Comtel GEOAMP XT Manual

MAGNEWAVE GEOAMP XT MANUAL
Manufactured by Comtel Systems Ltd., Edmonton, AB. 780-455-1945 www.bestpigtracker.com
The Magnewave Geoamp XT is a small but highly
effective acoustic amplifier that is purposely
designed to give optimal reception of oncoming
pigs in pipelines through the noises produced
by their passage.
PICTURE OF SHIRT POCKET SIZED GEOAMP
The Geoamp is built around a specially designed electronics circuit that features
very high signal sensitivity to the frequencies that are most required to detect
acoustic signals from geoprobes in position to detect travelling pigs in pipelines.
It is important that it also reject interfering signals and noises from a number of
objectionable sources, such as power lines, telephone lines, two way radio traffic,
wind noise, traffic noise and industrial plant noise. Our Geoamp is very good at
doing that, although it should be noted that no geoamp can exclude all noise if it
happens to fall right in the special frequencies needed to detect pigs in pipelines.
The picture to the right shows the front of the Geoamp.
Turning the knob to the right powers on the Geoamp
and further rotation will increase the strength of the
signal received from a geoprobe connected to the con-
nector on the left, marked GEO IN. An earphone can
be plugged into the middle connector marked EAR OUT.
1
