1Location of the Data Link Connector (DLC)
The DLC (Data Link Connector or Diagnostic Link Connector) is the standardized
16-cavity connector where diagnostic scan tools interface with the vehicle's on-board
computer. The DLC is usually located 12 inches from the center of the instrument
panel (dash), under or around the driver's side for most vehicles. If Data Link
Connector is not located under dashboard, a label should be there telling location. For
some Asian and European vehicles, the DLC is located behind the ashtray and the
ashtray must be removed to access the connector. If the DLC cannot be found, refer to
the vehicle's service manual for the location.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Creader VIII and is the answer not in the manual?

Questions and answers

Gilles COTE
March 3, 2025

Comment imprimer un rapport de diagnostique d'une voiture lorsque l'on a compléter tous les test

0

Summary of Contents for Launchf Creader VIII

  • Page 1 1Location of the Data Link Connector (DLC) The DLC (Data Link Connector or Diagnostic Link Connector) is the standardized 16-cavity connector where diagnostic scan tools interface with the vehicle's on-board computer. The DLC is usually located 12 inches from the center of the instrument panel (dash), under or around the driver’s side for most vehicles.
  • Page 2 2Diagnostic Trouble Codes (DTC) that identify which section of the emission control system has malfunctioned...
  • Page 3 OBDII/EOBD Generic OBDII Diagnostics The OBD II Diagnostics function is a fast-access option that allows you to carry out a quick test on the engine system of OBD II vehicles...

  • Page 4: Vehicle Diagnosis

    Vehicle diagnosis If the manufacturer of your vehicle is not listed, use the UP/DOWN scroll button to select Other and press the OK button.
  • Page 8 Review...
  • Page 9 Reset...
  • Page 10 3 Setings...
  • Page 11 Help...
  • Page 12 Register code...

  • Page 13: Software Update

    Software Update This function allows you to update the scan tool software through a computer. www.dbscar.com If you are a new user, slide right arrow next to Register to enter registration page...
  • Page 15 If you have registered to be a member, input your name/CC and password in Fig. 3-4, and then click the “Log In” button to enter the main menu screen directly...
  • Page 17 Doenload...
  • Page 18 Different vehicle software Different language...
