Summary of Contents for Eschenbach mobilux Digital
- Page 1 Bedienungsanleitung User Manual Mode d'emploi Istruzioni d'uso Manual de instrucciones Gebruiksaanwijzing Betjeningsvejledning Bruksanvisning Käyttöopas Instrukcja obsługi Návod k obsluze...
- Page 2 - 3 -...
- Page 3 Dear customer, we congratulate you on the purchase of this electronic magnifying glass for hand-held or contact use - a quality product made by Eschenbach - and we hope you enjoy using the device on a daily basis. As the market leader for magnifying glasses and reading glasses, we at Eschenbach are able to look back on many years of experience which are mirrored in the quality, handling and design of our products.
-
Page 4: Safety Instructions
X Charge the reader only with the supplied mains adapter or a USB connection! X Check your mobilux DIGITAL Touch HD and the mains adapter and its power cable for visible damage. If the mobilux DIGITAL Touch HD, the mains adapter or its cable are damaged, disconnect the mains adapter from the mains power immediately. -
Page 5: Package Contents
Package contents X Electronic reader mobilux DIGITAL Touch HD (in the remaining text also referred to simply as "reader") X Charger (with plugs for EU, GB, US, AUS) X USB cable X SD card (supplied preinstalled) X Case X Cleaning cloth... -
Page 6: Operation
Switching on/off Press and hold the On/Off button (w) for a second to turn on mobilux DIGITAL Touch HD and to switch to live image mode. The enlarged image of the reading material will appear on the screen (q). - Page 7 On the upper edge of the screen, icons appear for 5 seconds to display the battery charge level, the last set zoom level and the screen brightness. Battery fully charged 75% charge 50% charge 25% remaining charge, the icon lights up red for 5 seconds on the upper edge of the screen Remaining run time approx.
- Page 8 Writing with the device Once in place, the reader can be tilted forward so that it also rests on the front edge of the display and thus – to a limited extent – you can write under the reader. In addition, due to its high depth-of- field the reader can also be held in the hand at a very short distance to the reading material.
- Page 9 2 seconds. Setting the screen mode The mobilux DIGITAL Touch HD is equipped with a range of display modes so that you can achieve the best possible image. Tap repeatedly on the icon to scroll through the various display modes from true-colour mode via high-contrast black/white and white/black displays to false-colour black/yellow and yellow/black displays.
- Page 10 Touch the icon for 2 seconds to switch on/off the LEDs (o) that illuminate the reading material on the underside of the device. Tap again briefly on the screen to hide the three icons. Opening the menu Press the screen gently for 3 seconds to call up the following menu: A - Time display B - "Close menu"...
- Page 11 Display image files If you tap this button briefly, the two most recently recorded image files are displayed as thumb- nails. Tap a thumbnail to view it full screen. Tap on the screen to hide the icons. Tap again on the screen to restore the icons.
- Page 12 Tap on the icon to go back 10 files in the preview. Tap on the icon to display the thumbnails of the previous two files. Tap on the icon to display the thumbnails of the following two files. Tap on the icon to move forward 10 files in the preview.
- Page 13 Call up device settings If you tap this button briefly, you can then adjust the device settings described below. Here, too, you can use the icon to return to the previous menu level. Use the to close the menu and return to the live image display.
- Page 14 Activate/deactivate save confirmation Here you can set whether a display image is saved as a file immediately or whether the reader will only save the file after a confirmation. For immediate saving, tap here on the icon; for saving only after a confirmation, tap on the icon.
- Page 15 Setting the date and time After calling up this function, you can tap on the parameters for the date and time to increase or decrease the parameters (now displayed white) using the buttons. Tap on "24H" to switch between 24-hour and 12-hour mode. Setting the line guide function After calling up this function, you can set the the reading line or reading bar (shadow bars that darken the upper and lower part of the display black).
- Page 16 SD card. The following operating systems are required for running mobilux Digital: Windows Vista, Windows 7 or Windows 8. mobilux Digital may also run on other Windows platforms, but this cannot be guaranteed. We can accept no liability for the data integrity of computers running operating systems other than those mentioned here.
- Page 17 Follow the installation instructions corresponding to the operating system installed on your computer. Tap the symbol to enable communication between the reading device and the mobilux Digital software previously installed. Tap the symbol in order to work with the reading device while the internal battery is being charged using the USB cable..
-
Page 18: Care Instructions
X Only clean the mobilux DIGITAL Touch HD with a soft, dry cloth. For heavier soiling (e.g. finger- prints), moisten the cloth slightly. X If you are not using the mobilux DIGITAL Touch HD, always keep it in the hard foam case sup- plied. -
Page 19: Warranty
Warranty Within the parameters of the applicable statutory provisions, we provide a warranty for the func- tioning of the product described in this manual with regard to faults arising in connection with manufacturing defects or material defects. In event of damage due to improper handling, including damage from a fall or impact, no warranty claims can be made.
