Summary of Contents for CJB WEX-QM871

  • Page 1 WEX-QM871 Intel QM87 User Manual Rev.01, Aug. 2015...

  • Page 2: Table Of Contents

    Contents Chapter 1 Product Information ................4 1.1 Block Diagram ..................... 4 1.2 Features ....................... 5 1.3 PCB Layout ....................7 1.4 Dimensions ....................9 1.5 Jumper Setting ..................10 1.6 Connector Function List ................13 1.7 Connector Definitions ................15 1.8 I/O Ports Power Output (max.) ..............
  • Page 3 2.25 Security Menu ..................66 2.26 Security Boot Menu ................67 2.27 Exit Menu ....................68 Chapter 3 Drivers Installation ................70 3.1 Intel Chipset Device Software ..............70 3.2 Intel Graphic Media Accelerator Driver ........... 73 3.3 LAN Driver ....................76 3.4 Audio Driver ....................

  • Page 4: Chapter 1 Product Information

    Chapter 1 Product Information This chapter introduces the product features, jumper and connector information. 1.1 Block Diagram Intel® Haswell...

  • Page 5: Features

    1.2 Features ® ® Generation Core™ i7/i5/i3/Celeron Intel Processor Processor on board; FCBGA1364 System Processor/ ® Intel 8 Series Chipset Family Mobile Chipset Chipsets Platform Controller Hub (PCH) BIOS Technology DDR3/DDR3L 1333/1600 MHz SDRAM Max. Memory Up to 8GB DDR3/DDR3L DRAM Capacity Socket 1 x 204-pin DDR3/DDR3L SO-DIMM...
  • Page 6 1 x RS-232/422/485 Audio 1 (Line-in, Line-out, Mic-in) Front Panel 1 8-bit programmable digital input/output 1 x RS-232 Rear I/O 2 x RJ45 HDMI USB 3.0 DC 12V Input 1x2*2-pin ATX power connector for DC +12V input Power Interval Programmable 1~255 sec/min Watchdog Timer Output System reset...

  • Page 7: Pcb Layout

    1.3 PCB Layout Top View...

  • Page 8: Bottom View

    Bottom View MINI-PCIe Rear I/O View LAN1 LAN2 USB1 COM1 HDMI...

  • Page 9: Dimensions

    1.4 Dimensions...

  • Page 10: Jumper Setting

    1.5 Jumper Setting JCMOS: CMOS Clear Pin No. Function Normal Operation (Default) Clear CMOS Contents 3 2 1 3 2 1 3 2 1 3 2 1 Jumper Setting JLVDS: LCD Power (+3.3V/+5V) Selection Pin No. Function LCD Power +3.3V (Default) LCD Power +5V 3 2 1 3 2 1...
  • Page 11 JLVDS1: LCD Panel Type Selection Jumper Setting LCD Panel Type Jumper Setting LCD Panel Type 800 x 600 1024 x 768 18bit 18bit (Default) 1024 x 768 1280 x 768 24bit 18bit 1280 x 800 1280 x 960 18bit 18bit 1280 x 1024 1366 x 768 24bit...
  • Page 12 JMINI-PCIE: Mini-PCIE_or mSATA Function Selection Pin No. Function Mini-PCIe (Default) mSATA 3 2 1 3 2 1 3 2 1 3 2 1 Jumper Setting JCOM: SP339E RS232/422/485 Slew Rate Selection Pin No. Function 250Kbps (Default) 1Mbps 3 2 1 3 2 1 3 2 1 3 2 1...

  • Page 13: Connector Function List

    1.6 Connector Function List Rear I/O Port List Connector Function Note COM1 Serial port connector LAN1, LAN2 RJ45 connector USB1 USB3.0 connector HDMI HDMI port connector VGA connector OnBoard Expansion Slot List Connector Function Note CHA-DIMM1 DDR3/DDR3L SO-DIMM connector MINI-PCIE Mini-PCI Express connector/mSATA (share) OnBoard I/O Connector List (1/2) Connector...
  • Page 14 OnBoard I/O Connector List (2/2) Connector Function Note USB2,USB3 USB2.0 with box-header CMOS BAT (CR2032) with box-header SPI1 Reserved for debug...

  • Page 15: Connector Definitions

    1.7 Connector Definitions The following sections provide pin definitions and detailed description of all on-board connectors. The connector definitions follow the following notation: Column Description Name Shows the pin-numbers in the connector. The graphical layout of the connector definition tables is made similar to the physical connectors. Type Analog Input.
  • Page 16 Rear I/O Port Pin Define LAN1 USB1 HDMI LAN2 COM1 COM1: RS-232 Serial Port (DB9) Connector Signal COM1 Type Note RS-232 Data Carrier Detect (DCD) Received Data (RXD) Transmitted Data (TXD) Data Terminal Ready (DTR) COM1 Ground RS-232 Data Set Ready (DSR) Request To Send (RTS) Clear To Send (CTS) Ring Indicator (RI#)
  • Page 17 LAN1, LAN2: RJ45 (LAN) Connectors LAN1, LAN2 Type Signal Note DIFF MDI0+ / TXD+ DIFF MDI0- / TXD- DIFF MDI1+ / RXD+ DIFF MDI2+ RJ45 DIFF MDI2- DIFF MDI1- / RXD- DIFF MDI3+ DIFF MDI3- USB1: USB3.0 Connectors USB1 Type Signal Note USB3.0 P2 power +5V...
  • Page 18 VGA: VGA (DB15) Connector Type Signal Note VGA Red color values VGA Green color values VGA Blue color values Not connected Ground Ground Ground Ground VGA power +5V Ground Not connected VGA DDC data VGA Horizontal synchronization VGA Vertical synchronization VGA DDC clock Note 1: VGA port pin.12 (DDC Data) and pin.15 (DDC Clock) Pull Up +5V/2.2KΩ.
  • Page 19 OnBoard Expansion Slot Pin Define CHA-DIMM1: DDR3/DDR3L SO-DIMM Slot (1/3) Signal Type CHA-DIMM1 Type Signal VREF_DQ Ground Ground Ground Ground DIFF DQS0# DIFF DQS0 Ground Ground Ground Ground DQ12 DQ13 Ground Ground DQS1# DIFF DQS1 DIFF Reset# Ground Ground DQ10 DQ14 DQ11 DQ15...
  • Page 20 CHA-DIMM1: DDR3/DDR3L SO-DIMM Slot (2/3) Signal Type CHA-DIMM1 Type Signal Ground Ground CKE0 CKE1 VDDQ +1.35V VDDQ +1.35V (Note1) (Note1) Not connected VDDQ +1.35V VDDQ +1.35V (Note1) (Note1) VDDQ +1.35V VDDQ +1.35V (Note1) (Note1) VDDQ +1.35V VDDQ +1.35V (Note1) (Note1) VDDQ +1.35V VDDQ +1.35V (Note1)
  • Page 21 CHA-DIMM1: DDR3/DDR3L SO-DIMM Slot (3/3) Signal Type CHA-DIMM1 Type Signal DQ34 DQ39 DQ35 Ground Ground DQ44 DQ40 DQ45 DQ41 Ground Ground DIFF DQS5# DIFF DQS5 Ground Ground DQ42 DQ46 DQ43 DQ47 Ground Ground DQ48 DQ52 DQ49 DQ53 Ground Ground DQS6# DIFF DQS6 DIFF...
  • Page 22 MINI-PCIE: Mini-PCIe Express Slot Signal Type MINI-PCIE Type Signal WAKE# +3.3Vaux (Note 1) Not connected Ground Not connected +1.5V (Note2) CLKREQ# Not connected Ground Not connected PCIE_CLOCK- DIFF Not connected PCIE_CLOCK+ DIFF Not connected Ground Not connected Not connected Ground Not connected Not connected Ground...
  • Page 23 OnBoard I/O Connector Pin Define AUDIO: Audio with Box-header AUDIO Type Signal Note Line-in (Right) Line-in (Left) Line-in jack detect Mic-in jack detect Mic-in (Right) Mic-in (Left) Line-out jack detect Audio Ground Box-header 2.0mm Line-out (Right) Line-out (Left) BAT: CMOS Battery with Box-header Type Signal Note...
  • Page 24 CPUFAN: CPU FAN 4-Pin Connector CPUFAN Type Signal Note Ground CPU FAN power +12V CPU FAN Sense CPU FAN Control Note 1: CPUFAN pin.2 power supply maximum +12V/0.75A Note 2: CPUFAN pin.3 sensor pull up +12V/4.7K Ω SYSFAN: System FAN 3-Pin Connector SYSFAN Type Signal...
  • Page 25 INV: LCD Inverter with Box-header Type Signal Note Inverter power +12V Inverter power +12V Ground LCD Panel backlight adjustment Box-header 2.5mm LCD Panel backlight enable Note 1: INV pin.1~2 total power supply maximum +12V/1.5A SMB: SMBus with Pin-header Type Signal Note SMBus clock (+3.3V Level)
  • Page 26 LVDS: LCD Panel LVDS 18/24bit Box-header LVDS Type Signal Note Ground Ground DIFF LVDS_A3+ DIFF LVDS_A3- DIFF LVDS_ACLK+ DIFF LVDS_ACLK- DIFF LVDS_A2+ LVDS_A2- DIFF DIFF LVDS_A1+ LVDS_A1- DIFF LVDS_A0+ DIFF DIFF LVDS_A0- Ground Ground DIFF LVDS_B3+ LVDS_B3- DIFF LVDS_BCLK+ DIFF DIFF LVDS_BCLK- LVDS_B2+...
  • Page 27 SATA1, SATA2: SATA III Port Connector SATA1, SATA2 Type Signal Note Ground DIFF SATA TX+ DIFF SATA TX- Ground DIFF SATA RX- DIFF SATA RX+ Ground SATA_PWR: SATA Power with Box-header SATA_PWR Type Signal Note SATA power +5V Ground Ground Box-header 2.5mm SATA power +12V SATA_PWR pin.1 power supply maximum +5V/1.5A...
  • Page 28 USB2: USB 2.0 Ports with Box-header USB2 Type Signal Note USB2.0 P2 Power +5V 1, 2 USB2.0 P3 Power +5V 1, 2 DIFF USB2.0 P2 D- DIFF USB2.0 P3 D- DIFF USB2.0 P2 D+ DIFF USB2.0 P3 D+ Box-header 2.0mm Note 1: USB2 pin.1~2 power supply maximum +5V/0.5A Note 2: For USB2.0 cabling it is required to use only Hi-Speed USB cable, specified in USB2.0 standard.
  • Page 29 SPI1: SPI Count Header - (reserved for debug) SPI1 Type Signal Note SPI_CS0_N +V3.3M_SPI SPI_SO SPI_HOlD_N SPI_CK Pin-header 2.0mm SPI_SI...

  • Page 30: I/O Ports Power Output (Max.)

    ※1. WEX-QM871 M/B total +12V maximum power output watts = +12V/4.25A (51W) ※2. WEX-QM871 M/B total +5V maximum power output watts = +5V/6.8A (34W) ※ 3. WEX-QM871 M/B total +3.3V maximum power output watts = +3.3V/2.1A (7W) OnBoard Expansion Slots Power Output (max.)
  • Page 31 +5V/0.5A 2.5W pin.1~2 (USB3) ※1. WEX-QM871 M/B total +12V maximum power output watts = +12V/4.25A (51W) ※2. WEX-QM871 M/B total +5V maximum power output watts = +5V/6.8A (34W) ※3. WEX-QM871 M/B total +3.3V maximum power output watts = +3.3V/2.1A (7W)

  • Page 32: Chapter 2 Bios Setup

    Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Main Advanced Boot Security Exit Main BIOS Information Choose the system default language Model Name WEX-QM871 BIOS Version R000 BIOS Tag 0000-00-000 Build Date 03/25/2014 ME Firmware Version 9.0.30.1482 PCH Information LynxPoint QM87 / C2 Processor Information Intel (R) Celeron (R) CPU 2000E @ 2.20GHz...

  • Page 33: Advanced Menu

    2.2 Advanced Menu This section allows you to configure CPU and other system devices for basic operation through the following sub-menus. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Main Advanced Boot Security Exit Advanced CPU Configuration ►CPU Configuration Parameters ►PCH-IO Configuration...
  • Page 34 □ Platform Misc Configuration □ Power Management...

  • Page 35: Cpu Configuration (1/2)

    2.3 CPU Configuration (1/2) Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Advanced Number of cores to CPU Configuration enable in each processor Intel(R) Celeron(R) CPU 2000E @ 2.20GHz package. CPU Signature 306c3 Microcode Patch Max CPU Speed 2200 MHz Min CPU Speed 800 MHz...

  • Page 36: Cpu Configuration (2/2)

    2.3 CPU Configuration (2/2) Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Advanced Package C State limit Execute Disable Bit [Enabled] Intel Virtualization Technology [Enabled] Hardware Prefetcher [Enabled] Adjacent Cache Line Prefetch [Enabled] Boot performance mode [Turbo Performance] EIST [Enabled] CPU C states...
  • Page 37 □ Adjacent Cache Line Prefetch The processor has a hardware adjacent cache line prefetch mechanism that automatically fetches an extra 64-byte cache line whenever the processor requests for a 64-byte cache line. This reduces cache latency by making the next cache line immediately available if the processor requires it as well.
  • Page 38 □ CPU C7 Report The item allows BIOS to report the CPU C7 state. Choices: Disabled, CPU C7, CPU C7s. □ C7 Latency The item selects short or long time when BIOS reports CPU C7 state. Choices: Short, Long. □ Package C State limit The item selects “Auto”...

  • Page 39: Pch-Io Configuration

    2.4 PCH-IO Configuration Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Advanced PCI Express PCH-IO Configuration Configuration Settings ►PCI Express Configuration ►Intel (R) Rapid Start Technology Azalia [Auto] PCH LAN Controller [Enabled] Wake on LAN [Disabled] Select Screen : Select Item Enter : Select +/- : Change Opt.

  • Page 40: Pci Express Configuration

    2.5 PCI Express Configuration Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Advanced Enable or disable PCI PCI Express Configuration Express Clock Gating for each root port. PCI Express Clock Gating [Enabled] DMI Link ASPM Control [Enabled] DMI Link Extended Synch Control [Disabled] Select Screen...

  • Page 41: Intel Rapid Start Technology

    ® 2.6 Intel Rapid Start Technology Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Advanced Enable or disable Intel (R) Rapid Start Technology Intel (R) Rapid Start Technology. Intel (R) Rapid Start Technology [Disabled] Select Screen : Select Item Enter : Select +/- : Change Opt.

  • Page 42: Sata Configuration

    2.7 SATA Configuration Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Advanced Determines how SATA SATA Configuration controller(s) operate. SATA Mode Selection [AHCI] Aggressive LPM Support [Enabled] SATA Controller Speed [Default] SMART Self Test [Disabled] ►SATA 1 ‒ Empty ►SATA 2 ‒...
  • Page 43 □ SATA 1 – Empty □ SATA 2 – Empty □ SATA 3 – Empty...

  • Page 44: Serial Ata Port Configuration - Sata 1

    2.8 Serial ATA Port Configuration – SATA 1 Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Advanced Enable or Disable SATA Serial ATA Port Configuration Port SATA 1 Empty Software Preserve Unknown Port 4 [Enabled] Hot Plug [Disabled] SATA Device Type [Hard Disk Drive]...

  • Page 45: Serial Ata Port Configuration - Sata 2

    2.9 Serial ATA Port Configuration – SATA 2 Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Advanced Enable or Disable SATA Serial ATA Port Configuration Port SATA 2 Empty Software Preserve Unknown Port 5 [Enabled] Hot Plug [Disabled] SATA Device Type [Hard Disk Drive]...

  • Page 46: Serial Ata Port Configuration - Sata 3

    2.10 Serial ATA Port Configuration – SATA 3 Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Advanced Enable or Disable SATA Serial ATA Port Configuration Port SATA 3 Empty Software Preserve Unknown Port 2 [Enabled] Hot Plug [Disabled] SATA Device Type [Hard Disk Drive]...

  • Page 47: System Agent Configuration

    2.11 System Agent Configuration Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Advanced Enable or disable CPU System Agent Configuration Audio Device. [Enabled] CPU Audio Device ►Graphics Configuration ►DMI Configuration ►Memory Configuration Select Screen : Select Item Enter : Select +/- : Change Opt.

  • Page 48: Graphics Configuration

    2.12 Graphics Configuration Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Advanced Select which of Graphics Configuration IGFX/PEG/PCI Graphics device should be Primary Primary Display [Auto] Display Or select SG for Internal Graphics [Auto] Switchable Gfx. Aperture Size [256MB] DVMT Pre-Allocated [32M]...
  • Page 49 □ DVMT Total Gfx Mem The item selects DVMT Total Graphics Memory size used by Internal Graphics Device. Choices: 128M, 256M, MAX. □ RC6 (Render Standby) ® Enable or disable Intel Graphics Render Standby support Choices: Enabled, Disabled. □ Primary IGFX Boot Display The item selects the display device which will be activated during POST.

  • Page 50: Dmi Configuration

    2.13 DMI Configuration Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Advanced Enable or disable the DMI Configuration control of Active State Power Management on SA Gen2 side of the DMI Link. DMI Link ASPM Control [L0sL1] DMI Gen 2 [Auto] Select Screen...

  • Page 51: Memory Configuration

    2.14 Memory Configuration Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Advanced NMode Support Option. Memory Information Memory Frequency 1600 Mhz Total Memory 4096 MB (DDR3) Memory Voltage 1.35V DIMM#0 4096 MB (DDR3) CAS Latency (tCL) Minimum delay time CAS to RAS (tRCDmin) Row Precharge (tRPmin) Active to Precharge (tRASmin)

  • Page 52: Usb Configuration

    2.15 USB Configuration Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Advanced Enables Legacy USB USB Configuration support. AUTO option disables legacy support USB Devices : if no USB devices are 1 Keyboard, 2 Mice, 1 Point, 3 Hubs connected.
  • Page 53 □ USB Ports Per-Port Disable Control The item activates the capability of the motherboard to Enable or Disable each USB Port independently. Choices: Enabled, Disabled. Enabled: USB Port #0 [Enable/Disable] USB Port #1 [Enable/Disable] USB Port #2 [Enable/Disable] USB Port #3 [Enable/Disable] USB Port #8 [Enable/Disable] USB Port #9 [Enable/Disable] USB Port #6 [Enable/Disable]...

  • Page 54: Super I/O Configuration

    2.16 Super I/O Configuration Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Advanced Set Parameters of Serial Super I/O Configuration Port 1 (COMA) Fintek Super I/O ‒ F81866A ►Serial Port 1 Configuration ►Serial Port 2 Configuration Watchdog [Disabled] Select Screen : Select Item...

  • Page 55: Serial Port 1 Configuration

    2.17 Serial Port 1 Configuration Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Advanced Enable or Disable Serial Serial Port 1 Configuration Port (COM) Serial Port [Enabled] Device Settings IO=3F8h; IRQ=4; Change Settings [Auto] Select Screen : Select Item Enter : Select +/- : Change Opt.

  • Page 56: Serial Port 2 Configuration

    2.18 Serial Port 2 Configuration Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Advanced Enable or Disable Serial Serial Port 2 Configuration Port (COM) Serial Port [Enabled] Device Settings IO=2F8h; IRQ=3; Change Settings [Auto] Serial port Mode [RS-232] Select Screen : Select Item...

  • Page 57: Hardware Monitor

    2.19 Hardware Monitor Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Advanced Enable or Disable Smart Hardware Monitor Fan Feature. [Enabled] Smart Fan Function ►CPU Fan Configuration ►System Fan Configuration Fan Pulses per Revolution : +35 C CPU Temperature : +37 C System Temperature...

  • Page 58: Cpu Fan Configuration

    2.20 CPU Fan Configuration Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Advanced Smart Fan Operation Mode. CPU Fan Configuration CPU Fan Mode [Standard] Faster Fan [Enabled] Select Screen : Select Item Enter : Select +/- : Change Opt. F1 : General Help F2 : Previous Values F3 : Optimized Defaults...

  • Page 59: System Fan Configuration

    2.21 System Fan Configuration Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Advanced Smart Fan Operation Mode. System Fan Configuration System Fan Mode [Standard] Faster Fan [Enabled] Select Screen : Select Item Enter : Select +/- : Change Opt. F1 : General Help F2 : Previous Values F3 : Optimized Defaults...

  • Page 60: Platform Misc Configuration

    2.22 Platform Misc Configuration Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Advanced PCI Express Native Platform Misc Configuration Support Enable/Disable. This feature is only Native PCIE Enable [Enabled] available in Vista. Native ASPM [Enabled] Select Screen : Select Item Enter : Select +/- : Change Opt.

  • Page 61: Power Management

    2.23 Power Management Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Advanced Select ACPI sleep state Power Management the system will enter when the SUSPEND button ACPI Sleep State [S1 only (CPU Stop Clock)] is pressed. Resume By RTC Alarm [Disabled] Wake by Event [Disabled]...

  • Page 62: Boot Menu

    2.24 Boot Menu Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Main Advanced Boot Security Exit Boot Number of seconds to Boot Configuration wait for setup activation Key. Setup Prompt Timeout 65535(0xFFFF) means Bootup NumLock State [On] indefinite waiting.
  • Page 63 □ GateA20 Active Upon Request – GA20 can be disabled using BIOS services. Always – Do not allow disabled GA20; this option is useful when any RT codes are executed above 1MB. □ Option ROM Massages This item sets display mode for option ROM. Choices: Forces BIOS, Keep current.

  • Page 64: Csm Parameters

    2.25 CSM Parameters Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Boot This option controls if [Enabled] Launch CSM CSM will be launched [UEFI and Legacy] Boot option filter [Do not launch] Launch PXE OpROM policy [Legacy only] Launch Storage OpROM policy [Legacy only] Launch Video OpROM policy...
  • Page 65 □ Launch Video OpROM policy The item controls the execution of UEFI and Legacy Video OpROM. Choices: Do not launch, Legacy only. □ Other PCI device ROM priority It determines OpROM execution policy for devices other than Network, Storage, or video.

  • Page 66: Security Menu

    2.25 Security Menu Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Main Advanced Boot Security Exit Security Set Administrator Password Description Password If ONLY the Administrator’s password is set , then this only limits access to Setup and is only asked for when entering Setup.

  • Page 67: Security Boot Menu

    2.26 Security Boot Menu Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Security Secure Boot can be enabled if 1.System System Mode Setup running in User mode Secure Boot Not Active with enrolled Platform Key (PK) 2.CSM function Secure Boot Support [Enabled] is disabled...

  • Page 68: Exit Menu

    2.27 Exit Menu Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc . Main Advanced Boot Security Exit Exit Reset the system after Save Changes and Reset saving the changes. Discard Changes and Exit Restore Defaults Save as User Defaults Restore User Defaults Boot Override Launch EFI Shell from filesystem device...
  • Page 69 □ Boot Override These items display the available devices. The number of device items that appears on the screen depends on the number of devices installed in the system. □ Launch EFI Shell from filesystem device The item attempts to EFI Shell application from one of the available file system devices.

  • Page 70: Chapter 3 Drivers Installation

    Chapter 3 Drivers Installation This chapter introduces driver installation information. Please insert the utility CD to CD-ROM drive, the install menu will appear automatically, if the install menu does not list suitable driver of Operate System or appear automatically, please select corresponding driver of utility CD to install. The Windows 7 driver installation steps are as below.
  • Page 71 Step 2: Read the License Agreement and click “Accept” to continue. Step 3: Click “Install” to continue.
  • Page 72 Step 4: Click “Finish” to complete setup.

  • Page 73: Intel Graphic Media Accelerator Driver

    3.2 Intel Graphic Media Accelerator Driver Step 1: Click “Next” to continue. Step 2: Click “Yes” to continue.
  • Page 74 Step 3: Click “Next” to continue. Step 4: Click “Next” to continue.
  • Page 75 Step 5: Click “Yes” to complete setup.

  • Page 76: Lan Driver

    3.3 LAN Driver Step 1: Click “Next” to continue. Step 2: Click “Next” to continue.
  • Page 77 Step 3: Click “Next” to continue. Step 4: Click “Install” to continue.
  • Page 78 Step 5: Click “Finish” to complete setup.

  • Page 79: Audio Driver

    3.4 Audio Driver Step 1: Click “Next” to continue. Step 2: Click “Finish” to complete setup.

  • Page 80: Usb Driver

    3.5 USB Driver Step 1: Click “Next” to continue. Step 2: Click “Yes” to continue.
  • Page 81 Step 3: Click “Next” to continue. Step 4: Click “Next” to continue.
  • Page 82 Step 5: Click “Finish” to complete setup.

  • Page 83: Iamt Driver

    3.6 iAMT Driver Step 1: Click “Next” to continue. Step 2: Click “Yes” to continue.
  • Page 84 Step 3: Click “Next” to continue. Step 4: Click “Finish” to complete setup.

  • Page 85: Appendix A: Watchdog Timer

    Appendix A: Watchdog Timer The working algorithm of the WDT function can be simply described as a counting process. The Time-Out Interval can be set through software programming. The availability of time-out interval is set by software. The System Board allows users control WDT through dynamic software programming. The WDT starts counting when it is activated.
  • Page 86 // Enter Extended Function Mode outp(0x2E, 0x87); outp(0x2E, 0x87); // Select Logic Device 7 outp(0x2E, 0x07); outp(0x2F, 0x07); // Select & Enable GPIO1 outp(0x2E, 0x27); outp(0x2F, inp(0x2F) | 0x05); // Assign Pin 70 to be a WDTO# Signal outp(0x2E, 0x2C); outp(0x2F, inp(0x2F) &...
  • Page 87 Definitions of Variables: Value of Count-mode Register : 1) 0x00 -- Count down in seconds (Bit3=0) 2) 0x08 -- Count down in minutes (Bit3=1) Value of Time-out Value Register : 1) 0x00 -- Time-out Disable 2) 0x01~0xFF -- Value for counting down...

  • Page 88: Appendix B: Gpio

    Appendix B: GPIO The System Board provides 4 dedicated output ports and 4 programmable I/O ports that can be individually configured to perform a simple I/O function. Users can configure 4 programmable I/O ports to become an input or output port by programming register bit of I/O Selection .To invert port value, the setting of Inversion Register has to be made .
  • Page 89 // Enter Extended Function Mode outp(0x2E, 0x87); outp(0x2E, 0x87); // Assign Pin111-118 to be GPIO port outp(0x2E, 0x27); outp(0x2F, inp(0x2F) & 0xF3); outp(0x2E, 0x28); outp(0x2F, inp(0x2F) | 0x20); // Select Logic Device 6 outp(0x2E, 0x07); outp(0x2F, 0x06); // Enable GPIO Port outp(0x2E, 0x30);...
  • Page 90 Definitions of Variables: Each bit in the lower nibble of each Register represents the setting of a GPIO port. Super IO Pin Pin Name GPIO DIO GPIO80 GPIO DIO-In0 GPIO81 GPIO DIO-In1 GPIO82 GPIO DIO-In2 GPIO83 GPIO DIO-In3 GPIO84 GPIO DIO-Out0 GPIO85 GPIO DIO-Out1 GPIO86...
