Summary of Contents for Inrico T196
- Page 1 T196 FCC ID: 2AIV6-T196 Please read this instruction book carefully before use and keep this with care...
- Page 2 Warning ● Flammable environment (gas, dust and fog, etc.) ● Please turn off the radio before getting close to the blasting zone or detonator areas. General information before use Please observe the following instructions to prevent fire, injury or damage to the radio.
-
Page 3: Table Of Contents
Contents Unpacking and checking equipment Accessories Preparation work Using the Lithium Battery Feature of the Lithium battery Charging for the Lithium battery Installing accessories Installing/Removing battery Installing antenna Installing belt clip Installing sling Installing headset Knowing the device well Unit structure Volume selector/ON and OFF switch Push To Talk button PTT Session selector... -
Page 4: Unpacking And Checking Equipment
Unpacking and checking equipment Note: following instructions is only suitable for authorized retailers and service providers.Carefully unpack the radio. We recommend you check the items listed in the following table before discarding the package. If any item is missing, please contact local dealer immediately. Accessories: Number Items... -
Page 5: Using The Lithium Battery
Using the Lithium Battery Charge before use To reduce electrical emission in battery, please remove the battery from device if not in use withina long time. Please keep the battery in cool and dry places. When keeping battery for long time: 1、Remove battery from device；... -
Page 6: Installing Accessories
Installing accessories Installing/Removing battery ※ Do not short out the battery terminal, or set the battery in fire. ※ Do not attempt to remove the shell of battery. ※ Do not install battery in any dangerous condition, since the possible flame may cause explosion. Aim the four dents of battery to the corresponding guides on the back of radio;Push the battery along the guides until the latch on the back of radio clicks. -
Page 7: Installing Antenna
Installing antenna Hold the antenna pedestal, revolve the antenna in clockwise until it is tightened. Antenna Antenna Installing belt clip If needed, screw the belt clip onto the back of radio by two screw holes located on the back of radio to facilitate portability. Belt clip... -
Page 8: Installing Sling
Installing sling Take the tail of sling across the oval hole on the back of radio to install. Installing headset Open the cover from the top of device to show the headset sockets. Headset will work immediately after being plugged in. -
Page 9: Knowing The Device Well
Knowing the device well Antenna Group Selector Knob Switch / Vol Knob Indicator Lanyard Hole Microphone Belt Clip Battery Charging Contact Earphone Jack Microphone Interface Recording Playback Single Call User-defined... -
Page 10: Unit Structure
Unit structure 1.Volume selector/ ON/OFF switch A：Clockwise for switch ON, counterclockwise for switch OFF. B：Clockwise for volume UP, counterclockwise for volume DOWN. 2.Push To Talk button PTT A：Press PTT button to initiate a call (red light goes on) when radio is standing by. B：If not in reception, hold PPT to apply for turn to talk (red light goes on). -
Page 11: Introduction
Introduction 1.Installing battery and SIM card Please insert effective USIM card before use, make sure the USIM card can be effective in any selected WCDMA cellphone. (1)Revolve the volume button to switch ON/OFF device. (2)Remove the battery cover by pushing backwards. (3)Lift USIM socket cover, place the USIM card in the socket well in right direction. -
Page 12: Faq
If your radio shows following problem in use, please check the instruction below, and if the issue still persists, please contact local authorized service. 1.Poor reception: Possible reasons: signal over your current location is weak (such as basement or next to a blocking building), or the network is busy (such as during rush hours). -
Page 13: Indicator Light Interpretation
Indicator light interpretation Device Status Indicator Status Frequency Green on ON/Setting Green flashes fast Searching for network Flash every 1 sec Standing by Green flashes slow Flash every 5 secs Red on Initiating call Receiving call Green on Brief technical data Voltage 3.7V Frequency band... - Page 14 There is not any voice communication or FM transmitter on the device. T196 is a Push-to-Talk radio. Front-of-face position for Head SAR testing is necessary. According to KDB 643646 A2, all sides of the...
- Page 15 FCC Warning Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 16 This mobile device meets guidelines for exposure to radio waves. Your mobile device is a radio transmitter and receiver. It is designed not to exceed the limits for exposure to radio waves recommended by international guidelines. The SAR limit adopted by USA and Canada is 1.6 watts/kilogram (W/kg) averaged over one gram of tissue.
