Summary of Contents for RJ Laser Photonic HairLaser
- Page 1 Photonic HairLaser Natural care with light Operating Instructions...
-
Page 2: Table Of Contents
Contents Overview ......................3 Introduction ......................4 Safety information ....................5 General information Liability disclaimer Safety standards Decommissioning in the event of a hazard Safety advice Delivery contents ....................7 Assembly instructions..................8 Working with the touchscreen..............11 Service menu..................... 12 Error messages.................... -
Page 3: Overview
Overview Fast and easy touchscreen operation Daily work has never been easier. Slot for memory card Simple software update procedure to support future applications. Safe against misuse The safety key protects Ergonomic height against unauthorized use. adjustment The laser hood can be variably adjusted for optimal positioning above the head. -
Page 4: Introduction
The unique technology of the Photonic HairLaser nurtures and regenerates skin and hair in a natural way. The new therapy for satisfied customers. -
Page 5: Safety Information
Photonic HairLaser if given to others. Liability disclaimer You may use the Photonic HairLaser only for the purposes described in these operating instructions and only under supervision! The Photonic HairLaser must be operated only together with original accessory parts. The manufacturer is not liable for the device and the consequences resulting from operation or applications that are not described within these operating instructions. -
Page 6: Decommissioning In The Event Of A Hazard
Your Photonic HairLaser is equipped with a safety key to prevent unauthorized use. The laser can be operated only with the key inserted. When the Photonic HairLaser is not in use, the key should always be removed and stored separate from the device in order to prevent unauthorized use. -
Page 7: Delivery Contents
Delivery contents Contents when delivered The Photonic HairLaser is supplied partially assembled in three packages. The stand base package contains: Stand base 4 wheels (2 with brakes) The stand tube package contains: Long stand tube Short stand tube with handle... -
Page 8: Assembly Instructions
Assembly instructions The Photonic HairLaser can be assembled easily in just a few minutes. No tools are required. Safety information The stand rod contains a powerful spring mechanism. Caution: There is a risk of injury when opening a tightened locking screw. - Page 9 Insert the long stand rod (with thread point- ing downwards) down into the stand base and turn clockwise until the stop. Secure the rod to the stand base from below using the butterfly screw (do not forget the washer). Now attach the short stand Now place the laser rod (with the shorter end hood on the stand and...
- Page 10 Insert the connection cable for the power supply into the back of the laser hood and secure the cable to the stand using the cable clips. Once you have plugged in the power cord, your Photonic HairLaser is ready to use. You can now simply turn the key to switch on the device.
-
Page 11: Working With The Touchscreen
Working with the touchscreen The HairLaser is ready To start a treatment, simply press the “Ready” button on the “Stand-by” screen. That takes you to the “Treatment time” screen. Selecting the treatment time Stopping treatment The treatment time is factory set to 10 Treatment can be stopped at any time by minutes. -
Page 12: Service Menu
You should need to access the functions of the service menu only if you wish to personally customize the basic settings of your Photonic HairLaser (e.g. language, energy saving mode, or button clicks), to From the treatment time screen, pressing do special test functions, or to update the the “Stand-by”... - Page 13 You can change the language of the software on your Photonic HairLaser here. Version indicator Under “Version” you can view information on the current version of the hardware and software of your Photonic HairLaser.
- Page 14 You can save energy by setting the screensaver to activate sooner. By default, the screensaver activates after 10 minutes of inactivity. Power indicator The power indicator indicates the total time that the Photonic HairLaser has been used for treatment. The power indicator screen...
- Page 15 “On”. Before activating the “Logging” func- tion, you must insert an SD card into your Photonic HairLaser. Ensure that the contact strips are facing down and that the beveled corner is for- ward. A correctly inserted card will be indicated by a corresponding sym- bol in the Stand-by screen.
-
Page 16: Error Messages
Error messages Operating display not visible Error message If you turn on the safety key and the “Power If the laser diodes are not operating cor- On” LED does not light up and no image rectly or an additional laser probe is not appears on the touchscreen, this may be be- detected (due to cable problem or probe cause the power adapter is not connected... -
Page 17: Care And Maintenance
Do not use solvents! Calibration and safety check Your Photonic HairLaser does not contain any user-serviceable internal parts or compo- nents. There is thus no reason to open the device's housing. The device should be checked and recalibrated once a year at the latest. Please con-... -
Page 18: Technical Description
Technical description Technical data Class 2M laser therapy device Photonic HairLaser Floorstanding device, corded IP rating IPX0 Absolute uncertainty of laser power measurement Power adapter FRIWO FW7362M/12 Power supply 100-240 V~ / 50-60 Hz / 700 mA Weight 18 kg Dimensions (L x W x H) Approx. - Page 19 Laser diodes Quantity Wavelength 655 nm Power output 5 mW (max) per laser diode Laser type Continuous wave (CW) NOHD* 0.14 m *) Safety margin (NOHD): The distance at which the radiation intensity or radiation is equal to the corresponding limit for the maximum permissible radiation of the cornea (MPE = maximum permissible exposure).
- Page 20 λ = 655 nm, cw Laser Diode Data: Lasertherapy Device Photonic Hair 108 x 5 mW / 655 nm Serial-No.: EN 60825-1:2007 12161- 12 Serial-No.: 12161- 12 Laser Diode Data: 108 x 5 mW / 655 nm Use Power Supply Laser Diode Data: 108 x 5 mW / 655 nm Globtek 10V only!
-
Page 21: Warranty And Disposal
The manufacturer’s warranty is valid for 24 months. The manufacturer is only responsible for the features of the Photonic HairLaser as warranted by the operating instructions if the device has been operated carefully and in accordance with the operating instructions. -
Page 22: Manufacturer/Distributor
Manufacturer/Distributor REIMERS & JANSSEN GmbH Medical Laser Technology Fabrikstraße 22 service@rj-laser.com www.rj-laser.com 79183 Waldkirch, Germany Tel. +49 (0) 7681 - 493 4149 Fax +49 (0) 7681 - 493 4150 Quality management certified according to EN ISO 13485: 2003 + AC: 2009 Publisher Editor Photographs Volker...
