FORESIGHT TTP111V Manual

TWISTED PAIR TRANSMISSION SYSTEM – Passive Series
ITEM NO.: TTP111V, TTP111VT, TTP111VF, TTP111VP, TTP111VPJ, TTP111VCT, TTP111VL,
TTP111VLH, TTP111AV, TTP414V, TTP414VH, TTP414VD, TTP444V, TDP414V,
TDP414VP
Features:
Transmit a full motion monochrome video signal up to 600 meters, color video signal up to
400 meters.
Distance Up to 1Km when used with an active receiver such as TTA111VH, TTA111VR,
TTA111AVR, TTA414VR, TPA008, TPA016.
Passive, No power required.
Built in a highly balanced mode of video transmission on TTP111VLH, TTP414VH, perfect
to put them at receiver side for extra interference immunity.
Eliminate Coaxial Cable.
Up to multi TTP111XX, can work with 1U rack mounting multi channel receiver panel
TPP016, TPA008, and TPA016.
FCC
Installation View:
FORESIGHT CCTV INC. | 5863 Leslie Street, Unit#713, North York, Ontario,Canada, M2H 1J8 | http://www.foresight-cctv.com | 1-888-GO2-CCTV
TTP111VLH: Exceptional Interference Rejection ( Perfect for DVR )
C-TICK
1
