure 9, RF Inhibit with Internal Source Figure 10, RF Inhibit with External Source Mixing internal and external references can result in damage to the equipment if there is a difference in ground potential between the controller and the TWTA.

  • Page 55: Serial Interface Ports (J1-A To J1-R)

    Unpacking and Installation, TWTA Octagon CPU Figure 11, RF Inhibit with Switch A Open Serial Interface Ports (J1-A to J1-R) Dual serial interface connectors (COM1 and COM2) are available for remote control operation. Both serial interface ports are always enabled. The amplifier will respond to commands from either interface.
  • Page 56 Unpacking and Installation, TWTA Octagon CPU Figure 12, Typical RS-485 2-Wire Duplex Implementation Figure 13, Typical RS-485 4-Wire Full Duplex Implementation MNC-0300-003 18 of 22 Revision N...

  • Page 57: Summary Fault Indicators (J1-S To J1-X)

    Unpacking and Installation, TWTA Octagon CPU Note Refer to Table 2“, Monitor and Control Connector Pinouts,” on page 13 for the definition of the pins listed in the following paragraphs. Summary Fault Indicators (J1-S to J1-X) Two sets of Form C relay contacts (Summary Fault A and Summary Fault B) are used to indicate that a fault has occurred.

  • Page 58: Local Operation

    Nichtbefolgen könnte die Verletzung oder den Tod von Menschen zur Folge haben. Local Operation Xicom Technology digital outdoor units have a built-in microprocessor for Monitor and Control using Xicom Standard Protocol. Refer to the chapter titled Amplifier Communication and Protocol for detailed information.
  • Page 59 Unpacking and Installation, TWTA Octagon CPU 2. Connect the amplifier to the primary power source. 3. Place the Local/Remote Override Switch in the Local position. 4. Turn the Primary Power Switch ON. 5. The LED indicator on the front panel of the unit will blink AMBER while the unit is in the Heater Time Delay Mode.
  • Page 60 Unpacking and Installation, TWTA Octagon CPU MNC-0300-003 22 of 22 Revision N...
  • Page 61 Operation, Rack and Digital HPAs Operation, Rack and Digital HPAs Record of Changes Revision ECO Description Date Initiated By Preliminary Release 08/2001 A.L. Crozier, Jr. Incorporate changes created by 08/2001 A.L. Crozier, Jr. Firmware 4.14 Format Change—Table of Contents, 09/2001 A.L.
  • Page 62 Operation, Rack and Digital HPAs Table of Contents ParagraphTitle Page Number Operation, Rack and Digital HPAs......... 7 Overview.
  • Page 63 Operation, Rack and Digital HPAs Table of Contents ParagraphTitle Page Number Menutrees............40 Initial Setup and Operation .
  • Page 64 Operation, Rack and Digital HPAs List of Figures Number Title Page Number Figure 1, Rackmount Front Panel LED Display ....... 8 Figure 2, Status Menu 1 Display and Softkeys .
  • Page 65 Operation, Rack and Digital HPAs List of Tables Number Title Page Number Table 1, LED Indicator Definitions ......... 8 Table 2, Keyboard Functions .
  • Page 66 Operation, Rack and Digital HPAs MNC-0400-001 6 of 54 Revision G...

  • Page 67: Operation, Rack And Digital Hpas

    Operation, Rack and Digital HPAs Operation, Rack and Digital HPAs Overview The Xicom Digital M&C System, which is incorporated into all Xicom XTD and XTRD series amplifiers provides a common user interface for the entire line of Microwave Tubes. The M&C...

  • Page 68: Front Panel Display And Softkeys

    Operation, Rack and Digital HPAs Figure 1, Rackmount Front Panel LED Display Table 1, LED Indicator Definitions Nomenclature Color Functional Description (When lit) Power Green Indicates AC Power Switch (circuit breaker) is ON, and prime power is applied to amplifier. Amber Filament Time Delay cycle (FTD) in process.

  • Page 69: Front Panel Keyboard

    Operation, Rack and Digital HPAs A discussion of the function of each associated softkey is included with the discussion of each menu or screen. A compressed menutree showing all the menus and screens is included as Figure 18, Figure 19, and Figure 20 as an aid to the operators.

  • Page 70: Enable Key

    Operation, Rack and Digital HPAs Table 2, Keyboard Functions Key Name Function HV On Pressed to set amplifier high voltage ON (Used in conjunction with Enable key when Enable key is ON.) HV OFF Pressed to set amplifier high voltage OFF (Used in conjunction with Enable key when Enable key is ON.) Setup Pressed to display SETUP Menu 1 (Always used in conjunction with...

  • Page 71: Ac Power Switch

    Operation, Rack and Digital HPAs AC Power Switch The AC Power Switch, which is a circuit breaker, is located on the rear panel of the amplifier. The switch toggle is pressed UP to apply prime power to the amplifier. Note The AC Power Switch on multiple drawer TWTA Racks is located on the rear panel of the Power Supply Drawer Assembly.
  • Page 72 Operation, Rack and Digital HPAs Table 3, Summary Record, Amplifier Operating Parameters Amplifier Amplifier Amplifier Amplifier Amplifier Amplifier Parameter No. 1 No. 2 No. 3 No. 4 No. 5 No. 6 Poll Address RF Output Power Setting Watts Max. Refl Power? Set Point* Alarm On/Off Fault On/Off...

  • Page 73: Menu And Screen Descriptions

    Operation, Rack and Digital HPAs Menu and Screen Descriptions There are four functional groups of menus and screens: 1 The Status 1 Menus and Screens 2. The Status 2 Menus and Screens 3. The Setup Menus and Screens 4. The Fault Menus and Screens Startup Screen When The AC Power Switch is set to ON, the Startup Screen is displayed for a few seconds, then the Startup Screen is...
  • Page 74 Operation, Rack and Digital HPAs Two of the Status 1 Menu softkeys are active. The functions of the active Status 1 Menu softkeys are: [Softkey 1]--Temporarily changes the units used for the RF power data display. Cycles one step each time [Softkey1] key is pressed.
  • Page 75 Operation, Rack and Digital HPAs Figure 6, Status 1 Menu Note The information within the dotted portion of Figure 6 is for illustrative purposes only. This information is not displayed on the amplifier front panel display MNC-0400-001 15 of 54 Revision G...

  • Page 76: Status 2 Menus And Screens

    Operation, Rack and Digital HPAs The bottom line of the STATUS 1 Menu can have three different messages: If the amplifier is set up to automatically turn high voltage ON when • prime power is applied, the message will be AUTO HIGH VOLTAGE ON Note To disable AUTO-HIGH VOLTAGE ON, press the softkey to the right...
  • Page 77 Operation, Rack and Digital HPAs Power Out—The current RF output power of the amplifier. The RF output is continuously monitored and displayed on this menu. Atten Set—The current attenuator setting. This is only available when High Voltage is OFF. RFLTD PWR—The current value of reflected power present at the output of the amplifier.
  • Page 78 Operation, Rack and Digital HPAs Note The information within the dotted portion of Figure 7 is for illustrative purposes only. This information is not displayed. MNC-0400-001 18 of 54 Revision G...

  • Page 79: Setup Menu System

    Operation, Rack and Digital HPAs Figure 7, Status 2 and Displayall Menus Setup Menu System The Setup Menus are used to customize the amplifier to meet user interface and operational requirements. Entries made via the Setup Menus change the amplifier default parameters and operation.

  • Page 80: Default Menus

    Operation, Rack and Digital HPAs There are five setup menus, Setup Menu 1, Setup Menu 2, Setup Menu 3, Setup Menu 4, and Setup Menu 5. A special function key [Setup] is used to access the setup menus. Two keys, [Enable]+[Setup], are pressed to access the Setup Menus when [Enable] is set to ON.

  • Page 81: Default Menu 2

    Operation, Rack and Digital HPAs [Softkey 1]—Toggles between LOCAL and REMOTE. Factory default is LOCAL. When in Remote the amplifier status cannot be controlled; that is, turn high voltage on or off from the front panel. [Softkey 2]—Changes the default values for the units used for the RF power data display.
  • Page 82 Operation, Rack and Digital HPAs WARNING There are no high voltage interlocks installed on the ODU amplifiers. To prevent electric shock when performing maintenance, turn the AUTO HIGH VOLTAGE ON function OFF. Failure to comply could result in serious injury or death. WARNUNG In die ODU Verstärker sind keine Hochspannungs- Verriegelungsschalter eingebaut.

  • Page 83: Buzzer Volume Menu

    Operation, Rack and Digital HPAs Buzzer Volume Menu The Buzzer Volume Menu (Figure 9) allows you to enable or disable the audio alarm and to set the volume level of the alarm. Three of the softkeys of the Buzzer Volume Menu are active. The Buzzer Volume Menu softkey functions are: [Softkey 1]—Controls the audio alarm.

  • Page 84: Exiting The Default Menus

    Operation, Rack and Digital HPAs Exiting the Default Menus There are three ways to exit the Default Menus: 1 Press the [Enter] key to return to the Setup 1 Menu. 2. Press the [Status1] key to go to the Status 1 Menu. 3.

  • Page 85: Set Max Power Menu

    Operation, Rack and Digital HPAs exceeds the allowed number, the oldest entry is dropped. The GAIN control knob is used to scroll through the list of faults. Press [Enter] to return to the Alarms/Faults Menu. Set Max Power Menu The Set Max Power Menu, Figure 10 allows you to control the maximum power detection circuits.

  • Page 86: Set Min Power Menu

    Operation, Rack and Digital HPAs Set Min Power Menu The Set Min Power Menu (Figure 10) allows you to control the minimum power detection circuits. The front panel 10-key pad and three of the softkeys of the Set Min Power Menu are active. The front panel 10-key pad is used to enter the desired minimum power level.

  • Page 87: Test Menu

    Operation, Rack and Digital HPAs The front panel 10-key pad and three of the softkeys of the Set Max Reflected Power Menu are active. The front panel 10-key pad is used to enter the desired maximum reflected power level. The Set Max Reflected Power Menu softkey functions are: [Softkey 1]—Cycles one step each time the softkey is pressed.

  • Page 88: Setup 2 Menu

    Operation, Rack and Digital HPAs [Softkey 3]—Pressed to test the summary fault circuit. The Summary Fault relays will switch; the Summary Fault LED will change state and high voltage will momentarily go off. [Softkey 4]—Pressed to test the waveguide arc fault circuit. The fault line on the amplifier will change state.
  • Page 89 Operation, Rack and Digital HPAs Press [Softkey 2] to access the Offset factor Menu — This menu allows the user to adjust displayed output power up or down by a given amount (in dB). [Softkey 3] allows you to turn RF Inhibit ON or OFF. [Softkey 4] allows access to Setup Menu 3.
  • Page 90 Operation, Rack and Digital HPAs Figure 11, Setup Menu 2 MNC-0400-001 30 of 54 Revision G...

  • Page 91: Constant Power Sub-Menu

    Operation, Rack and Digital HPAs Constant Power Sub-menu The amplifiers can be setup to automatically maintain RF output power at a preset level. The front panel 10-key pad and one of the softkeys of this menu are active. The softkey functions are: [Softkey 1]—Enables or disables the Constant Power function.

  • Page 92: Setup Menu 3

    Operation, Rack and Digital HPAs Setup Menu 3 Setup Menu 3 allows you to: Set the time and date used for alarm and fault recording. • Select linearizer, if installed, and adjust phase and amplitude. • Select band. • Setup Menu 3, Figure 12 provides access to the Time/Date Menu, the Linearization Menu, the Calibrate Attenuator Menu, and Setup Menu 4.

  • Page 93: Setup Menu 4

    Operation, Rack and Digital HPAs Figure 12, Setup Menu 3 Setup Menu 4 Setup Menu 4, Figure 13provides access to the Configure COM1, Configure COM2, Set System Address sub-menus, and Setup Menu 5 which is used to Calibrate Attenuator and Replace Firmware.

  • Page 94: Configure Com1 Menu

    Operation, Rack and Digital HPAs Figure 13, Setup Menu 4 Configure COM1 Menu Three softkeys are active: [Softkey 1]—Sets the serial port baud rate. Cycles one step each time the [Softkey 1] is pressed. The step sequence is: 1200 2400 4800 9600 19.2...

  • Page 95: Configure Com2 Menu

    Operation, Rack and Digital HPAs Configure COM2 Menu Three softkeys are active: [Softkey 1]—Sets the serial port baud rate. Cycles one step each time the [Softkey 1] is pressed. The step sequence is: 1200 2400 4800 9600 19.2 38.4 57.6 1200, etc.

  • Page 96: Setup Menu 5

    Setup Menu 5 Setup Menu 5, Figure 15 provides access to the Calibrate Attenuator and Replace Firmware submenus. This Setup Menu is to be used by Xicom Personnel only. It is shown here solely for information. Figure 15, Setup Menu 5...
  • Page 97 Operation, Rack and Digital HPAs MNC-0400-001 37 of 54 Revision G...
  • Page 98 Operation, Rack and Digital HPAs Table 4, TWTA Fault and Alarm List Fault Log Abbr. Display Name Comments fanlck Fan Lock (Will Never Happen) ovrtmp Supply Over Temp tubtmp TWT Tube Over Temp tubhot Tube Temp Fault 2kWatt only su\plhot Supply Fault 2 kWatt only vswr VSWR Reflected Power...

  • Page 99: Fault Report Displays--Latched Faults

    Operation, Rack and Digital HPAs Fault Report Displays--Latched Faults The latched fault report displays are shown in Figure 16. Latched faults must be cleared by the operator. These fault report displays all operate in the same way. When the indicated fault occurs, the fault report display replaces the current menu and (if the audio alarm is enabled) the buzzer sounds.

  • Page 100: Non-Latched Fault Report Displays

    Operation, Rack and Digital HPAs Non-latched Fault Report Displays See Figure 17. Non-latched faults clear when the fault condition occurs. The non-latched fault report does not clear when the fault clears. Operator action is required to reset the fault report display.
  • Page 101 Operation, Rack and Digital HPAs MNC-0400-001 41 of 54 Revision G...
  • Page 102 Operation, Rack and Digital HPAs Figure 18, Menutree Sheet 1 of 3 MNC-0400-001 42 of 54 Revision G...
  • Page 103 Operation, Rack and Digital HPAs Figure 19, Menutree Sheet 2 of 3 MNC-0400-001 43 of 54 Revision G...
  • Page 104 Operation, Rack and Digital HPAs Figure 20, Menutree, Sheet 3 of 3 MNC-0400-001 44 of 54 Revision G...

  • Page 105: Initial Setup And Operation

    Operation, Rack and Digital HPAs Initial Setup and Operation General The amplifier can be operated from the amplifier Front Panel (LOCAL configuration) or from a remote controller (REMOTE configuration). The amplifier is configured at the factory with the default values shown in Table 5. These values allow immediate operation of the amplifier when the amplifier is connected to an operational load or a dummy load capable of dissipating rated RF output power.
  • Page 106 Operation, Rack and Digital HPAs recorded in a power amplifier log. Amplifier run-time records are maintained by the amplifier MNC-0400-001 46 of 54 Revision G...

  • Page 107: Operating Configurations

    Note Familiarity with the XTRD menu system is required for LOCAL operation. Familiarity with the XICOM command set is required for REMOTE operation. Operating Modes The operating modes of the TWTA are described in the following sections.

  • Page 108: Standby Mode

    Operation, Rack and Digital HPAs Standby Mode In this mode, there are no faults and the TWT is ready for high voltage to be applied. Heater Standby Mode The purpose of heater standby is to extend the life to the tube when the high voltage is off.

  • Page 109: Fault Mode

    Operation, Rack and Digital HPAs Fault Mode This mode exists anytime a condition detrimental to the TWT is detected by the power supply fault detection circuitry. Faults are indicated on the front panel by red LEDs. Any of the following conditions trip the fault detection circuitry: Excessive Helix Current Fault—(Latched) When the power supply detects a Helix Current fault, it turns OFF high voltage...

  • Page 110: Clearing Alarms And Faults

    Operation, Rack and Digital HPAs WARNING ELECTRIC SHOCK HAZARD due to high voltage capacitors inside the equipment. Allow five minutes for the capacitors to completely discharge before removing lid and working in the equipment. Failure to comply could result in serious injury or death to personnel. WARNUNG GEFAHR VON ELEKTRISCHEN SCHLÄGEN wegen unter Hochspannung stehender Kondensatoren...

  • Page 111: Turn-On Sequence

    Operation, Rack and Digital HPAs 3. The RF drive signal is within the frequency range of the amplifier and +5 dBm or less with the HPA set for minimum gain (control fully counterclockwise). Caution Operate the amplifier within the power limit specification.

  • Page 112: Normal Turn-On

    Operation, Rack and Digital HPAs 9. Turn on the RF drive signal.Slowly increase the RF drive to the TWT by rotating the Gain Control clockwise. Monitor the RF output power. Caution Do not exceed the dBm input power specification. Driving the TWT by more than 2 dBm beyond the input power required to reach the saturation point will over drive the tube.

  • Page 113: Normal Turn-Off

    Operation, Rack and Digital HPAs 3. Press the [Enable] key and the [HV ON] key at the same time. The high voltage ON indicator should light (green). This indicates that high voltage is ON and applied to the TWT. The Standby and Htr Standby Indicators should turn OFF.
  • Page 114 Operation, Rack and Digital HPAs MNC-0400-001 54 of 54 Revision G...
  • Page 115 Amplifier Communication and Protocol, Octagon ISA CPU Amplifier Communication and Protocol, Octagon ISA CPU Record of Changes Revision ECO Description Date Initiated By Preliminary Release 08/2001 A.L. Crozier, Jr. Format changes 08/2001 A.L. Crozier, Jr. Format change—Table of Contents, List of 09/2001 A.L.
  • Page 116 Amplifier Communication and Protocol, Octagon ISA CPU Table of Contents Paragraph Title Page Number Amplifier Communication and Protocol, Octagon ISA CPU ......5 Overview .

  • Page 117: Paragraph Title

    Amplifier Communication and Protocol, Octagon ISA CPU List of Figures Paragraph Title Page Number Figure 1, Basic Configuration............6 MNC-0500-002 3 of 36 Revision H...
  • Page 118 Amplifier Communication and Protocol, Octagon ISA CPU List of Tables Paragraph Title Page Number Table 1, Standard Packet Format ..........9 Table 2, Packet Format (Redundant Controller—XTC-100 Family .

  • Page 119: Amplifier Communication And Protocol, Octagon Isa Cpu

    Note In this chapter, the term analog refers to devices without a serial interface. The term digital refers to devices with a serial interface (RS-232/RS-485). Xicom amplifiers typically respond to a message in less than 100 milliseconds. Communication Digital HPAs Both rack-mounted and outdoor digital HPAs have a built-in microprocessor for handling serial communications.
  • Page 120 Amplifier Communication and Protocol, Octagon ISA CPU Figure 1, Basic Configuration MNC-0500-002 6 of 36 Revision H...

  • Page 121: Protocol

    'A' and 'Z' to differentiate it from other devices. RS-485 device addresses are selected on rack HPAs using the front panel interface. They are selected on digital outdoor HPAs using Xicom's "wRemote" utility. Note If a device is not responding to your messages, check the RS-485 device address.

  • Page 122: Printable Vs. Non-Printable Protocols

    If you send a message using non-printable protocol, devices will respond using the non-printable protocol. There are no DIP switches to set, and there is no software to configure. Xicom devices always respond in kind: Printable and non-printable protocols differ only in the characters •...

  • Page 123: Communication Parameters

    Amplifier Communication and Protocol, Octagon ISA CPU Communication Parameters Communications can be configured as follows: Baud rates: 1200, 2400, 4800, 9600, 19,200, 38,400, and 57600 Parity:None, Even, or Odd Data bits:7 or 8 Stop bits:1 or 2 Flow control options should be set to "none." HPAs support 8/1 or 7/2, but not 8/2, etc.
  • Page 124 Amplifier Communication and Protocol, Octagon ISA CPU Table 3, Start Byte, End Byte, & Check Byte Packet Accept/ Protocol Start Byte End Byte Check Byte Type Reject Printable Message (ASCII){ (ASCII)} Message Response Accepted or “Base 95” Rejected Message Message Non-Printable “Exclusive OR”...

  • Page 125: Example Of "Base 95

    Amplifier Communication and Protocol, Octagon ISA CPU Example of “Base 95” Message (“ID/Version” Query): {AO} 1 Take Sum of Message Bytes ‘{‘ + ‘A’ + ‘O’ + ‘}’ 123 + 65 + 48 + 125 = 361 2. Subtract 32 361 –...
  • Page 126 Amplifier Communication and Protocol, Octagon ISA CPU Table 5, Command Reject Codes ASCII Reject Reason Character Command byte not recognized Illegal parameter or parameter out of range System in local mode Slow command being executed Hardware or Software failure High voltage is OFF RF is inhibited HPA Power is OFF Invalid key or key sequence...
  • Page 127 Amplifier Communication and Protocol, Octagon ISA CPU Table 6, ASCII Code Cross Reference CHAR CHAR CHAR ‘ < > MNC-0500-002 13 of 36 Revision H...
  • Page 128 Amplifier Communication and Protocol, Octagon ISA CPU Table 6, ASCII Code Cross Reference CHAR CHAR CHAR SPACE “ & ‘ MNC-0500-002 14 of 36 Revision H...

  • Page 129: Commands And Queries

    Amplifier Communication and Protocol, Octagon ISA CPU Commands and Queries Firmware Information The following firmware revision is baseline: TWT Amplifier (all models)3.81 All commands and queries listed herein are compatible with baseline firmware except where noted. Note Certain commands and queries require that special options be present in your unit(s).
  • Page 130 Amplifier Communication and Protocol, Octagon ISA CPU Table 8, List of Amplifier Commands Command Page AC Power Heater Standby High Voltage On High Voltage Off Fault Reset Step Attenuator Go To Power (dBW) Go To Power (Watts) Constant Power (dBW) Constant Power (Watts) Terminate Constant Power RF Inhibit...

  • Page 131: Amplifier Queries

    Amplifier Communication and Protocol, Octagon ISA CPU Amplifier Queries ID/Version Command Byte: '0' Response: "MMMMMMMVRR" MMMMMMM is the amplifier model number. V is the firmware version number. RR is the firmware revision level. Optional Parameter: “00” Returns the following: Response: "MMMM-MMM/SSSSS/V.RR" MMMM-MMM is the amplifier model number.
  • Page 132 Amplifier Communication and Protocol, Octagon ISA CPU Summary Status Command Byte: '1' Response: "AB" formatted as follows: Byte ‘B’ Bit 7: Reserved Byte 'A' Bit 6: Complement of Bit 5 Bit 7: Reserved Bit 5: Summary Fault Bit 6: Complement of Bit 5 Bit 4: Heater Standby Bit 5: Power Supply Enabled Bit 3: Output Power changed 0.2 dB since last...
  • Page 133 Amplifier Communication and Protocol, Octagon ISA CPU Fault Status Command Byte: '3' Response: "AB" formatted as follows: Byte 'B' Byte 'A' Bit 7: Reserved. Bit 7: Reserved. Bit 6: Complement of bit 5. Bit 6: Complement of bit 5. Bit 5: Under Voltage Fault. Bit 5: Latched Helix Arc Fault.
  • Page 134 Since it emulates the HPA command set, it will respond to this query, but it only returns a single 20 character string. Xicom's digital ODU has no display it internally maintains the same menu system as Xicom's digital rack HPA. A digital ODU returns four 20 character strings, each terminated by '!'.
  • Page 135 Amplifier Communication and Protocol, Octagon ISA CPU Alarm Condition Command Byte: '9' Response: One byte of alarm status, formatted as follows. Bit 7: Reserved. Bit 6: Complement of bit 5. Bit 5: High Output Power. Bit 4: Low Output Power. Bit 3: High Reflected Power (VSWR).
  • Page 136 Amplifier Communication and Protocol, Octagon ISA CPU Advanced Query Command Byte: '?' Description: The Advanced Query feature, which is included in firmware versions 3.56 and higher, is intended to streamline the user’s polling loop by allowing the user to construct custom query sequences.
  • Page 137 Amplifier Communication and Protocol, Octagon ISA CPU Parameter Information Requested Response Format 4 bytes Byte A Summary Status Byte A Byte B Summary Status Byte B Byte C Bit 7 — not used (always 0) Bit 6 — compliment of Bit 5 Bit 5 —...
  • Page 138 Amplifier Communication and Protocol, Octagon ISA CPU XX.X in dBm HV OFF or RF not detectable ‘P’ Fwd Power “<XX” XX.X in dBm HV OFF or RF not detectable ‘Q’ Reverse Power “<XX” A XX.X in dBm (generate alarm) Reverse Power Alarm/Fault ‘R’...
  • Page 139 Amplifier Communication and Protocol, Octagon ISA CPU Get Serial Configuration Command Byte: 'X' Parameters: '?' returns the configuration of the communications port that the query was received on. "1?" returns information on COM1. "2?" returns information on COM2. “R?” returns RS-485 Configuration. Response for ‘?’, ‘1?’, and ‘2?’: "CBBBBBBPDS"...

  • Page 140: Amplifier Commands

    Amplifier Communication and Protocol, Octagon ISA CPU Amplifier Commands AC Power Command Byte: '!' Function: Enables/Disables AC power to the HPA. Parameters: '0' - Disable AC power. '1' - Enable AC power. Compatibility: This command is only available for ODUs connected to a controller. The controller will intercept the command and enable or disable power to the specified amplifier.
  • Page 141 Amplifier Communication and Protocol, Octagon ISA CPU Fault Reset Command Byte: 'B' Function: Resets any of the HPA's resetable faults. Step Attenuator Command Byte: 'C' Function: Steps attenuator count up or down. The attenuator count is written to the D- to-A converter that controls the attenuation.
  • Page 142 Amplifier Communication and Protocol, Octagon ISA CPU Constant Power (dBW) Command Byte: 'F' Function: The HPA seeks the specified power level until Constant Power is terminated by Goto Power (Command Byte ‘D’ or ‘E’) or Terminate Constant Power (Command Byte ‘H’). Also called "Auto Gain Stabilization," the Constant Power (dBW) command allows the user to operate an amplifier over extended periods of time while maintaining a set power level.
  • Page 143 Amplifier Communication and Protocol, Octagon ISA CPU Clear RF Inhibit Command Byte: 'J' Function: RF drive to the TWT is enabled. Compatibility: Attenuator required. Set Attenuator Command Byte: 'K' Parameter: “XX.X” dB of attenuation OR “IX.X” to increase attenuation by X.X OR “DX.X”...
  • Page 144 Amplifier Communication and Protocol, Octagon ISA CPU Max RF Power Trip Command Byte: 'M' Function: Sets a Max RF trip point. If output power exceeds the set point, an alarm or fault is generated provided the HPA has processed an “Enable RF Limits” command ('R').
  • Page 145 Amplifier Communication and Protocol, Octagon ISA CPU Miscellaneous Setup Command Byte: 'P' Function: Miscellaneous Setup Parameters: “ZXXXX” to set linearizer amplitude, “zXXXX” to set linearizer phase. XXXX is a count between 0 and 4095. Note: You can convert counts to volts using the conversion equation V=counts*10/4096. Compatibility: Linearizer required Parameters: “CX”...
  • Page 146 Amplifier Communication and Protocol, Octagon ISA CPU Waveguide Switch Control Command Byte: ‘U’ Format: ‘U1’ Activate override mode and switch in amplifier ‘U0’ Activate override mode and switch in other amplifier ‘UM’ Activate overide mode ‘UA’ Terminate overide mode, activating automatic mode NoteS: When sending a ‘U1’...
  • Page 147 Amplifier Communication and Protocol, Octagon ISA CPU Simulate Front Panel Input Command Byte: 'V' Function: Simulates Digital Rack HPA front panel keypad/encoder input. Any/all front panel input can be simulated using this command. Combining this command with query '5', Current Screen, grants remote access to all digital HPA menus and functions.
  • Page 148 '2': Down Arrow. Notes: If communicating with an amplifier via Xicom's digital outdoor controller, reference the alternate parameter list. Otherwise, use the standard parameter list. Rack amplifiers normally require that the enable key be pressed to process certain front panel inputs.
  • Page 149 Amplifier Communication and Protocol, Octagon ISA CPU Set Serial Configuration Command Byte: 'X' Function: Configures serial communications on the specified port. Use this command carefully as it could cause you to lose communications with the amplifier. See the Get Serial Configuration query for a related command. To configure the serial port, use Parameter Format 1.
  • Page 150 Amplifier Communication and Protocol, Octagon ISA CPU MNC-0500-002 36 of 36 Revision H...

  • Page 151: Preventive Maintenance

    Preventive Maintenance Preventive Maintenance Record of Changes Revision ECO Description Date Initiated By 9295 Original Release 11/29/2001 A.L. Crozier, Jr. 9664 Update Record of Changes page to 03/19/2002 A.L. Crozier, Jr. remove chapter number. 11429 Add paragraph about spare HPA 08/25/2003 A.L.
  • Page 152 Preventive Maintenance Table of Contents Paragraph Title Page Number Preventive Maintenance ..........3 Requirements .

  • Page 153: Requirements

    Lower Deck Cover. • Spare Amplifiers To ensure the working integrity of spare amplifiers, within the first 6 months following delivery, Xicom Technology recommends: that spare amplifiers be fitted with an output waveguide load. • AC power turned ON.

  • Page 154: Maintenance Procedures

    Preventive Maintenance Maintenance Procedures Lower Deck Perform the following procedure to remove, inspect, and clean the Lower Deck Cover. 1 Turn the Power Amplifier OFF. 2. Disconnect the Prime Power. 3. Remove and retain the self-locking screws. Refer to the appendix titled Mechanical Drawings.

  • Page 155: United States

    Preventive Maintenance the manufacturers, importers and users are responsible for the proper disposal or recycling of batteries. In accordance with these directives, the TL-5242/W battery contains no dangerous substances. The reaction products are inorganic and do not represent environmental hazards once the decomposition or neutralization process has terminated.

  • Page 156: Europa

    Preventive Maintenance vertraut ist. Wir empfehlen Ihnen, sich mit Ihrem örtlichen Büro der Bundesbehörde für Umweltschutz in Verbindung zu setzen. Europa Die Europäische Gemeinschaft (EG) hat zwei Direktiven erlassen: 91/157/EEC und 93/86/EEC. Diese Direktiven werden von den einzelnen Mitgliedsländern unterschiedlich umgesetzt. Daher sind in jedem Land die Hersteller, Importeure und Benutzer für die vorschriftsmäßige Entsorgung oder die Wiederaufbereitung von Batterien verantwortlich.
  • Page 157 Service and Repair Service and Repair Record of Changes Revision ECO Description Date Initiated By Preliminary Release 08/2001 A.L. Crozier, Jr. Incorporate RMA Form and format 08/2001 A.L. Crozier, Jr. change Format changes—Table of Contents, 09/2001 A.L. Crozier, Jr. List of Figures, List of Tables 9183 Original Release 10/12/2001 A.L.
  • Page 158 Service and Repair Table of Contents Paragraph Title Page Number Service and Repair ........... . 3 Introduction.

  • Page 159: Return Authorization

    Facsimile: 408-213-3107 email: CustSupport@xicomtech.com Or you may use the online RMA request form located on the Xicom Technology Web Site: www.xicomtech.com/support/support.htm Figure 1 on page 5 is an example of the RMA Form. When corresponding with Xicom Technology always refer to the equipment by the model number, part number and serial number.
  • Page 160 Mark the container with the words FRAGILE, DELICATE INSTRUMENT. HANDLE WITH CARE on each side of the container. Ship the container to the following address: XICOM TECHNOLOGY 3550 Bassett Street Santa Clara, CA 95054 RMA #__________________...
  • Page 161 PLEASE NOTE - Units returned during the Warranty period that are found to be problem free will be charged the minimum evaluation fee. FOR ALL OUT OF WARRANTY UNITS: Xicom Technology will not proceed with the repair until we have a purchase order in place.
  • Page 162 Service and Repair MNC-0700-001 Revision F...
  • Page 163 TWTA SPECIFICATION XTU-400K, II, 13.75-14.5, DIG, DET RF, VGIPA This document is best viewed using the Times New Roman font TH IS DOC UME N T I S TH E PR OPER TY OF X ICO M TEC HNO LO G Y. REPR OD UC TI ON OR R EL EAS E WI THO UT E XPRE SS P ERM IS SIO N IS S TR IC TL Y PRO HI BI TED .
  • Page 164 TH I S DO C UM EN T IS TH E PR OP ER TY O F X IC O M TE C HN OL O G Y. RE PRO D UC TI O N OR R E L EA SE W I TH O UT E X PR ESS PER M IS S IO N IS S TR IC TL Y PR OH IBI TE D . XTU-400K, II, 13.75-14.5, DIG, DET RF, VGIPA Document No.
  • Page 165 TH I S DO C UM EN T IS TH E PR OP ER TY O F X IC O M TE C HN OL O G Y. RE PRO D UC TI O N OR R E L EA SE W I TH O UT E X PR ESS PER M IS S IO N IS S TR IC TL Y PR OH IBI TE D . XTU-400K, II, 13.75-14.5, DIG, DET RF, VGIPA Document No.
  • Page 166 TH I S DO C UM EN T IS TH E PR OP ER TY O F X IC O M TE C HN OL O G Y. RE PRO D UC TI O N OR R E L EA SE W I TH O UT E X PR ESS PER M IS S IO N IS S TR IC TL Y PR OH IBI TE D . XTU-400K, II, 13.75-14.5, DIG, DET RF, VGIPA Document No.
  • Page 167 TH I S DO C UM EN T IS TH E PR OP ER TY O F X IC O M TE C HN OL O G Y. RE PRO D UC TI O N OR R E L EA SE W I TH O UT E X PR ESS PER M IS S IO N IS S TR IC TL Y PR OH IBI TE D . XTU-400K, II, 13.75-14.5, DIG, DET RF, VGIPA Document No.
  • Page 168 TH I S DO C UM EN T IS TH E PR OP ER TY O F X IC O M TE C HN OL O G Y. RE PRO D UC TI O N OR R E L EA SE W I TH O UT E X PR ESS PER M IS S IO N IS S TR IC TL Y PR OH IBI TE D . XTU-400K, II, 13.75-14.5, DIG, DET RF, VGIPA Document No.

  • Page 169: Serial Number

    TH I S DO C UM EN T IS TH E PR OP ER TY O F X IC O M TE C HN OL O G Y. RE PRO D UC TI O N OR R E L EA SE W I TH O UT E X PR ESS PER M IS S IO N IS S TR IC TL Y PR OH IBI TE D . XTU-400K, II, 13.75-14.5, DIG, DET RF, VGIPA Document No.
  • Page 170 TH I S DO C UM EN T IS TH E PR OP ER TY O F X IC O M TE C HN OL O G Y. RE PRO D UC TI O N OR R E L EA SE W I TH O UT E X PR ESS PER M IS S IO N IS S TR IC TL Y PR OH IBI TE D . XTU-400K, II, 13.75-14.5, DIG, DET RF, VGIPA Document No.
  • Page 171 TH I S DO C UM EN T IS TH E PR OP ER TY O F X IC O M TE C HN OL O G Y. RE PRO D UC TI O N OR R E L EA SE W I TH O UT E X PR ESS PER M IS S IO N IS S TR IC TL Y PR OH IBI TE D . XTU-400K, II, 13.75-14.5, DIG, DET RF, VGIPA Document No.
  • Page 172 TH I S DO C UM EN T IS TH E PR OP ER TY O F X IC O M TE C HN OL O G Y. RE PRO D UC TI O N OR R E L EA SE W I TH O UT E X PR ESS PER M IS S IO N IS S TR IC TL Y PR OH IBI TE D . XTU-400K, II, 13.75-14.5, DIG, DET RF, VGIPA Document No.
  • Page 182 Operation Addendum, Block Upconverter Operation Addendum, Block Upconverter Record of Changes Revision ECO Description Date Initiated By 10125 Original Release 08/05/2002 A.L. Crozier, Jr. 10516 Add X and DBS Band Information 12/06/2002 A.L. Crozier, Jr. 12612 Add Note about 10 MHz Reference; 10/20/2004 A.L.
  • Page 183 Operation Addendum, Block Upconverter Table of Contents Paragraph Title Page Number Operation Addendum, Block Upconverter ........3 Overview.
  • Page 184 Figure 1, Typical Block Diagram of a High Power Amplifier with Block Upconverter. Note If the modem being used does not have the IF multiplexed with the reference, a dixplexer is available from Xicom (Part Number: 545-0021-001) to combine the two signals. Note Xicom offers SSPA/HPA Block Upconverter options with an internal 10 MHz reference.

  • Page 185: Functional Description

    Operation Addendum, Block Upconverter Functional Description The block diagram in Figure 3 provides a schematic for the BUC. Table 1 presents a frequency plan for the output of the BUC. The input of the BUC provides diplexing to direct the reference frequency to the LO Synthesizer and IF frequency to the mixer.
  • Page 186 Operation Addendum, Block Upconverter Figure 3, Detailed BUC Block Diagram MNC-0000-015 5 of 8 Revision C...
  • Page 187 Operation Addendum, Block Upconverter Table 1, BUC Output Frequency Plan Band LO Freq IF Freq Output Freq .950 5.85 1.550 6.45 1.750 6.65 6.95 0.95 1.45 12.80 .950 13.75 1.700 14.5 13.05 0.95 14.0 1.45 14.5 16.35 0.95 17.3 1.75 18.1 Notes: 1) RF = IF + LO...
  • Page 188 RF sample port. In the event that the frequency drifts outside the acceptable range, the unit must be either re-aligned by a Xicom certified maintenance center or alternatively the modem L Band output must be adjusted to correct the output frequency. Adjusting the L Band modem frequency is the simplest method and is recommended.
  • Page 189 Operation Addendum, Block Upconverter Figure 4, Drift Compensation Block Diagram MNC-0000-015 8 of 8 Revision C...
