- Page 1 RE KIT ® Transceiver System for Mechanical, 10k , or 8.2k Resistive Safety Edges UL 325 Recognized Component BI-DIRECTIONAL COMMUNICATION Fixed Device RCOO900 Movable Device TCOO900 I NSTRU CTI O N MANU AL v .5. 23 .1 7...
-
Page 2: Technical Specifications
RCOO900 power supply 12/24 Vac-dc Battery duration 2 years (no rmal functioning mode). 5 years (Low Power mode). Minimum battery level (TCOO900) 1.9V Compatible safety edges (TCOO900) Mechanical (N.C. o N.O.) and/or resistive (8.2 kΩ/10kΩ). Number of outputs (RCOO900) Maximum number of Transmitters for each RCOO900 8 for each device. - Page 3 DESCRIPTION The iGAZE® RE transceiver system is intended as a safety device for automated gates and rolling doors. The system is comprised of 1 fixed device (RC00900) with 2 output relays, which is connected to the operator, and up to 8 movable devices (TC00900) for each relay.
- Page 4 EXAMPLE 2 - Both safety edges are normally closed Dip switch DIP1 OFF: mechanical safety edge 1 Frequency If you want to connect a mechanical edge on Low Power the input Safety1 (normally closed contact), you Safety2 Type Mechanical edge 2 (N.C.) Led and Safety1 Type must set dip switch 1 to «OFF».
- Page 5 EXAMPLE 5 TCOO900 with mechanical safety edge N.C. on input 1 and 8.2kΩ or 10kΩ resistive edge on input 2 Dip switch WARNING: Frequency DIP1 OFF: mechanical safety edge 1 If you want to connect a mechanical edge on Low Power Safety2 Type Resistive edge 2 8.2k /10k...
- Page 6 STEP 3 SET DIP SWITCHES 4 AND 5 ON THE TCOO900 AND 3 AND 4 ON THE RCOO900 TO THE SAME SETTINGS. RCOO900 TCOO900 3 4 5 6 3 4 5 6 Function N° DIP N° DIP Function Test device.
- Page 7 STEP 6 MOUNT THE RCOO900 AS CLOSE AS POSSIBLE TO THE TCOO900. IF MOUNTED TO A WALL, USE SUITABLE SCREWS AND ANCHORS TO SECURE THE RCOO900. STEP 7 DEPENDING ON THE TYPE OF SIGNAL REQUIRED, CONNECT THE OUTPUTS AS EXPLAIN IN THE FOLLOWING TABLE, AND ACCORDING TO THE FOLLOWING EXAMPLES.
- Page 8 Out2 10k2 Dip Switch Programming/ Reset Key 10k2 10k2 To Operator To Operator STEP 8 STEP 9 MOUNT THE IGAZE RE RCOO900 POWER THE RCOO900 WITH 12-24 VAC/DC ® INSULATED POWER SUPPLY (NOT INCLUDED WITH THE IGAZE RE KIT). ®...
- Page 9 (*) If you hear 4 BEEPS, it means that the maximum number of safety edges for the selected channel has been reached and that no new devices on the same relay can be memorized. NOTE: When the TCOO900 is used with two connected safety edges, it is necessary to carry out the learning process two times, one for each input.
-
Page 10: Receiver Reset
Check each associated device Note: If one TCOO900 is in the alarm state and it is necessary to open or close the operating device, press and keep pressed the programming / test button of the TCOO900 in alarm at the same time the operating device is activated to open or close. -
Page 11: Fcc Compliance
ENERGY SAVING (LOW POWER) With the dip switch set to low power it is important to remember that the TCOO900 will only check in with the RCOO900 every 15 seconds. If a power failure (dead battery) were to occur during this 15 second interval, the RCOO900 will only signal an alarm after the 15 second interval has been reached. -
Page 12: Troubleshooting
– refer to step 2 And if N.O. mechanical edge DIP 6 on the TCOO900 is in the ON position – refer to step 2 And if N.C. mechanical edge DIP 6 on the TCOO900 is in the OFF position – refer to step 2 Determine what type of output signal the gate operator is looking for: •...
