  • Page 1 High Resolution 32X Zoom Color Camera User Manual HCZ-6320...

  • Page 2: User Manual

    High Resolution 32X Zoom Color Camera User Manual Copyright ©2017 Co., Ltd. All rights reserved. Hanwha Techwin Trademark Each of trademarks herein is registered. The name of this product and other trademarks mentioned in this manual are the registered trademark of their respective company. Restriction Copyright of this document is reserved.
  • Page 3 Before operating the camera, confirm the camera model and correct input power voltage. To help you understand this manual thoroughly, we’ll introduce our model description. ■ HCZ-6320 SERIES • NTSC MODEL • PAL MODEL HCZ-6320N HCZ-6320P ■ MODEL DESCRIPTION • HCZ-6320X _ SIGNAL SYSTEM • SIGNAL SYSTEM...
  • Page 4 safety information CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates that dangerous voltage consisting a risk of electric shock is present within this unit.
  • Page 5 9. If this product fails to operate normally, contact the nearest service center. never disassemble or modify this product in any way. (Hanwha Techwin is not liable for problems caused by unauthorized modifications or attempted repair.) 10.

  • Page 6: Fcc Statement

    safety information FCC STATemeNT This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : 1) This device may not cause harmful interference, and 2) This device must accept any interference received including interference that may cause undesired operation.

  • Page 7: Important Safety Instructions

    important safety instructions 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean the contaminated area on the product surface with a soft, dry cloth or a damp cloth.
  • Page 8 20. Installing or using the product in water can cause serious damage to the product. Hanwha Techwin cares for the environment at all product manufacturing stages to preserve the environment, and is taking a number of steps to provide customers with more environment-friendly products.The Eco mark represents Hanwha Techwin’s will to create...

  • Page 9: Table Of Contents

    contents INTROdUCTION Features What’s included Component names and functions CONNeCTION Connecting to Monitor Connecting to Power Control via RS-485 Interface Using Coaxial Communications Connecting to 8P Control Terminal CAmeRA OpeRATION Menu Configuration Menu Setup TROUbleShOOTING Troubleshooting SpeCIFICATIONS Specifications Dimensions SAmSUNG-T pROTOCOl SAMSUNG-T Protocol Command Description COmmANd deSCRIpTION...
  • Page 10 introduction FeATUReS y 32x Optical Zoom The built-in HCZ-6320(32x) optical zoom lens is a highly durable component. It features auto focus, auto iris, and zoom functions. y high Resolution Use of a 2.38 mega pixel CMOS device provides clear pictures with a horizontal resolution of 1000TV lines.

  • Page 11: What's Included

    WhAT’S INClUded High Resolution 32X Zoom Color Camera User Manual HCZ-6320 Main Body Quick Manual 8-PIN CABLE ASSY Cable for the testing Camera Holder (Mount) Camera Holder (Mount) monitor Screw English_11...

  • Page 12: Component Names And

    introduction COmpONeNT NAmeS ANd FUNCTIONS fronT siDE Camera Holder (Mount) Holes Used when you mount the camera onto the bracket by fixing the camera holder (mount) adaptor with the bracket. Zoom lens Built-in zoom lens. Attach the holder to the top of the camera. Use screws included in the package or their equivalent.

  • Page 13: Functions

    ReaR side CVBS POWER DC 12V Ahd Jack Sends video signal and connects to the Video IN port of a AHD DVR. CVbS Jack Analog video output port. (for installation) Function setup switch Press the Function Setup switch to display the menu screen. After the menu is displayed on the screen, move the cursor <up/down/left/right>...

  • Page 14: Connecting To Power

    connection ConnECTing To MoniTor Refer to the following figure to connect monitors through DVR. ALARM NETWORK BACKUP POWER AHD DVR CVBS POWER DC 12V HCZ-6320 Monitor y As the connecting method varies with the instruments, refer to the manual supplied with the instrument. y Only connect the cable when the power is turned off.

  • Page 15: Control Via Rs-485 Interface

    When the resistance value of copper wire is at [20°C(68°F)] Copper wire size (AWG) #24 (0.22mm #22 (0.33mm #20 (0.52mm #18 (0.83mm Resistance value(Ω/m) 0.078 0.050 0.030 0.018 Voltage Drop (V/m) 0.028 0.018 0.011 0.006 y As shown in the table above, voltage decreases as the wire gets longer. Therefore use of an excessively long adaptor output line for connection to the cam- era may affect the performance of the camera.

  • Page 16: Connection

    connection Using Coaxial CoMMUniCaTions • Coaxial Communications System • OSD Control method CAMERA CONTROLLER MENU/ENTER OSD KEY UP KEY JOYSTICK UP DOWN DOWN KEY JOYSTICK DOWN LEFT LEFT KEY JOYSTICK LEFT RIGHT RIGHT KEY JOYSTICK RIGHT <DVR> ALARM NETWORK BACKUP POWER : BNC •...

  • Page 17: Connecting To 8P Control Terminal

    ConnECTing To 8P ConTrol TErMinal The camera can be controlled by using external controllers like a Remote controller. (RS-485 Communication) CVBS POWER DC 12V SPC-6000 8-Pin CABLE ASSY SPC-200 * 8P Control Terminal Configuration Name Cable color Description Name Cable color Description ZOOM ORANGE...
  • Page 18 connection Connector Function Signal Level +6V ~ +12V Tele ZOOM Wide -6V ~ -12V +6V ~ +12V FOCUS Near -6V ~ -12V 3±0.5sec USER Vcc ← → There is no motion There is motion DAY mode : D&N terminals must be OPEN to external signals. EX DN (Do not input voltage) NIGHT mode : D&N terminal must be connected to the ground...

  • Page 19: Camera Operation

    camera operation meNU CONFIGURATION mAIN SeTUp meNU SSdR ● ON ● OFF ● ATW ● MANUAL ● AWC→SET WhITe bAl ● OUTDOOR ● INDOOR ● MERCURY ● SODIUM ● BLC ● HLC ● OFF bACKlIGhT ● WDR INTellIGeNCe ● OFF ●...

  • Page 20: Menu Setup

    camera operation meNU SeTUp Use Function Setup switch on back of the camera. CVBS Function Setup switch POWER DC 12V 1. Press Function Setup switch for 3 seconds. • Main setup menu is displayed on the monitor screen. MAIN SETUP Select the ...
  • Page 21 SSdR (SUpeR dYNAmIC RANGe) SSDR illuminates darker spots of an image while retaining the same light level for brighter spots to even out the overall brightness of images with high contrast between bright and dark spots MAIN SETUP SSDR  WHITE BAL 1.
  • Page 22 camera operation ❖ Select one of the following 7 modes, as appropriate for your purpose. y ATW : Select this when the color temperature is between 1,800˚K and 10,500˚K. y MANUAL : Select this to fine-tune White Balance manually. Set White Balance first by using the ATW or AWC mode.
  • Page 23 BaCklighT Unlike conventional cameras, the HCZ-6320 is designed to deliver a distinctive subject and background at the same time, even when the subject is backlight, by using the features of the proprietary WN2 chip. 1. When the SETUP menu screen is MAIN SETUP displayed, select ‘Backlight’...
  • Page 24 camera operation y WDR When there are both bright and dark areas at the same time, this mode makes both areas distinctive. - LEVEL : Select one from low, middle, WDR SETUP MODE high to adjust the brightness of the WDR setup.
  • Page 25 inTElligEnCE Commands the camera to motion-detect and trace an object 1. When the SETUP menu screen is displayed, select ‘INTELLIGENCE’ by using the Functiion Setup Switch so that the arrow indicates ‘INTELLIGENCE’ . 2. Select a desired mode using the Function Setup switch. y DETECTION : Since the camera detects INTELLIGENCE motion without any additional external...
  • Page 26 camera operation - DIRECTION • IN : Detects objects entering the fenced area. • OUT : Detects objects exiting the fenced area • IN/OUT : Detects all objects entering and exiting the fenced area. TRACKING TRACKING SEL POS POS1  SEL POS POS1 ...
  • Page 27 - DWELL TIME : Use the left or right button in the ‘DWELL TIME’ item to select a time between 5 and 60 seconds for the dwell time before the zoom is returned to the ‘START ZOOM’ position. (5,7,10,15,20,30,40,60 sec) y SETUP CONFIG - DETECT AREA : Defines the Motion SETUP CONFIG...
  • Page 28 camera operation Tips on Using the Motion Detection Feature • The feature may not function properly under flickering light conditions. • The camera interprets sudden changes in lighting and subsequent change in brightness of an object as motion. • With the feature enabled, other algorithms may require additional time to operate. •...
  • Page 29 - MANUAL : Select 'MANUAL' and press the ZOOM/FOCUS POS SETUP FUNCTION SETUP SWITCH to confirm. Increase or decrease optical zoom (ZOOM) or digital zoom (D-ZOOM) positions moving directional buttons while ← : NEAR → : FAR verifying the changes on screen. Press the ↑...
  • Page 30 camera operation y ZOOM POS INIT : FOCUS SETUP Moves to the controlled ZOOM position MODE ONE-PUSH when the power is truned on and the initial ZOOM TRACK AUTO TRACK ZOOM position has been set. ZOOM SPEED FAST D-ZOOM - AUTO : If you turn the power off and on, ZOOM POS INIT AUTO ...
  • Page 31 ExPosUrE From the Main Setup menu, select EXPOSURE and press Function Setup Switch. You can now change the exposure setting. 1. Press the Functiion Setup Switch to MAIN SETUP access the main setup menu and then SSDR position the indicator over EXPOSURE. WHITE BAL 2.
  • Page 32 camera operation Press the FUNCTION SETUP SWITCH to complete. ❷ Image may become unstable if the camera is set to 'ESC' mode and faces a strong fluorescent light. In case the shutter is set to Low Speed in a bright environment, saturation may occur.
  • Page 33 sPECial 1. Press the Function Setup Switch to MAIN SETUP access the main setup menu and then SSDR position the indicator over 'SPECIAL'. WHITE BAL BACKLIGHT 2. Press the Function Setup Switch to con- INTELLIGENCE firm. FOCUS y PRIVACY : Hide the area that you want not EXPOSURE ▶...
  • Page 34 camera operation - AUTO : The mode is switched DAY/NIGHT AUTO SETUP to 'Color' in a normal environment, but switches to ▶ DWELL TIME 5 SEC 'B/W' mode when ambient DURATION SLOW illumination is low. To set up RETURN the switching time or speed for AUTO mode, press the Function Setup Switch.
  • Page 35 y DIS : The DIS mode can compensate for SPECIAL SETUP vibration of the camera. PRIVACY When DIS is operating, D-ZOOM does not DAY/NIGHT AUTO operate. ▶ DIS DEFOG y DEFOG: You can use the defog mode to allow the camera to automatically detect the fog density of the screen and display a clear image despite smog, fog or general poor visibility.
  • Page 36 camera operation - COAX : You can select whether to use COAX communication. Coaxial communication is not available in CVBS mode. y IMAGE ADJ : Includes image quality or special function factors. When the SETUP menu screen is SPECIAL SETUP displayed, select ‘IMAGE ADJ.’...
  • Page 37 y DISPLAY: Use this feature to designate a name for the camera, which will display on the monitor screen. - CAM TITLE Press the Function Setup Switch DISPLAY SETUP to display the main setup menu and ▶ CAM TITLE move the arrow indicator to ‘CAM CAM ID TITLE’...
  • Page 38 camera operation - LANGUAGE : You can select the menu language according to your requirements. - RETURN : Select this to save the SPECIAL menu settings and return to the SPECIAL menu. rEsET Resets the camera settings to the factory defaults. Communication, Language and Monitor settings are not initialized.

  • Page 39: Troubleshooting

    troubleshooting TroUBlEshooTing If you have trouble operating your camera, refer to the following table. If the guidelines do not enable you to solve the problem, contact an authorized technician. SOLUTION PROBLEM ▶ M E nsure that your camera is supplied with rated N othing appears on the power as appropriate.

  • Page 40: Specifications

    specifications sPECifiCaTions HCZ-6320 VIDEO Imaging Device 1/2.8" 2.38M CMOS Total Pixels 1952(H) x 1116(V), 2.18M Effective Pixels 1944(H) x 1104(V), 2.14M Scanning System Progressive Color : 0.2 Lux (1/30sec, F1.6, 30IRE), 0.003 Lux(2sec, F1.6, 30IRE) Min. Illumination B/W : 0.01 Lux (1/30sec, F1.6, 30IRE), 0.0001 Lux(2sec, F1.6, 30IRE) S / N Ratio 50dB Video Output...
  • Page 41 HCZ-6320 Electronic Shutter Speed Minimum / Maximum / Anti flicker (2 ~ 1/33,000sec) Digital Zoom Flip / Mirror Off / On Intelligent Video Analytics Detection / Tracking / Fixed Moved / Tampering Remote Control I/F RS-485, Coaxial Protocol RS-485: Samsung-T/E, Pelco-D/P, Panasonic, Bosch, AD, Vicon, Honeywell Coaxial : ACP (AHD Coax Protocol) Video Transmission Distance 500m(5C2V Coaxial Cable)

  • Page 42: Specifications Dimensions

    specifications DiMEnsions Unit : mm (Inches) 42_ specifications...
  • Page 43 MEMO English_43...

  • Page 44: Samsung-T Protocol Command Description

    SAMSUNG-T Protocol Command Descri p ti o n saMsUng-T ProToCol CoMManD DEsCriPTion Byte1 Byte2 Byte3 Command Packet CAM ID HOST ADDR Return Packet CAM ID HOST ADDR Command Name Checksum CHECKSUM CALCULATION : UNARY OPERATION OF SUMMATION F EX) CHECKSUM = ~(BYTE2+BYTE3+... +BYTE8+ BYTE9); Function Reset all data to factory default value.
  • Page 45 Byte4 ll Byte5 Byte 6 Byte7 Byte8 Byte9 Byte10 Byte11 CAMMAND DATA3 DATA4 DATA5 DATA6 CHECKSUM CAMMAND DATA3 DATA4 DATA5 DATA6 CHECKSUM FROM BYTE2 TO BYTE9. 000Fh CHECK SUM 000Fh CHECK SUM 0100h CHECK SUM 0100h CHECK SUM 0200h CHECK SUM 0200h CHECK SUM 0040h...
  • Page 46 SAMSUNG-T Protocol Command Descri p ti o n Function Save current user preset configuration information. Command Packet CAM ID HOST ADDR User Preset Save Return Packet CAM ID HOST ADDR Parameter P1:00h(USER PRESET 1) ~ 80h(USER PRESET 128) Function Execute selected user preset. Command Packet CAM ID HOST ADDR...
  • Page 47 0003h CHECK SUM 0003h CHECK SUM 0007h CHECK SUM 0007h CHECK SUM 0005h CHECK SUM 0005h CHECK SUM 00B1h CHECK SUM 00B1h CHECK SUM 0008h CHECK SUM 0008h CHECK SUM 0010h CHECK SUM 0010h CHECK SUM 0004h CHECK SUM 0004h CHECK SUM 0002h CHECK SUM...
  • Page 48 Head Office 6, Pangyo-ro 319 beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, 463-400 Rep. of KOREA Tel : +82.70.7147.8753 Fax : +82.31.8018.3740 www.hanwha-security.com Hanwha Techwin America 500 Frank W. Burr Blvd. Suite 43 Teaneck, NJ 07666 Toll Free +1.877.213.1222 Direct +1.201.325.6920 Fax +1.201.373.0124 www.hanwha-security.com...
