Huawei CloudEngine 6850
Switch Configuration Guide for Dell EMC SC Series SANs
Dell EMC Configuration and Deployment Guide
Abstract
This document illustrates how to configure Huawei
series switches for use with Dell EMC™ SC Series storage using Dell
EMC best practices.
February 2018
®
CloudEngine 6850
Advertisement
Table of Contents
Related Manuals for Huawei CloudEngine 6850 Series
Summary of Contents for Huawei CloudEngine 6850 Series
- Page 1 Huawei CloudEngine 6850 Switch Configuration Guide for Dell EMC SC Series SANs Abstract ® This document illustrates how to configure Huawei CloudEngine 6850 series switches for use with Dell EMC™ SC Series storage using Dell EMC best practices. February 2018...
-
Page 2: Revisions
Dell believes the information in this document is accurate as of its publication date. The information is subject to change without notice. Huawei CloudEngine 6850 Switch Configuration Guide for Dell EMC SC Series SANs | SCG3464... -
Page 3: Table Of Contents
Configure breakout ports ............................ 8 2.10 Configure additional switch ..........................8 2.11 Calibrate link flapping protection setting (optional) ..................... 9 Technical support and resources ..........................10 Huawei CloudEngine 6850 Switch Configuration Guide for Dell EMC SC Series SANs | SCG3464... -
Page 4: Introduction
Note: For proper functionality, the switch must be at the firmware version shown in Table 2 before proceeding with configuration. Using previous firmware versions may have unpredictable results. Note: The latest firmware updates and documentation can be found at: www.huawei.com. This site requires a login. -
Page 5: Cabling Diagram
Introduction Cabling diagram The cabling diagram shown in Figure 1 represents the Dell EMC recommend method for deploying servers and SC Series storage arrays. Cabling diagram Huawei CloudEngine 6850 Switch Configuration Guide for Dell EMC SC Series SANs | SCG3464... -
Page 6: Dell Recommended Switch Configuration
An initial password is required for the first login via the console. Continue to set it? [Y/N]: Y Set a password and keep it safe! Otherwise you will not be able to login via the console. Huawei CloudEngine 6850 Switch Configuration Guide for Dell EMC SC Series SANs | SCG3464... -
Page 7: Configure Management Network
[*HUAWEI] interface range 10GE 1/0/1 to 10GE 1/0/48 [*HUAWEI-port-group] undo shutdown [*HUAWEI-port-group] flow-control Note: The flow-control command enables RX and TX flow control. [*HUAWEI-port-group] jumboframe enable 9216 [*HUAWEI-port-group] stp edged-port enable [*HUAWEI-port-group] quit Huawei CloudEngine 6850 Switch Configuration Guide for Dell EMC SC Series SANs | SCG3464... -
Page 8: Disable Link Flapping Protection
Disable link flapping protection The Huawei CE6850 switch has an inbuilt link flap protection, which by default turns off an interface if five link flapping events occur within an interval of ten seconds. The default values might cause interfaces on certain edge-devices to be turned off. -
Page 9: Calibrate Link Flapping Protection Setting (Optional)
Calibrate link flapping protection setting (optional) Huawei CE 6850 has an inbuilt link flap protection, which by default turns off an interface if five link flapping events occur within an interval of ten seconds. The default values might cause interfaces on certain edge- devices to be turned off. -
Page 10: A Technical Support And Resources
Dell TechCenter provide expertise that helps to ensure customer success on Dell EMC storage platforms. Additional referenced or recommended Dell publications: • Dell EMC Storage Compatibility Matrix • SC Series Technical Documents Huawei CloudEngine 6850 Switch Configuration Guide for Dell EMC SC Series SANs | SCG3464...
