Summary of Contents for Botex PSA-631
- Page 1 PSA-631 power distributor...
- Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 13.10.2017, ID: 258281...
-
Page 3: Table Of Contents
General information..........................4 1.1 Further information........................... 5 1.2 Notational conventions........................6 1.3 Symbols and signal words....................... 6 Safety instructions............................. 8 Features............................... 12 Installation and starting up........................ 13 Connections and controls........................14 Technical specifications........................18 Protecting the environment......................19 PSA-631 power distributor... -
Page 4: General Information
If you sell the unit please make sure that the buyer also receives this manual. Our products are subject to a process of continuous development. Thus, they are subject to change. PSA-631 power distributor... -
Page 5: Further Information
Our online guides provide detailed information on technical basics Online guides and terms. Personal consultation For personal consultation please contact our technical hotline. If you have any problems with the device the customer service will Service gladly assist you. PSA-631 power distributor... -
Page 6: Notational Conventions
The letterings for connectors and controls are marked by square brackets and italics. Examples: [VOLUME] control, [Mono] button. 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual. PSA-631 power distributor... - Page 7 This combination of symbol and signal word indicates a pos- sible dangerous situation that can result in material and environmental damage if it is not avoided. Warning signs Type of danger Warning – high-voltage. Warning – danger zone. PSA-631 power distributor...
-
Page 8: Safety Instructions
This device may be used only by persons with sufficient physical, sensorial, and intellectual abilities and having corresponding knowledge and experience. Other persons may use this device only if they are supervised or instructed by a person who is responsible for their safety. PSA-631 power distributor... - Page 9 Never let children unattended use electrical devices. DANGER! Electric shock caused by high voltages inside Within the device there are areas where high voltages may be present. Never remove any covers. There are no user-serviceable parts inside. PSA-631 power distributor...
- Page 10 If in doubt, seek advice from a regis- tered electrician. NOTICE! Risk of fire Do not cover the device nor any ventilation slots. Do not place the device near any direct heat source. Keep the device away from naked flames. PSA-631 power distributor...
- Page 11 Failure to do so could result in damage to the device and possibly injure the user. Unplug the device before electrical storms occur and when it is unused for long periods of time to reduce the risk of electric shock or fire. PSA-631 power distributor...
-
Page 12: Features
Input – Cable with CEE plug Outputs – 4 × 5-pin CEE built-in socket with hinged lid Circuit breaker with trigger switch for each output Four-pole residual current device (RCD, residual current circuit breaker) for the input PSA-631 power distributor... -
Page 13: Installation And Starting Up
Create all connections while the device is off. Use power supply cables with earthed earthing pin plug or 5-pin CEE-plug only. Rack mounting The unit has been designed for rack mounting in a standard 19-inch rack; it occupies three rack units. PSA-631 power distributor... -
Page 14: Connections And Controls
Connections and controls Connections and controls Front panel PSA-631 power distributor... - Page 15 In case of overload (> 16 A), the circuit breaker automatically disconnects the supply to the assigned CEE socket. 4 [L1 / L2 / L3] Measuring instruments for voltage (‘V’) and current (‘A’) of the three phases. PSA-631 power distributor...
- Page 16 Connections and controls Rear panel PSA-631 power distributor...
- Page 17 Connections and controls 5 4 × 5-pin CEE built-in socket with hinged lid. 6 Power cable with CEE plug. PSA-631 power distributor...
-
Page 18: Technical Specifications
4 × 32 A, 4-pin Outputs 4 × 5-pin CEE built-in socket Operating supply voltage AC 400 V 50 Hz Dimensions (W × H × D) 482 mm × 134 mm (3 RU) × 256.7 mm Weight 8.2 kg PSA-631 power distributor... -
Page 19: Protecting The Environment
Dispose of this device through an approved waste disposal firm or through your local waste facility. When discarding the device, comply with the rules and regulations that apply in your country. If in doubt, consult your local waste disposal facility. PSA-631 power distributor... - Page 20 Notes PSA-631 power distributor...
- Page 21 Notes PSA-631 power distributor...
- Page 22 Notes PSA-631 power distributor...
- Page 24 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
