Summary of Contents for Richsound Research TB232SW
-
Page 1: User Manual
TB232SW USER MANUAL... -
Page 2: Table Of Contents
Contents Important Safety Instructions ................2 Safety ......................................2 Warning .....................................3 What’s in the Box .....................4 Specifications ......................4 Identifying the Parts ....................5 Main Unit ....................................5 Remote Control ..................................5 Preparations......................6 Prepare the Remote Control ..............................6 Replace the Remote Control Battery ..........................6 Placement and Mounting ..............................6 Wall Mounting (if using option-B) ...........................7 Connections ......................8 Use the AUX Socket ................................8... -
Page 3: Important Safety Instructions
Important Safety Instructions 10 Do not defeat the safety purpose of the CAUTION polarized or grounding plug. A polarized RISK OF ELECTRIC SHOCK plug has two blades with one wider than the DO NOT OPEN other. A grounding plug has two blades and a third grounding prong. -
Page 4: Warning
These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock, do not perform The Bluetooth® word mark and logos are any servicing other than that contained in registered trademarks owned by Bluetooth the operating instructions unless you are SIG, Inc. -
Page 5: Identifying The Parts
Identifying the Parts Main Unit Front View Rear View 1 Remote Control Sensor 6 OPTICAL Socket 2 LED Indicators 7 SERVICE ONLY Socket red/Green indicator: In STANDBY/AUX mode. The USB socket is for service only. It is not Orange indicator: In Optical mode. -
Page 6: Preparations
Preparations Prepare the Remote Control The provided Remote Control allows the unit to be operated from a distance. Even if the Remote Control is operated within the effective range (6m), remote control operation may • be impossible if there are any obstacles between the unit and the remote control. If the Remote Control is operated near other products which •... -
Page 7: Wall Mounting (If Using Option-B)
Wall Mounting (if using option-B) Note: Installation must be carried out by qualified personnel only. Incorrect assembly can result in severe personal injury and property damage (if you intend to install this product yourself, you must check for installations such as electrical wiring and plumbing that may be buried inside the wall). It is the installer’s responsibility to verify that the wall will safely support the total load of the unit and wall brackets. -
Page 8: Connections
Connections HDMI socket Using HDMI to connect the soundbar, AV equipment and TV: ARC (Audio Return Channel) The ARC (Audio Return Channel) function allows you to send audio from your ARC- compliant TV to your sound bar through a single HDMI connection. -
Page 9: Use The Aux Socket
Use the AUX Socket A. Use a RCA to 3.5mm audio cable (not included) to connect the TV’s audio output sockets to the AUX 1 socket on the unit. B. Use a 3.5mm to 3.5mm audio cable (included) to connect the TV’s or external audio device headphone socket to the AUX 1 socket on the unit. -
Page 10: Basic Operation
Basic Operation Standby/ON • When you first connect the unit to the main socket, the unit will be in STANDBY mode. The POWER indicator will light up red. • Press the button on the remote control to switch the main unit ON or OFF. •... -
Page 11: Bluetooth Operation
/PAIR" button on the remote control to be searchable. After the “Pairing” voice prompt and the Blue indicator will flash rapidly. 3 Activate your Bluetooth device and select the search mode. “TB232SW” will appear on your Bluetooth device list. 4 Select “B232SW” in the pairing list. After the “Paired” voice prompt, the system is successfully connected and the Blue indicator will light up solidly. -
Page 12: Troubleshooting
Troubleshooting To keep the warranty valid, never try to repair the system yourself. If you encounter problems when using this unit, check the following points before requesting service. No power - Ensure that the AC cord of the apparatus is properly connected . - Ensure that there is power at the AC outlet. -
Page 13: Standard Accessories
Standard Accessories Sound Bar ...................................... x 1 Wire Subwoofer................................... x 1 Remote Control ..................................x 1 Power Cable....................................x 1 3.5mm to 3.5mm audio Cable ............................... x 1 HDMI Cable ....................................x 1 OPTICAL Cable ..................................... x 1 User Manual ....................................x 1 QSG .........................................
