OPERATING INSTRUCTIONS
(gray model# CEI-4710)
Please read this manual!
This manual contains setup information necessary to
achieve proper performance from your Pocket Pro II.
815.874.8001
(blue model# CEI-4700)
competitionelectronics.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pocket Pro II and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Competition Electronics Pocket Pro II

  • Page 1 OPERATING INSTRUCTIONS (blue model# CEI-4700) (gray model# CEI-4710) Please read this manual! This manual contains setup information necessary to achieve proper performance from your Pocket Pro II. 815.874.8001 • competitionelectronics.com...
  • Page 2: Table Of Contents

    User Manual / Operating Instructions Table of Contents Battery Installation . . . . . . . . . . . . . . . . . . 2 Setting the Main Display Type .
  • Page 3: Battery Installation

    . This will prevent battery discharge in the event it is not turned off after use . To wake up the timer, press the SET/ON button . Forced Shutdown To turn the Pocket Pro II off, press and hold the MENU DOWN button for approximately 3 seconds .
  • Page 4: Quick Start

    If you want to get started right away, all you have to do is press the start button on the side and shoot . The Pocket Pro II comes from the factory configured and ready to run . After the timer shuts down, press the SET/ON button to turn it on .
  • Page 5: Shot Detection

    User Manual / Operating Instructions Shot Detection Each time a shot is detected, it will be added to the “shot string” maintained within the timer . The timer will automatically calculate the “split time . ” Split time is the time between the current shot and the previous shot .
  • Page 6: Setting The Par Time (Second Beep)

    User Manual / Operating Instructions Setting the PAR Time (second beep) The par time setting (also known as the “second beep”) comes configured from the factory for 0 seconds . When the par time is set to 0, the timer will beep only once, at the start of a timing cycle .
  • Page 7: Display Backlighting

    User Manual / Operating Instructions Fixed Delay On the same screen as mentioned in the previous section, select “RANDOM . ” Now, using the MENU UP/DOWN button, advance to the “RANDOM START TIME – MINIMUM” and “RANDOM START TIME – MAXIMUM” display screens . In both screens, select the same delay time, between .5 seconds and 9 .9 seconds .
  • Page 8: Beeper Volume

    . A new setting will be saved automatically . Setting the Main Display Type The Pocket Pro II can be configured to show three different types of main displays . These are selected from the “MAIN SCREEN TYPE” menu, and are described below .
  • Page 9 START is pressed again . The normal shot dead time setting is overridden when in RPM mode and set to a fixed value of 0 .032 seconds . This allows the Pocket Pro II to detect shots at rates of up to 1800 RPM .
  • Page 10: Shot Dead Time

    The SHOT DEAD TIME feature is used to reduce false shot recordings due to echoes or ringing . Once a shot is detected, the Pocket Pro II will disregard subsequent shots for a short period of time . The default setting is .11 seconds, but can be adjusted from .05 to .12 seconds .
  • Page 11: Setting The Date And Time

    User Manual / Operating Instructions Setting the Date and Time Using the MENU UP/DOWN buttons, cycle through the MONTH, DAY, YEAR, HOURS, and MINUTES display screens using the SET UP/DOWN buttons to set the date and time . To synchronize to the nearest second, set the “MINUTES” value and at the mark, advance to the next/previous display screen .
  • Page 12: Battery Status

    . This will allow the session to continue in the event a replacement battery is not readily available . When the battery voltage becomes depleted to less than 6 volts, the Pocket Pro II will shut down to avoid undefined operation . Resetting the Timer to Factory Defaults To reset factory default values within your timer, remove the battery, then hold down the “Start”...
  • Page 13: Timer "Wraparound

    . Accuracy The Pocket Pro II measures internally to a resolution of 1 mSec, but shot displays, splits, etc . are internally rounded to the nearest 10 mSec . For this reason, RPM readings may appear to be inaccurate when manually calculated using the displayed shot string values .
  • Page 14: Specifications

    • Battery type: 9 volt alkaline Pocket Pro II Carrying Case (model# CEI-4707) $10.95 • This handy case will protect your timer during transport and storage. • It features a zipper storage compartment for spare batteries, velcro belt strap, and a Competition Electronics embroidered logo . • Economically priced at $10.95 which includes postage to continental U .S .A . residents . To Order Call 815-874-8001 or visit our website at competitionelectronics.com...
  • Page 15: Limited Warranty

    * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * * COMPETITION ELECTRONICS, INC., warrants the Pocket Pro II manufactured by it to be free from defects in material and work- manship for a period of 2 years from date of purchase by the original purchaser for use.
  • Page 16 User Manual / Operating Instructions www.competitionelectronics.com Rev 5-2013...
