08/2/2009
Ins-50012-MS Mace Security stand alone plastic reader and keypad
Technical Support
877-585-6223
Documentation on all Mace Security Products can be found on our web site - http://www.macepro.com/
Suitability
Wet environments
Security sensitive doors
Fitting
Exit button
(push to make)
2V DC release current rating
must be less than A.
* The diode current rating must
be equal to or greater than the
current in the release
Technical Help is available:
Grey
+2V DC
White
*
0V
User cards are NOT supplied with this unit.
support@mace.com
Monday - Friday 9am to 7pm (EST)
Mounted on metal surface
Readers mounted together
Black
-
+
S e c u r i t y Pro d u c t s
12 inches
between readers
9-5V DC
(fuse rating 1A)
Page
Advertisement
Table of Contents
Summary of Contents for Mace Ins-50012-MS
- Page 1 Technical Support 877-585-6223 support@mace.com Technical help is available: Monday - Friday 9am to 7pm (EST) Documentation on all Mace Security Products can be found on our web site - http://www.macepro.com/ Suitability Mounted on metal surface Wet environments Readers mounted together...
- Page 2 Please read the following notes before installing Electrical shock from voltages used in this system can cause injury or death. Prior to making any electrical connections, or performing maintenance and repair, ensure power is removed. Mains electrical connections should be made only by qualified personel in accordance with local regulation.
- Page 3 Setting The Master Code The first time the keypad is turned on the GREEN LEDs flash alternately. This indicates a 6 digit Master Code must now be entered. »The Master Code allows access to the Programming Menu. To set the Master Code, do the following: Press Press Press...
- Page 4 Changing the keypad backlight Enter 6 digit Master Code GREEN LEDs flash simultaneously indicating reader is in Programming Mode Press and hold = On Press for 3 seconds = default press = Off to exit programming mode Setting multiple entry codes (maximum = 120) Enter 6 digit Master Code GREEN...
- Page 5 Setting the keypad for additional security Enter 6 digit Master Code GREEN LEDs flash simultaneously indicating reader is in Programming Mode Press and hold = On When enabled, the keypad will Press for 3 seconds deactivate for 60 seconds if = default press there are 20 consecutive...
- Page 6 Adding proximity tokens Up to 2000 proximity tokens can be added to the keypad. Each token is allocated to a memory slot on the keypad. A note will need to be made of the memory slot a token is allocated to, a handy table is included in these instructions for this purpose.
- Page 7 Technical Help Here is the list of topics about this product that receive the most technical support inquiries. We list them here to help you speed up the installation and trouble shooting process. 1. I have connected the keypad correctly. Why doesn’t it open when I enter my code? Q- Check that there is power to the keypad by setting the keypad backlight to ON, and listening for keypad beeps.
- Page 8 Page 8...
