Summary of Contents for King-Pigeon security W12
- Page 1 HD Camera WIFI Network Wireless Sensors Movement Detection Email Notification App Push Notification SMS & Phone Call Notification GSM WIFI CAMERA ALARM SYSTEM HD WIFI Camera with SMS & Phone Call Notification User Manual Ver 1.2...
-
Page 2: Table Of Contents
Table of Content 1. The Introduction......................3 2. The Specification....................... 3 3. The Diagram......................4 4. The Settings of WIFI camera................... 5 4.1 The User Registration................... 5 4.2 The Mobile APP Settings................5 4.3 Add Wireless Sensors. -
Page 3: The Introduction
GSM 3G WIFI Camera Alarm System 1. The Introduction. The GSM WIFI Camera is specially designed for home security.It could be used as a HD WIFI Camera Alarm System and a GSM SMS Alarm System. The WIFI Camera had included most functions of the WIFI camera in the present market, and meanwhile its GSM alarm system can support 64 wireless zones, and support App push notification, SMS &... -
Page 4: The Diagram
GSM 3G WIFI Camera Alarm System 3. The Diagram. PPower Adapter TF Card GSM Antenna SIM Card WIFI Antenna Network Interface Used to connect with the LAN port of the Router. Micro Speaker When using a network cable connected to the Internet use. Network Interface GSM antenna GSM signal reception. -
Page 5: The Settings Of Wifi Camera
GSM 3G WIFI Camera Alarm System 4. The Settings of WIFI camera. Please scan the QR code to download the mobile app: Or visit: http://yoosee.co/ 4.1 The User Registration. Use your mobile phone number or email to register a user ID according to your country code. 4.2 The Mobile APP Settings. -
Page 6: Add Wireless Sensors
GSM 3G WIFI Camera Alarm System 4.2.2.1 add the device by ‘Smartlink’ Make sure your mobile and your camera are using the same WIFI network in your first programming. Please click 【Smartlink】and follow the step as below, the app will add all the cameras automatically. 4.2.2.2 Add device manually: Make sure the camera’s power is on, and connect with the WIFI network already, then Click 【Manual】, it will be like the picture as below:... - Page 7 GSM 3G WIFI Camera Alarm System Zone Settings. Note: This function is optional, please make sure your device has this function. The device supports 8 pcs remote controls, 64 wireless zones (433 frequency), supports 8 groups. Learning the code as follows Click【Device】→【Device name】→【Settings】→【Defense Area settings】...
-
Page 8: The Pc Cms Settings
GSM 3G WIFI Camera Alarm System 4.4 The PC CMS Settings. Please download the PC CMS software at http://yoosee.co/ Log Account in PC. Two different ways to log in as below: 1. 【Remote Log In】: Use the ID of your mobile app to log in. 2. -
Page 9: The Settings Of Gsm Alarms
GSM 3G WIFI Camera Alarm System The video setting in PC. Click on the monitor screen, select【start video】(Notice: the video will save the local on your PC) Playback: this device can playback the video from computer, open the CMS software, choose “playback”... - Page 10 GSM 3G WIFI Camera Alarm System 2） Set the phone number to receive the alert. (Max. 9 phone numbers) SMS Commands Return SMS Message Password + Serial Number + A + Function Code + # + Phone Number + # Tel1: Empty Tel2: Empty For Example:...
- Page 11 GSM 3G WIFI Camera Alarm System 6） Inquiry the device information remotely SMS Commands Return SMS Message Password+EE Armed or Disarmed GSM Value: For Examples: 1234EE IMEI Code: Notice: The GSM Signal Value range: 1~31. 7） Arm/Disarm the devices SMS Commands Return SMS Message Password+AA Armed By “Telephone Number”...
-
Page 12: The Warranty
GSM 3G WIFI Camera Alarm System 6. The Warranty. 1) This system is warranted to be free of defects in material and workmanship for one year. 2) This warranty does not extend to any defect, malfunction or failure caused by abuse or misuse by the Operating Instructions.
