aoyue Ritocco Instruction Manual

Touch up tool for 3d prints
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
A fire may result if the appliance is not used with care, therefore:
be careful when using the appliance in places where
◆
there are combustible materials ;
do not apply to the same place for a long time;
◆
do not use in presence of an explosive atmosphere;
◆
be aware that heat may be conducted to combustible
◆
materials that are out of sight;
place the appliance on its stand after use and allow it to
◆
cool down before storage;
do not leave the appliance unattended when it is
◆
switched on.
Correct Disposal of this product
This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible harm
to the environment or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the return and
collection systems or contact the retailer where the product was
purchased. They can take this product for environmental safe
recycling.
AOYUE INTERNATIONAL LIMITED
Jishui Industrial Zone, Nantou, Zhongshan City,
Guangdong Province, P.R.China
http://www.aoyue3d.com
28
This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
A fire may result if the appliance is not used with care, therefore:
be careful when using the appliance in places where
◆
there are combustible materials ;
do not apply to the same place for a long time;
◆
do not use in presence of an explosive atmosphere;
◆
be aware that heat may be conducted to combustible
◆
materials that are out of sight;
place the appliance on its stand after use and allow it to
◆
cool down before storage;
do not leave the appliance unattended when it is
◆
switched on.
Correct Disposal of this product
This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible harm
to the environment or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable reuse of material
resources. To return your used device, please use the return and
collection systems or contact the retailer where the product was
purchased. They can take this product for environmental safe
recycling.
AOYUE INTERNATIONAL LIMITED
Jishui Industrial Zone, Nantou, Zhongshan City,
Guangdong Province, P.R.China
http://www.aoyue3d.com
28
AOYUE3D
Ritocco
Touch up tool for 3d prints
Instruction Manual
Thank you for purchasing Ritocco touch up tool
for 3d prints. Please read the manual before
using the unit.
Keep manual in accessible place for future
reference.
This manual is designed to familiarize and instruct
the technician with the proper operation and
maintenance of the equipment. Please read
carefully and observe the guidelines in order to
maximize usage and minimize the risk of injury or
accidents .
AOYUE3D
Ritocco
Touch up tool for 3d prints
Instruction Manual
Thank you for purchasing Ritocco touch up tool
for 3d prints. Please read the manual before
using the unit.
Keep manual in accessible place for future
reference.
This manual is designed to familiarize and instruct
the technician with the proper operation and
maintenance of the equipment. Please read
carefully and observe the guidelines in order to
maximize usage and minimize the risk of injury or
accidents .
®
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ritocco and is the answer not in the manual?

Questions and answers

Summary of Contents for aoyue Ritocco

  • Page 1 Instruction Manual ◆ switched on. Thank you for purchasing Ritocco touch up tool Correct Disposal of this product for 3d prints. Please read the manual before This marking indicates that this product should not be disposed with using the unit.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Product Description ........3 Package Inclusion ........3 Safety Precautions ........4 Specification ..........5 Functions and Features ....... 5 Holder Assembly Instruction ......6-8 Display Controls .......... 9 Quick Tip Change ........10 Operating Guidelines Easy mode ........11-14 Advanced mode ......

  • Page 3: Product Description

    OPERATING GUIDELINES PRODUCT DESCRIPTION From Mode Lock Selection The Aoyue 3D Ritocco is the world’s most advanced sculpting and retouching tool for 3D prints. Its Mode lock selection revolutionary compound heater and tip design allows (UP and DOWN button simultaneously pushed) fast heat up and heat response to tackle any retouching Set PLA temperature (up &...

  • Page 4: Safety Precautions

    SAFETY PRECAUTIONS OPERATING GUIDELINES CAUTION: Improper usage can cause serious injury to personnel ADVANCED OPTIONS II and/or damage to equipment and work area. For your own safety Within the advanced options selection we can also set please observe the following precautions. the PLA Mode temperature , ABS Mode temperature, and the Single set temperature mode temperature.

  • Page 5: Specification

    OPERATING GUIDELINES SPECIFICATION MAIN STATION From off to Mode Lock Selection Voltage Input : 12V DC Weight: 50 grams Press and hold UP & DOWN Temperature: up to 150-400°C (302 to752°F ) button while plugging in the tool Heating Element: Composite Ceramic heater Pass code entry mode (UP button pushed until it reaches code 110)

  • Page 6: Holder Assembly Instruction

    “110” Press and hold both up and down button while plugging in the Ritocco the display would show “001” indicating the user to enter the pass code. Press the up button to select pass code 110. Press both up and down button to enter the pass code.

  • Page 7: Holder Assembly Instruction

    OPERATING GUIDELINES HOLDER ASSEMBLY INSTRUCTION ADVANCED OPTIONS I The system can allow parents or teachers to lock out other modes so the tool can only be used in a specific mode or temperature. This is to restrict users from setting a temperature that is unsuitable for the materials being worked on.
  • Page 8 The system’s temperature scale can be switched between Centigrade or Fahrenheit. To switch the display scale press the up button while plugging in the Ritocco the display would show the Celsius sign, press the up or down button to switch between Celsius or Fahrenheit scale. Wait for 3—5 seconds, the display will save the new settings and revert to standby mode.
  • Page 9 OPERATING GUIDELINES DISPLAY AND CONTROL From off to Sleep timer adjustment Press and hold DOWN button 1 — Down Button while plugging in 2 — LCD Display Sleep timer 30 minutes heater “OFF” 3 — Up Button (UP button pushed) Sleep timer 31 heater “OFF”...
  • Page 10 Insert tip Adjusting the Sleep: Press the down button while plugging in the Ritocco the display would show a number“030” indicating this is the current set sleep timer. (default 30 minutes) Press the up or down button to adjust sleep timer settings.

  • Page 11: Easy Mode

    Standby mode heater “OFF” appropriate temperature settings has already been pre- programmed into the Ritocco, simply select what type of plastic (UP and DOWN button pushed for more than 10 seconds (ABS, or PLA ) you would like to work with.

  • Page 12: Advanced Mode

    OPERATING GUIDELINES OPERATING GUIDELINES Stand by mode -> Scroll through modes DIGITAL OFFSET MODE The unit is provided with a digital offset feature for tip Standby mode heater off calibration. (UP button pushed) To calibrate the tip temperature: ABS Selection 1.

  • Page 13: Advanced Mode

    OPERATING GUIDELINES OPERATING GUIDELINES From standby mode to ABS From standby mode to Advanced Mode Standby mode heater “OFF” Standby mode heater “OFF” (UP button pushed) (UP button pushed) ABS Selection heater “OFF” ABS Selection heater “OFF” (wait for 3 to 6 seconds) (UP button pushed) ABS mode heater “ON”...

  • Page 14: Advanced Mode

    (UP button pushed) Selecting Advanced working mode: ABS Selection heater “OFF” Plug in the Ritocco the display would show “OFF” indicating it is in the stand by mode, the heating element (UP button pushed) would not be powered.
