- Page 1 Operating instructions Electronic temperature sensor TC6702...
- Page 2 1 Functions and features The unit detects the system temperature in machines and installations. 2 Function The unit switches the two complementary outputs OUT1 / OUT2: - With rising temperature OUT1 closes and OUT2 opens when the set value [SET] is reached. - With falling temperature OUT1 opens and OUT2 closes, when the set value [RESET] is reached.
- Page 3 5 Setting RESET 1: locking ring 2: setting rings (manually adjustable after unlocking) 3: LED green: supply voltage O.K. 4: setting marks 5: LED yellow: value [SET] reached, OUT1 = ON / OUT2 = OFF] 6: process connection G¼ male pin 4 = Out1 / pin 2 = Out2 • Minimum distance between [SET] and [RESET] = 3 K.
- Page 4 6 Scale drawing M12 x1 Dimensions are in millimeters...
- Page 5 7 Technical data Operating voltage [V] ..................9.6...32 DC Current rating [mA] ......................500 Current consumption [mA] ....................< 30 Measuring range [°C / °F] ..............-25...140 / -13...284 Measuring element ...........1 x Pt 1000 to DIN EN 60751, class B Accuracy [K] ..................± 3 (setting accuracy) Repeatability [K] ......................±...
