Summary of Contents for HTD HD-IWS10
- Page 1 D i g i t a l A m p l i f i e r O w n e r ’s M a n u a l Home Theater Direct, Inc. www.htd.com Expert Support: 866-HTD-AUDIO (483-2834) info@htd.com V.03.22.2016 © Copyright Home Theater Direct, Inc.
- Page 2 Product Servicing the appliance. If your system fails to operate properly, please contact HTD Grounding or Polarization directly for further assistance, at 1-866-483-2834. Precautions should be taken so that the grounding or polariza- Additional information, including detailed specifications for each tion means of an appliance is not defeated.
-
Page 3: Subwoofer Placement
UL Class 3 approved cable (marked “CL3”) for compliance with local building codes. Consider using HTD cable for all of your home theater and whole-house audio installations. HTD cable offers exceptional performance, and of course, is priced significantly lower than retail. -
Page 4: Product Features
Product Features SDA-120 Features Level Knob Phase Switch Power Button Subwoofer Digital Amplifier SDA-120 80Hz 40Hz 120Hz CROSSOVER LEVEL Power Indicator Light Amplifier Protection Light Crossover Control Knob 5-way Binding Posts LEFT RIGHT SPEAKER POWER AUTO LFE IN LFE IN AC 120V~60Hz XO-ACTIVE XO-BYPASSED... - Page 5 “eye”. Rotate binding post clock-wise to tighten. Be sure to maintain polarity (Subwoofer + to Amplifier + , Subwoofer - to Amplifier -) HD-IWS10 Features 10” Reinforced Long-throw Alumi- Gold-plated Compression Terminals Sturdy Wooden Mounting Braces (included). num Driver Braces attach to existing studs.
- Page 6 Quick Steps: Install HTD In-Wall Powered Subwoofer You will need the following tools: Drill (with phillips Pencil Optional: 1/2” foam tape head bit and Drywall Saw 1/8” drill bit) Step 1 After checking for stud locations and confirming there are no obstructions hidden behind the wall, position the cardboard template and trace along the inside edge.
- Page 7 Step 4 Removing the grille from the in-wall powered sub- woofer is easy if you know a couple of tricks..Here they are: Brand new (un-installed) subwoofer: * Awl Method - Using an awl, insert the hook end of the awl into a hole of the grille (along the edge, not in the center).
- Page 8 Step 6 Using a 1/8” drill bit, drill pilot holes into the wood brackets at the four previously marked locations. This prevents the wood from splitting when the screws are driven in. Step 7 If you have not already done so, run the 2-con- ductor speaker cable from the location of the SDA-120 Amplifier, to this wall-space where the Subwoofer will go.
- Page 9 Step 9 Pick up the Subwoofer and hold it near the hole in the wall. Connect the speaker wires to the Subwoofer by pressing down on the gold-plated spring-loaded cable connectors on the back, top of the Subwoofer, and inserting one of the stripped ends into each one.
- Page 10 The connection of the inwall subwoofer in this example is performed as such: the SDA-120 ampli- fier is connected to a receiver’s LFE or Subwoofer Out connector using a shielded subwoofer cable (available from HTD), and the SDA-120 and In-Wall Subwoofer are connected using standard 2-conductor 14-gauge speaker cable.
- Page 11 XO-ACTIVE XO-BYPASSED This image above shows specifically how to connect the SDA-120 Amplifier to an HTD Whole-House Con- troller in order to use the In-wall Subwoofer in one Zone. The left side of this diagram shows use of RCA Y adapters to “split” the line-level signal coming from...
-
Page 12: Specifications
Auto-on capability with dual color LED indicator (amber:stand-by; blue:on) Warranty All HTD electronics carry a two-year parts and labor warranty. Details can be found at www.htd.com/info/warranty. Warranty registration occurred automatically at the time your order was placed. There is no need to complete or mail in additional paperwork.
