Summary of Contents for Mobile Create Eyelog MCG-W150

  • Page 2 Eyelog User's Manual - 1 -...
  • Page 3 Ubiquitous technology. But most of users are not satisfied with the security system with high price, difficulty of setup and handling, limited area, etc. Mobile Create Inc. was founded for creating new products users want based on users’ recognizing against undesirable trespassing or invaders in real time anytime and anywhere, and easy changing and setup.

  • Page 4: Table Of Contents

    Table of Contents Chapter 1. Setup Guide------------------------------------------------------------- 6 Chapter 1. Setup Guide 1. Prepare the Parts ---------------------------------------------------- 7 1.1 Functions of Keypads -------------------------------------------8 1.2 LCD Icons --------------------------------------------------------9 2. Insert SIM Card ------------------------------------------------------10 3. Insert Battery ------------------------ ------------------------------- 11 4 S it hi 4.
  • Page 5 PRECAUTIONS Warnings Please carefully read the device instruction and safety precautions booklet included with this product before using your Eyelog MCG-W150. This booklet contains important device manual and safety information Cautions 1. Handle the battery with care.  Do not use excessive force or sharp objects when handling the battery.

  • Page 6: Package Contents

    Package contents ② Battery ③ TA Adapter ④ Data Cable ① Eyelog Device • It is separate way to purchase the IR LED Dongle. It will included in your package if you purchase IR LED Dongle. - 5 -...

  • Page 7: Chapter 1 Setup Guide Chapter 1. Setup Guide

    Chapter 1 Setup Guide Chapter 1. Setup Guide  Quick starting to make device “Guard on”  Quick starting to make device Guard on 1. Make sure you had inserted the SIM card in device and your cell-phone 2. Put battery on and press power key to turn on the power 3.

  • Page 8: Prepare The Parts

    1. Prepare the Parts Speaker Camera Motion Sensor Key Pad ● Speaker : Melody and alarm ● LCD(Liquid Crystal Display) : Display the screen ● M i ● Motion Sensor : Sense the motion or intruder ● USB : Charge the battery , PC interface ●...

  • Page 9: Functions Of Keypads

    1 1 F 1.1 Functions of keypads KEY PAD ; Save the selected menu function(Menu & Save Key) ; Scroll up to select menus numbers or letters(Up Key) ; Scroll up to select menus, numbers or letters(Up Key) ; Cancel the selected menus, numbers, or letters(Cancel Key) ;...

  • Page 10: Lcd Icons

    1.2 LCD Icon Functions of the icons at the top of the stand-by mode ; Received signal strength in the network coverage area. ; Guard function is on. ; Guard function is off. ; Picture resolution is set at high ;...

  • Page 11: Insert Sim Card

    2. Insert SIM Card  SIM Card  SIM Card 1. Make sure you had inserted the SIM card in your device properly unless screen displays “Insert SIM Guard Off”. 2. Verify that there is no SIM card enabled (The device must not ask for a “Insert SIM”...

  • Page 12: Insert Battery

    3. Insert Battery  Input & Removal of the Battery • This is the way to input and take out your battery from your device. Input Removal 2. Stick up your battery Remove the battery as first and put it down it below Remove the battery 1.

  • Page 13: It Hi 4. Switching The Device

    4. Switching the Device On Press and hold the power on/off Key to switch your device on/off. Power ON mode Stand by mode Stand-by-mode 1.Make sure you have to check the signal strength bar until it displays in your device LCD 2 Press 2.

  • Page 14: User Registration

    5. User Registration i t ti  Mobile Number On main menu press Key and select Client Setting. By using Key, move the cursor to one Mobile Number. User Registration page By using Key, Select the person’s phone number. press Key to save or press Key to erase.

  • Page 15: Mobile Number

    5 1 U 5.1 User Registration i t ti  User Registration(Option) On main menu press Key and select Client Setting. By using Key, move the cursor to one Mobile Number. Press option Key, to Select the Option. press Key to change the Owner Property. Mobile Option page •...

  • Page 16: E-Mail Address

    5 2 E M il Add 5.2 E-Mail Address  E-Mail Address • This function allows you to register three E-Mail address to get • This function allows you to register three E-Mail address to get transformed SMS MSG and photo to your E-Mail when the invasion is sensed.

  • Page 17: Permit Exception

    5 3 P 5.3 Permit Exception it E  Permit Exception This will allow you to manage the the Eyelog You can select Permission or Change PIN On main menu press Key select Pin Code. Permit exception page and select change code Using l t h d U i Key,...
  • Page 18 5 4 All Cl 5.4 All Clear  All Clear • It will allow you to reset the User Registration On main menu press Key select User Registration. and select All Clear menu HTTP selected page - 17 -...
  • Page 19 6 Settings 6. Settings  Time/Date • This will allow you to set the current time and date. • TIME/DATE : You can set the current time.  On TIMER mode, using Keys, move the cursor to 1 menu bar and press Key.
  • Page 20  Shooting mode • It will allow you to choose video or Camera to send to your cell-phone • Camera activate Is taking by photo • Video activate Is played by Video • Edit Is option to change the Size, Sound and Shooting mode Select Shooting mode M lti Shot (Video can change the recording time)
  • Page 21  Multi Shot • This menu is functions as multi shot capture and transfer This menu is functions as multi shot capture and transfer • Capture and transfer consecutive 3 sheets of shot or 5 sheets of shot • Go to the resolution you want by using Keys and press Key to register it.

  • Page 22: Network Setting

    6.3 Network Setting Setup for Network • This function setup will be allowed to your device connected to your mobile phone • In the main display press Key menu select Network option • NETWORK SETUP : setup the NETWORK. Press Key to exit the menu.
  • Page 23  DATA ACCOUNT : It will allow you to choose GSM DATA or GPRS ACCOUNT  DATA ACCOUNT : It will allow you to choose GSM DATA or GPRS ACCOUNT. Press Key to exit the menu. Data Account page Move the cursor to 1 or 2 menu bar by using Key and press Key or...
  • Page 24 ACCOUNT NAME : It will allow you to name the account. NUMBER : It will allow you to register the operator number DNS: It will allow you to register the IP address of DNS SERVER .  Select numbers by using Key and register it.
  • Page 25 LINE TYPE : It will allow you to set the line type.  Select ISDN or ANALOGUE TYPE by using Key to set the LINE TYPE. SPEED : It will allow you to set the transferring speed SPEED : It will allow you to set the transferring speed. ...
  • Page 26 You can move the cursor to “APN” or the other menu bar by using the other menu bar by using ‘Function Key(bottom of the left key)’ GPRS DATA ACCOUNT EDIT page 1 EDIT page 1 ACCOUNT NAME : It will allow you to name the account. APN : It will allow you to register the APN USER NAME : It will allow you to register the user name .
  • Page 27 AUTH. TYPE : It will allow you to set the AUTH. TYPE  Select NORMAL or SECURE TYPE by using Key to set the AUTH. TYPE. When all the information are input, press Key which will be followed by confirmation page Press Key to store them, or Key to cancel them.
  • Page 28 1 . RENAME PROFILE : It will allow you to name the profile. 2. HOMEPAGE : It will allow you to set up the address of the homepage. EDIT PROFILE page 2 EDIT PROFILE page 2 <To Registration> Press Key to enter the registration page select numbers by using Key and ...
  • Page 29 4. CONNECTION TYPE : It will allow you to select the network connection type. Press Key or Key to enter the registration page.  Press Key to enter the WAP or HTTP selected page and select numbers by using Key and press Key to register the IP or Proxy Address.

  • Page 30: The Way To Install

    9. The Way to Install •You may choose either standing position as below.  Make device “Guard on” 1. Make sure you had inserted the SIM card in device and your cell-phone Make sure you had inserted the SIM card in device and your cell phone 2.

  • Page 31: Usb Cable Connect

    10. USB Cable Connect Connect Eyelog with TA adapter to Connect Eyelog with TA adapter to Connect USB to user computer Connect USB to user computer concentric plug concentric plug Connect USB to user computer • It will allow you to see saved video.(MMS) or pictures in your computer. •...

  • Page 32: The Range & Angle Of The Sensor

    11. The Range & Angle Of The Sensor In Daytime In Night Sensor Camera Sensor Camera angle angle angle angle 95° 60° 95° 60° When the light is less than 20 Lux. Infrared sensor will be automatically turn on. In Daytime In daytime the range of clear visible sight distance is more than 4m.

  • Page 33: Chapter 2. The Rest Functions

    Chapter 2. The Rest Functions 2 Th R t F 1. Album. 1. Photo • It will allow you to see saved pictures in Eyelog . Album page Album page Press menu key select Photo Album and you can see the view Press Key to select the pictures you want to see In Image Viewer...

  • Page 34: Video

    2. Video • It will allow you to see saved video.(MMS) Press menu key select Photo Album and you Video Player page Video Album page can see the view can see the view Press Key to select the video you want to see In Video Player Press Key to select option...

  • Page 35: 2. Version Info

    2. Version Info. 1. Version Information • It will allow you to see saved pictures in Eyelog . Version Info. page Press menu key select Version Info. and you can see the Version of Eyelog • You could see the Version , Branch, Build Time , Build, Serial Number Version Info.

  • Page 36: Chapter 3. Remote Control Operation

    Chapter 3. Remote Control Operation Using your remote control by cell-phone • You may use the selected person’s cell phone as a remote control by sending SMS message. • It’s same as when you usually send SMS message. •Sending “#help “#help”...

  • Page 37: How To Use Remote Control By Cell-Phone

    •Sending “# # vid vid” to the device from the remote control by SMS message will function as “VIDEO”. Then the device will send the message “Accept command to send video” to the remote control. This option is to take a video of the moment where the device are settled •Sending “#son “# # #son”...

  • Page 38: For The Error Reason Code

    For the error reason code For the error reason code Error Index Details Expression in SMS When can not guarantee surplus battery for confirm MSG Low battery LOW BATTERY by low battery until receiving Confirm MSG in 10 min after receiving request MSG When Confirm MSG does not return in 10 min after sent Certification timed out CERTI TIME OUT...
  • Page 39 Warning Read this information before use Near-Body Operation To maintain compliance with FCC RF exposure requirements, maintain a 20Cm, separation distance between the user's body, including the antenna, whether extended or retracted. Caution Modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
